NCP51V-EXPGK (2002)
Toyota Probox/Succeed
(0206-0212)4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88374B - VALVE, SERVICE, NO.1 | ||||
| 88374-30010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88374-30010 |
NCP5#,NLP51 |
1 | ||
| 88374C - VALVE, SERVICE, NO.2 | ||||
| 88374-30010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88374-30010 |
NCP5#,NLP51 |
1 | ||
| 88375B - CAP, SERVICE VALVE, NO.1 | ||||
| 88375-30290 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88375-30290 |
NCP5#,NLP51 |
1 | ||
| 88375D - CAP, SERVICE VALVE, NO.2 | ||||
| 88375-30280 |
NCP5#,NLP51 |
1 | ||
| 88375-30280 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88450 - CONDENSER ASSY, W/RECEIVER | ||||
| 88450-52081 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88450-52080 |
NCP5#..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88450-52080 |
NCP5# |
1 | ||
| 88450-52081 |
NCP5# |
1 | ||
| 88467 - CUSHION, COOLER CONDENSER, NO.1 | ||||
| 88467-12180 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
2 | ||
| 88467-12180 |
NCP5#,NLP51 |
2 | ||
| 88467 - CUSHION, COOLER CONDENSER, NO.1 | ||||
| 88467-12180 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
2 | ||
| 88467-12180 |
NCP5#,NLP51 |
2 | ||
| 88469D - COLLAR, CONDENSER BRACKET, NO.1 | ||||
| 88469-52010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
2 | ||
| 88469-52010 |
NCP5#,NLP51 |
2 | ||
| 88469D - COLLAR, CONDENSER BRACKET, NO.1 | ||||
| 88469-52010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
2 | ||
| 88469-52010 |
NCP5#,NLP51 |
2 | ||
| 88474 - DRYER, COOLER | ||||
| 88474-17010 |
NCP5# |
1 | ||
| 88474-17010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88645H - SWITCH, PRESSURE NO.1 | ||||
| 88645-60030 |
NCP5# |
1 | ||
| 88645-17020 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88645-60030 |
NCP50,51,55,58,59..DX,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88645-17020 |
NCP5# |
1 | ||
| 88706A - TUBE SUB-ASSY, LIQUID, A | ||||
| 88706-52141 |
NCP50,51,55,58,59 |
1 | ||
| 88706-52140 |
NCP50,51,55,58,59 |
1 | ||
| 88706-52141 |
NCP50,51,55,58,59..DX,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88706-52140 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88711 - HOSE, COOLER REFRIGERANT DISCHARGE, NO.1 | ||||
| 88711-52070 |
NCP50,51,55,58,59..4FC..(DX,DXJ,F,TX,U) ｴｱｺﾝ−無し |
1 | ||
| 88711-52070 |
NCP5#..4FC |
1 | ||
| 88712 - HOSE, COOLER REFRIGERANT SUCTION, NO.1 | ||||
| 88712-52121 |
NCP50,51,55,58,59..4FC..(DX,F,TX,U) ｴｱｺﾝ−無し |
1 | ||
| 88712-52120 |
NCP50,51,55,58,59..4FC |
1 | ||
| 88712-52120 |
NCP50,51,55,58,59..4FC..(DX,DXJ,F,TX,U) ｴｱｺﾝ−無し |
1 | ||
| 88712-52121 |
NCP50,51,55,58,59..4FC |
1 | ||
| Common parts | ||||
| 88718-52040 | ||||
| 88718-52050 | ||||
| 88899-52050 | ||||
| 88899-52060 | ||||
| 90099-14119 | ||||
| 90099-14120 | ||||
| 90099-14121 | ||||
| 90099-14122 | ||||
| 90119-06173 | ||||
| 91631-B0618 | ||||
| 91631-B0625 | ||||
| Linked diagrams | ||||
| 8714 | ||||
| 8719 | ||||
(0212- )4FC
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 88374B - VALVE, SERVICE, NO.1 | ||||
| 88374-30010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88374-30010 |
NCP5#,NLP51 |
1 | ||
| 88374C - VALVE, SERVICE, NO.2 | ||||
| 88374-30010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88374-30010 |
NCP5#,NLP51 |
1 | ||
| 88375B - CAP, SERVICE VALVE, NO.1 | ||||
| 88375-30290 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88375-30290 |
NCP5#,NLP51 |
1 | ||
| 88375D - CAP, SERVICE VALVE, NO.2 | ||||
| 88375-30280 |
NCP5#,NLP51 |
1 | ||
| 88375-30280 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88450 - CONDENSER ASSY, W/RECEIVER | ||||
| 88450-52081 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88450-52080 |
NCP5#..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88450-52080 |
NCP5# |
1 | ||
| 88450-52081 |
NCP5# |
1 | ||
| 88467 - CUSHION, COOLER CONDENSER, NO.1 | ||||
| 88467-12180 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
2 | ||
| 88467-12180 |
NCP5#,NLP51 |
2 | ||
| 88467 - CUSHION, COOLER CONDENSER, NO.1 | ||||
| 88467-12180 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
2 | ||
| 88467-12180 |
NCP5#,NLP51 |
2 | ||
| 88469D - COLLAR, CONDENSER BRACKET, NO.1 | ||||
| 88469-52010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
2 | ||
| 88469-52010 |
NCP5#,NLP51 |
2 | ||
| 88469D - COLLAR, CONDENSER BRACKET, NO.1 | ||||
| 88469-52010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
2 | ||
| 88469-52010 |
NCP5#,NLP51 |
2 | ||
| 88474 - DRYER, COOLER | ||||
| 88474-17010 |
NCP5# |
1 | ||
| 88474-17010 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88645H - SWITCH, PRESSURE NO.1 | ||||
| 88645-60030 |
NCP5# |
1 | ||
| 88645-17020 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88645-60030 |
NCP50,51,55,58,59..DX,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88645-17020 |
NCP5# |
1 | ||
| 88706A - TUBE SUB-ASSY, LIQUID, A | ||||
| 88706-52141 |
NCP50,51,55,58,59 |
1 | ||
| 88706-52140 |
NCP50,51,55,58,59 |
1 | ||
| 88706-52141 |
NCP50,51,55,58,59..DX,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88706-52140 |
NCP50,51,55,58,59..DX,DXJ,F,TX,U ｴｱｺﾝ−無し |
1 | ||
| 88711 - HOSE, COOLER REFRIGERANT DISCHARGE, NO.1 | ||||
| 88711-52070 |
NCP50,51,55,58,59..4FC..(DX,DXJ,F,TX,U) ｴｱｺﾝ−無し |
1 | ||
| 88711-52070 |
NCP5#..4FC |
1 | ||
| 88712 - HOSE, COOLER REFRIGERANT SUCTION, NO.1 | ||||
| 88712-52121 |
NCP50,51,55,58,59..4FC..(DX,F,TX,U) ｴｱｺﾝ−無し |
1 | ||
| 88712-52120 |
NCP50,51,55,58,59..4FC |
1 | ||
| 88712-52120 |
NCP50,51,55,58,59..4FC..(DX,DXJ,F,TX,U) ｴｱｺﾝ−無し |
1 | ||
| 88712-52121 |
NCP50,51,55,58,59..4FC |
1 | ||
| Common parts | ||||
| 88718-52040 | ||||
| 88718-52050 | ||||
| 88899-52050 | ||||
| 88899-52060 | ||||
| 88899-52061 | ||||
| 90099-14119 | ||||
| 90099-14120 | ||||
| 90099-14121 | ||||
| 90099-14122 | ||||
| 90119-06173 | ||||
| 91631-B0618 | ||||
| 91631-B0625 | ||||
| Linked diagrams | ||||
| 8714 | ||||
| 8719 | ||||
