KP36-D (1969)
Toyota Publica
(6904-7404)KB,2K,3K,3KB#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-22012 |
2K,3K..KP3# 12V 30A |
1 | ||
| 27020-22011 |
2K..KP3# 12V 30A |
1 | ||
| 27020-12011 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27020-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27020-24010 |
2K,3K..KP3# 12V 30A |
1 | ||
| 27020-24020 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-22012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27039-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27039-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27113-10012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27113-10011 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27113-10012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27115 - COVER, ALTERNATOR FELT, OUTER | ||||
| 27115-10011 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 90099-19068 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 90099-19068 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-22012 |
KB,2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27310-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-19191 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27412-56040 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 90099-19191 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 97100-06202 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 90099-10012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 90099-10012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27310C - FELT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-02009 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
2 | ||
| 90099-02009 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
2 | ||
| 27315 - COVER, ALTERNATOR FELT, INNER NO.1 | ||||
| 27313-39010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27313-39010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-22012 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27330-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 97110-06201 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-22012 |
2K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27350-22013 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27350-22013 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27350-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27350-22022 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27350-12011 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-24020 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27351-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27351-22010 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27353-22012 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-22011 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27356-22011 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27357-22012 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27357-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370 - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-31090 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370-40061 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370-22011 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27370-22011 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27410-22010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27410-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-24010 |
2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27411-24010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27411-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27411-22011 |
KB,2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27411-12010 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-31090 |
2K,3K#..KP3# 12V 30A |
1 | ||
| 27441-22010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27441-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| Common parts | ||||
| 27383-31011 | ||||
| 27387-31011 | ||||
| 90092-20582 | ||||
| 90093-00409 | ||||
| 90099-00862 | ||||
| 90099-02310 | ||||
| 90099-04808 | ||||
| 90099-05060 | ||||
| 90101-08164 | ||||
| 90119-08023 | ||||
| 90179-08068 | ||||
| 90201-08084 | ||||
| 90440-14034 | ||||
| 93219-14010 | ||||
| 93219-14020 | ||||
| 94120-40600 | ||||
| 94511-00400 | ||||
| 94511-00500 | ||||
| 94511-00600 | ||||
| 94511-01400 | ||||
| 94525-00600 | ||||
| 94612-10800 | ||||
(7201-7212)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-22012 |
2K,3K..KP3# 12V 30A |
1 | ||
| 27020-22011 |
2K..KP3# 12V 30A |
1 | ||
| 27020-12011 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27020-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27020-24010 |
2K,3K..KP3# 12V 30A |
1 | ||
| 27020-24020 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-22012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27039-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27039-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27113-10012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27113-10011 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27113-10012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 90099-19068 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 90099-19068 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-22012 |
KB,2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27310-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-19191 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27412-56040 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 90099-19191 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 97100-06202 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 90099-10012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 90099-10012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27310C - FELT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-02009 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
2 | ||
| 90099-02009 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
2 | ||
| 27315 - COVER, ALTERNATOR FELT, INNER NO.1 | ||||
| 27313-39010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27313-39010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-22012 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27330-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 97110-06201 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-22012 |
2K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27350-22013 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27350-22013 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27350-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27350-22022 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27350-12011 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-24020 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27351-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27351-22010 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27353-22012 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-22011 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27356-22011 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27357-22012 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27357-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370 - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-31090 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370-40061 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370-22011 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27370-22011 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27410-22010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27410-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-24010 |
2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27411-24010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27411-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27411-22011 |
KB,2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27411-12010 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-31090 |
2K,3K#..KP3# 12V 30A |
1 | ||
| 27441-22010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27441-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| Common parts | ||||
| 27378-31011 | ||||
| 27378-45010 | ||||
| 27387-31011 | ||||
| 27445-24030 | ||||
| 27447-56011 | ||||
| 90092-20582 | ||||
| 90099-00862 | ||||
| 90099-02309 | ||||
| 90099-02310 | ||||
| 90099-04259 | ||||
| 90099-05060 | ||||
| 90099-34003 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-10016 | ||||
| 94120-40600 | ||||
| 94511-00600 | ||||
| 94511-01400 | ||||
| 94521-00500 | ||||
| 94525-00600 | ||||
| 94612-11000 | ||||
(7212-7404)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-22012 |
2K,3K..KP3# 12V 30A |
1 | ||
| 27020-22011 |
2K..KP3# 12V 30A |
1 | ||
| 27020-12011 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27020-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27020-24010 |
2K,3K..KP3# 12V 30A |
1 | ||
| 27020-24020 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-22012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27039-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27039-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27113-10012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27113-10011 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27113-10012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 90099-19068 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 90099-19068 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-22012 |
KB,2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27310-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-19191 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27412-56040 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 90099-19191 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 97100-06202 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 90099-10012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 90099-10012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27310C - FELT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-02009 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
2 | ||
| 90099-02009 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
2 | ||
| 27315 - COVER, ALTERNATOR FELT, INNER NO.1 | ||||
| 27313-39010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27313-39010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-22012 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27330-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 97110-06201 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-22012 |
2K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27350-22013 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27350-22013 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27350-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27350-22022 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27350-12011 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-24020 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27351-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27351-22010 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27353 - HOLDER, W/RECTIFIER POSITIVE, ALTERNATOR | ||||
| 27353-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27353-22012 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27356 - HOLDER, W/RECTIFIER NEGATIVE, ALTERNATOR | ||||
| 27356-22011 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27356-22011 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27357-22012 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27357-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370 - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-31090 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370-40061 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370-22011 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27370-22011 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27410-22010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27410-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-24010 |
2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27411-24010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27411-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27411-22011 |
KB,2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27411-12010 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-31090 |
2K,3K#..KP3# 12V 30A |
1 | ||
| 27441-22010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27441-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| Common parts | ||||
| 27287-24031 | ||||
| 27378-24031 | ||||
| 27378-45010 | ||||
| 27387-24031 | ||||
| 27447-56011 | ||||
| 90092-20582 | ||||
| 90099-00862 | ||||
| 90099-02309 | ||||
| 90099-02310 | ||||
| 90099-04259 | ||||
| 90099-05060 | ||||
| 90101-10049 | ||||
| 90119-08023 | ||||
| 90179-10016 | ||||
| 94120-40600 | ||||
| 94511-00600 | ||||
| 94511-01400 | ||||
| 94521-00500 | ||||
| 94612-11000 | ||||
(7404- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 27020 - ALTERNATOR ASSY | ||||
| 27020-22012 |
2K,3K..KP3# 12V 30A |
1 | ||
| 27020-22011 |
2K..KP3# 12V 30A |
1 | ||
| 27020-12011 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27020-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27020-24010 |
2K,3K..KP3# 12V 30A |
1 | ||
| 27020-24020 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27039 - COVER, ALTERNATOR REAR END | ||||
| 27039-22012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27039-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27039-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27113 - PLATE, BEARING RETAINER, ALTERNATOR | ||||
| 27113-10012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27113-10011 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27113-10012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27212 - RING, SPACE(FOR ALTERNATOR ROTOR) | ||||
| 90099-19068 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 90099-19068 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27310 - FRAME ASSY, DRIVE END, ALTERNATOR | ||||
| 27310-22012 |
KB,2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27310-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27310A - COLLAR OR NUT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-19191 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27412-56040 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 90099-19191 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27310B - BEARING(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 97100-06202 |
KB,2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 90099-10012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 90099-10012 |
2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27310C - FELT(FOR ALTERNATOR DRIVE END FRAME) | ||||
| 90099-02009 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
2 | ||
| 90099-02009 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
2 | ||
| 27315 - COVER, ALTERNATOR FELT, INNER NO.1 | ||||
| 27313-39010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27313-39010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27330 - ROTOR ASSY, ALTERNATOR | ||||
| 27330-22012 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27330-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27330A - BEARING(FOR ALTERNATOR ROTOR) | ||||
| 97110-06201 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
1 | ||
| 27350 - FRAME ASSY, RECTIFIER END | ||||
| 27350-22012 |
2K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27350-22013 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27350-22013 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27350-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27350-22022 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27350-12011 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27351 - BUSH(FOR ALTERNATOR RECTIFIER END FRAME) | ||||
| 27351-24020 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27351-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27351-22010 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27357 - HOLDER, ALTERNATOR, W/RECTIFIER | ||||
| 27357-22012 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27357-22012 |
2K,3K,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27357-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27359 - FRAME, ALTERNATOR RECTIFIER END | ||||
| 27359-31090 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27359-31051 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370 - HOLDER ASSY, ALTERNATOR BRUSH | ||||
| 27370-31090 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370-40061 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27370-22011 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27370-22011 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27371 - BRUSH, ALTERNATOR | ||||
| 27371-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27372 - SPRING, ALTERNATOR BRUSH | ||||
| 27372-31011 |
KB,2K,3K,3KB#,3KHJ,3KU,4KJ,2UC..KP3#,50,UP3# 12V 30A,40A |
2 | ||
| 27410 - STATOR ASSY, ALTERNATOR | ||||
| 27410-11014 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27410-22010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27410-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27411 - PULLEY, ALTERNATOR | ||||
| 27411-24010 |
2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27411-24010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| 27411-12012 |
2K,3K#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27411-22011 |
KB,2K,3K,3KB#..KP3# 12V 30A |
1 | ||
| 27411-12010 |
2K,3K,3KB#..KP3#..DLX,HDX,SR,STD 12V 30A |
1 | ||
| 27441 - FAN, ALTERNATOR | ||||
| 27441-31090 |
2K,3K#..KP3# 12V 30A |
1 | ||
| 27441-22010 |
KB,2K,3K,3KB#,2UC..KP3#,UP3# 12V 30A |
1 | ||
| 27441-22010 |
2K,3K,3KB#..KP3#..DLX,HDX,S,SR,STD 12V 30A |
1 | ||
| Common parts | ||||
| 27378-31050 | ||||
| 27387-31011 | ||||
| 27447-24060 | ||||
| 27447-24061 | ||||
| 90099-00862 | ||||
| 90099-01379 | ||||
| 90099-01423 | ||||
| 90099-02310 | ||||
| 90099-04808 | ||||
| 90099-05060 | ||||
| 90099-05118 | ||||
| 90099-05119 | ||||
| 90101-08164 | ||||
| 90119-08023 | ||||
| 90179-06158 | ||||
| 90179-08068 | ||||
| 90440-14001 | ||||
| 90440-14034 | ||||
| 94511-01400 | ||||
| 94612-10800 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
