NHW20-AHEGB (2005)
Toyota Prius
(0511- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81107 - COMPUTER SUB-ASSY, HEADLAMP LIGHT CONTROL, RH | ||||
| 81107-51050 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 81107-47150 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81107-47150 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81108 - COMPUTER SUB-ASSY, HEADLAMP LIGHT CONTROL, LH | ||||
| 81107-47150 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81107-51050 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 81107-47150 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81110B - BULB(FOR HEADLAMP, NO.1) | ||||
| 90981-13058 |
NHW20 12V 60/55W,ﾊﾛｹﾞﾝ |
2 | ||
| 90981-13058 |
NHW20 12V 60/55W,ﾊﾛｹﾞﾝ |
2 | ||
| 81110L - BULB, DISCHARGE HEADLAMP | ||||
| 90981-20029 |
NHW20 43V 35W,ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
2 | ||
| 90981-20029 |
NHW20..G 43V 35W,ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
2 | ||
| 90981-20007 |
NHW20 85V 35W,ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
2 | ||
| 81118A - BRACKET, HEADLAMP, RH | ||||
| 81118-47060 |
NHW20..G |
1 | ||
| 81118-47060 |
NHW20 |
1 | ||
| 81118A - BRACKET, HEADLAMP, RH | ||||
| 81118-47060 |
NHW20..G |
1 | ||
| 81118-47060 |
NHW20 |
1 | ||
| 81125 - CORD, HEADLAMP | ||||
| 81165-21150 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
2 | ||
| 81125-33460 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
2 | ||
| 81165-21150 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
2 | ||
| 81134 - GASKET, HEADLAMP | ||||
| 90075-68007 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 90075-68007 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 90075-68001 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 81135 - UNIT ASSY, HEADLAMP, RH | ||||
| 81130-47060 |
NHW20 |
1 | ||
| 81130-47140 |
NHW20..G |
1 | ||
| 81145-47150 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81145-47150 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81145-47100 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 81135 - UNIT ASSY, HEADLAMP, RH | ||||
| 81130-47060 |
NHW20 |
1 | ||
| 81130-47140 |
NHW20..G |
1 | ||
| 81145-47150 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81145-47150 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81145-47100 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 81135C - COVER, HEADLAMP BACK, NO.1 | ||||
| 81135-47100 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
2 | ||
| 81135-47100 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
2 | ||
| 81135-47100 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
2 | ||
| 81139 - COVER, HEADLAMP SOCKET | ||||
| 81139-47060 |
NHW20..G |
2 | ||
| 81139-47060 |
NHW20 |
2 | ||
| 81158 - BRACKET, HEADLAMP, LH | ||||
| 81158-47060 |
NHW20 |
1 | ||
| 81158-47060 |
NHW20..G |
1 | ||
| 81158 - BRACKET, HEADLAMP, LH | ||||
| 81158-47060 |
NHW20 |
1 | ||
| 81158-47060 |
NHW20..G |
1 | ||
| 81175 - UNIT ASSY, HEADLAMP, LH | ||||
| 81185-47100 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 81185-47150 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81170-47060 |
NHW20 |
1 | ||
| 81185-47150 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81170-47140 |
NHW20..G |
1 | ||
| 81175 - UNIT ASSY, HEADLAMP, LH | ||||
| 81185-47100 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 81185-47150 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81170-47060 |
NHW20 |
1 | ||
| 81185-47150 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 81170-47140 |
NHW20..G |
1 | ||
| 81193 - RETAINER, HEADLAMP PROTECTOR, UPPER RH | ||||
| 81193-47020 |
NHW20 |
1 | ||
| 81193-47020 |
NHW20..G |
1 | ||
| 81194 - RETAINER, HEADLAMP PROTECTOR, UPPER LH | ||||
| 81194-47020 |
NHW20..G |
1 | ||
| 81194-47020 |
NHW20 |
1 | ||
| 81195A - RETAINER, HEADLAMP PROTECTOR, LOWER RH | ||||
| 81195-47020 |
NHW20 |
1 | ||
| 81195-47020 |
NHW20..G |
1 | ||
| 81196A - RETAINER, HEADLAMP PROTECTOR, LOWER LH | ||||
| 81196-47020 |
NHW20 |
1 | ||
| 81196-47020 |
NHW20..G |
1 | ||
| 81510C - BULB (FOR FRONT TURN SIGNAL LAMP) | ||||
| 90981-15021 |
NHW20 12V 21W,ｱﾝﾊﾞｰ |
2 | ||
| 90981-15011 |
NHW20 12V 21W,ｱﾝﾊﾞｰ |
2 | ||
| 81510C - BULB (FOR FRONT TURN SIGNAL LAMP) | ||||
| 90981-15021 |
NHW20 12V 21W,ｱﾝﾊﾞｰ |
2 | ||
| 90981-15011 |
NHW20 12V 21W,ｱﾝﾊﾞｰ |
2 | ||
| 81515B - SOCKET, FRONT TURN SIGNAL LAMP | ||||
| 90075-60028 |
NHW20..G |
2 | ||
| 90075-60028 |
NHW20 |
2 | ||
| 81515B - SOCKET, FRONT TURN SIGNAL LAMP | ||||
| 90075-60028 |
NHW20..G |
2 | ||
| 90075-60028 |
NHW20 |
2 | ||
| 81610F - BULB(FOR CLEARANCE LAMP) | ||||
| 99132-12050 |
NHW20..G 12V 5W |
2 | ||
| 99132-12050 |
NHW20 12V 5W |
2 | ||
| 81610F - BULB(FOR CLEARANCE LAMP) | ||||
| 99132-12050 |
NHW20..G 12V 5W |
2 | ||
| 99132-12050 |
NHW20 12V 5W |
2 | ||
| 81615D - SOCKET, CLEARANCE LAMP | ||||
| 90075-60046 |
NHW20 |
2 | ||
| 90075-60004 |
NHW20..G |
2 | ||
| 81615D - SOCKET, CLEARANCE LAMP | ||||
| 90075-60046 |
NHW20 |
2 | ||
| 90075-60004 |
NHW20..G |
2 | ||
| 85661 - MOTOR, HEADLAMP LEVELING, RH | ||||
| 85661-22020 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 85661-12010 |
NHW20..G |
1 | ||
| 85661-12020 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 85661-12020 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 85661 - MOTOR, HEADLAMP LEVELING, RH | ||||
| 85661-22020 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 85661-12010 |
NHW20..G |
1 | ||
| 85661-12020 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 85661-12020 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 85662 - MOTOR, HEADLAMP LEVELING, LH | ||||
| 85661-12020 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 85661-12020 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 85661-12010 |
NHW20..G |
1 | ||
| 85661-22020 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 85662 - MOTOR, HEADLAMP LEVELING, LH | ||||
| 85661-12020 |
NHW20..G ﾂｰﾘﾝｸﾞﾚｻﾞｰﾊﾟｯｹｰｼﾞ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 85661-12020 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ&ﾍｯﾄﾞﾗﾝﾌﾟ−ﾃﾞｨｽﾁｬｰｼﾞ(2灯式) |
1 | ||
| 85661-12010 |
NHW20..G |
1 | ||
| 85661-22020 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
1 | ||
| 85669 - PACKING, HEADLAMP LEVELING MOTOR BASE | ||||
| 90075-99120 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
2 | ||
| 90075-99120 |
NHW20..G |
2 | ||
| 85669 - PACKING, HEADLAMP LEVELING MOTOR BASE | ||||
| 90075-99120 |
NHW20 ﾂｰﾘﾝｸﾞｾﾚｸｼｮﾝ |
2 | ||
| 90075-99120 |
NHW20..G |
2 | ||
| Common parts | ||||
| 90075-02727 | ||||
| 90109-06122 | ||||
| 90179-06127 | ||||
| Linked diagrams | ||||
| 7403 | ||||
