KP31-G (1972)
Toyota Publica
(7201-7310)ST,XL
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47150 - VALVE ASSY, PROPORTIONING | ||||
| 47150-12011 |
KP31..ST,XL |
1 | ||
| 47150-10020 |
KP30,31 |
1 | ||
| 47311D - GROMMET(FOR FRONT BRAKE TUBE) | ||||
| 90480-15146 |
KP3#,UP3# OD=15 |
2 | ||
| 47311D - GROMMET(FOR FRONT BRAKE TUBE) | ||||
| 90480-15146 |
KP3#,UP3# OD=15 |
2 | ||
| 47312 - TUBE, FRONT BRAKE, NO.2 | ||||
| 47313-10091 |
KP31..ST,XL |
1 | ||
| 47313-10050 |
KP3#,UP3# |
1 | ||
| 47313-10051 |
KP3#..DLX,HDX,S,SR,STD |
1 | ||
| 47313 - TUBE, FRONT BRAKE, NO.3 | ||||
| 47314-10051 |
KP3#..DLX,HDX,S,SR,STD |
1 | ||
| 47314-10081 |
KP3# |
1 | ||
| 47314-10050 |
KP3# |
1 | ||
| 47314-10081 |
KP31..ST,XL |
1 | ||
| 47313A - HOSE, FLEXIBLE, NO.1(FOR FRONT) | ||||
| 90947-02257 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02187 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02100 |
KP3#..SED,V DISC BRAKE |
2 | ||
| 47313A - HOSE, FLEXIBLE, NO.1(FOR FRONT) | ||||
| 90947-02257 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02187 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02100 |
KP3#..SED,V DISC BRAKE |
2 | ||
| 47313D - RING, E(FOR FRONT FLEXIBLE HOSE SETTING) | ||||
| 96160-01200 |
KP3#,50 |
4 | ||
| 47313D - RING, E(FOR FRONT FLEXIBLE HOSE SETTING) | ||||
| 96160-01200 |
KP3#,50 |
4 | ||
| 47313D - RING, E(FOR FRONT FLEXIBLE HOSE SETTING) | ||||
| 96160-01200 |
KP3#,50 |
4 | ||
| 47313D - RING, E(FOR FRONT FLEXIBLE HOSE SETTING) | ||||
| 96160-01200 |
KP3#,50 |
4 | ||
| 47313J - HOSE, FLEXIBLE, NO.2(FOR FRONT) | ||||
| 90947-02188 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02083 |
KP3#..SED,V DISC BRAKE |
2 | ||
| 90947-02256 |
KP30,31 DISC BRAKE |
2 | ||
| 47313J - HOSE, FLEXIBLE, NO.2(FOR FRONT) | ||||
| 90947-02188 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02083 |
KP3#..SED,V DISC BRAKE |
2 | ||
| 90947-02256 |
KP30,31 DISC BRAKE |
2 | ||
| 47316A - HOSE, FLEXIBLE(FOR REAR BRAKE TUBE) | ||||
| 90947-02098 |
KP3# |
1 | ||
| 90947-02226 |
KP3#..SED,V |
1 | ||
| 90947-02171 |
KP3#..SED,V |
1 | ||
| 47316E - RING, E(FOR REAR FLEXIBLE HOSE) | ||||
| 96160-01200 |
KP3#,50 |
2 | ||
| 47316E - RING, E(FOR REAR FLEXIBLE HOSE) | ||||
| 96160-01200 |
KP3#,50 |
2 | ||
| 47321 - TUBE, REAR BRAKE, NO.1 | ||||
| 47315-10020 |
KP31..ST,XL |
1 | ||
| 47315-10020 |
KP30,31 |
1 | ||
| 47323 - TUBE, REAR BRAKE, NO.3 | ||||
| 47316-10062 |
KP3#..(SED,V)..4F..(DLX,HDX,S,SR,STD) |
1 | ||
| 47316-10060 |
KP3#,UP3#..SED,V |
1 | ||
| 47316-10101 |
KP31..ST,XL W/PV |
1 | ||
| 47316-10102 |
KP31..ST,XL W/PV |
1 | ||
| 47316-10103 |
KP30,31..4F |
1 | ||
| 47316-10063 |
KP3#..(SED,V)..4F..(DLX,HDX,S,SR,STD) |
1 | ||
| 47324 - TUBE, REAR BRAKE, NO.4 | ||||
| 47318-10030 |
KP3#..SED,V |
1 | ||
| 47325 - TUBE, REAR BRAKE, NO.5 | ||||
| 47319-10031 |
KP3#..SED,V |
1 | ||
| 47319-10030 |
KP3#,UP3#..SED,V |
1 | ||
| Common parts | ||||
| 91611-40845 | ||||
| 96990-10060 | ||||
(7310-7511)KP30,31 ; (7511-7907)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47150 - VALVE ASSY, PROPORTIONING | ||||
| 47150-12011 |
KP31..ST,XL |
1 | ||
| 47150-10020 |
KP30,31 |
1 | ||
| 47311D - GROMMET(FOR FRONT BRAKE TUBE) | ||||
| 90480-15146 |
KP3#,UP3# OD=15 |
2 | ||
| 47311D - GROMMET(FOR FRONT BRAKE TUBE) | ||||
| 90480-15146 |
KP3#,UP3# OD=15 |
2 | ||
| 47312 - TUBE, FRONT BRAKE, NO.2 | ||||
| 47313-10091 |
KP31..ST,XL |
1 | ||
| 47313-10050 |
KP3#,UP3# |
1 | ||
| 47313-10051 |
KP3#..DLX,HDX,S,SR,STD |
1 | ||
| 47313 - TUBE, FRONT BRAKE, NO.3 | ||||
| 47314-10051 |
KP3#..DLX,HDX,S,SR,STD |
1 | ||
| 47314-10081 |
KP3# |
1 | ||
| 47314-10050 |
KP3# |
1 | ||
| 47314-10081 |
KP31..ST,XL |
1 | ||
| 47313A - HOSE, FLEXIBLE, NO.1(FOR FRONT) | ||||
| 90947-02257 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02187 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02100 |
KP3#..SED,V DISC BRAKE |
2 | ||
| 47313A - HOSE, FLEXIBLE, NO.1(FOR FRONT) | ||||
| 90947-02257 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02187 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02100 |
KP3#..SED,V DISC BRAKE |
2 | ||
| 47313D - RING, E(FOR FRONT FLEXIBLE HOSE SETTING) | ||||
| 96160-01200 |
KP3#,50 |
4 | ||
| 47313D - RING, E(FOR FRONT FLEXIBLE HOSE SETTING) | ||||
| 96160-01200 |
KP3#,50 |
4 | ||
| 47313D - RING, E(FOR FRONT FLEXIBLE HOSE SETTING) | ||||
| 96160-01200 |
KP3#,50 |
4 | ||
| 47313D - RING, E(FOR FRONT FLEXIBLE HOSE SETTING) | ||||
| 96160-01200 |
KP3#,50 |
4 | ||
| 47313J - HOSE, FLEXIBLE, NO.2(FOR FRONT) | ||||
| 90947-02188 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02083 |
KP3#..SED,V DISC BRAKE |
2 | ||
| 90947-02256 |
KP30,31 DISC BRAKE |
2 | ||
| 47313J - HOSE, FLEXIBLE, NO.2(FOR FRONT) | ||||
| 90947-02188 |
KP30,31 DISC BRAKE |
2 | ||
| 90947-02083 |
KP3#..SED,V DISC BRAKE |
2 | ||
| 90947-02256 |
KP30,31 DISC BRAKE |
2 | ||
| 47316A - HOSE, FLEXIBLE(FOR REAR BRAKE TUBE) | ||||
| 90947-02098 |
KP3# |
1 | ||
| 90947-02226 |
KP3#..SED,V |
1 | ||
| 90947-02171 |
KP3#..SED,V |
1 | ||
| 47316E - RING, E(FOR REAR FLEXIBLE HOSE) | ||||
| 96160-01200 |
KP3#,50 |
2 | ||
| 47321 - TUBE, REAR BRAKE, NO.1 | ||||
| 47315-10020 |
KP31..ST,XL |
1 | ||
| 47315-10020 |
KP30,31 |
1 | ||
| 47323 - TUBE, REAR BRAKE, NO.3 | ||||
| 47316-10062 |
KP3#..(SED,V)..4F..(DLX,HDX,S,SR,STD) |
1 | ||
| 47316-10060 |
KP3#,UP3#..SED,V |
1 | ||
| 47316-10101 |
KP31..ST,XL W/PV |
1 | ||
| 47316-10102 |
KP31..ST,XL W/PV |
1 | ||
| 47316-10103 |
KP30,31..4F |
1 | ||
| 47316-10063 |
KP3#..(SED,V)..4F..(DLX,HDX,S,SR,STD) |
1 | ||
| 47324 - TUBE, REAR BRAKE, NO.4 | ||||
| 47318-10030 |
KP3#..SED,V |
1 | ||
| 47325 - TUBE, REAR BRAKE, NO.5 | ||||
| 47319-10031 |
KP3#..SED,V |
1 | ||
| 47319-10030 |
KP3#,UP3#..SED,V |
1 | ||
| Common parts | ||||
| 91611-40840 | ||||
| 91611-60825 | ||||
| 96990-10060 | ||||
