ZRT265-AEXEK (2007)
Toyota Premio/Allion
(0705- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 82210K - HARNESS ASSY, AIR CONDITIONER | ||||
| 82212-12020 |
NZT260,ZRT26#..CBU |
1 | ||
| 87050 - RADIATOR ASSY, AIR CONDITIONER | ||||
| 87050-12360 |
NZT260,ZRT26#..CBU 寒冷地仕様 |
1 | ||
| 87050-12350 |
NZT260,ZRT26#..CBU |
1 | ||
| 87103B - MOTOR SUB-ASSY, BLOWER W/FAN | ||||
| 87103-12060 |
NZT260,ZRT26#..CBU |
1 | ||
| 87106H - SERVO SUB-ASSY, DAMPER(FOR AIRMIX) | ||||
| 87106-12170 |
NZT260,ZRT26#..CBU |
1 | ||
| 87106J - SERVO SUB-ASSY, DAMPER(FOR MODE) | ||||
| 87106-42100 |
NZT260,ZRT26#..CBU |
1 | ||
| 87106N - SERVO SUB-ASSY, DAMPER(FOR RECIRCULATION) | ||||
| 87106-42120 |
NZT260,ZRT26#..CBU |
1 | ||
| 87107A - UNIT SUB-ASSY, HEATER RADIATOR | ||||
| 87107-42170 |
NZT260,ZRT26#..CBU |
1 | ||
| 87114B - COVER, HEATER | ||||
| 87114-12080 |
NZT260,ZRT26#..CBU 寒冷地仕様 |
1 | ||
| 87114-12080 |
NZT260,ZRT26#..CBU |
1 | ||
| 87130D - BLOWER ASSY | ||||
| 87130-12530 |
NZT260,ZRT26#..CBU |
1 | ||
| 87130-12541 |
NZT260,ZRT26#..CBU 寒冷地仕様 |
1 | ||
| 87130-12540 |
NZT260,ZRT26#..CBU 寒冷地仕様 |
1 | ||
| 87130-12531 |
NZT260,ZRT26#..CBU |
1 | ||
| 87139C - FILTER, CLEAN AIR | ||||
| 87139-50060 |
NZT260,ZRT26#..CBU 脱臭ﾌｨﾙﾀ |
1 | ||
| 87139-30040 |
NZT260,ZRT26#..CBU 花粉ﾌｨﾙﾀ |
1 | ||
| 87710G - QUICK HEATER ASSY | ||||
| 87710-12010 |
NZT260,ZRT26#..CBU 寒冷地仕様 |
1 | ||
| 88501 - EVAPORATOR SUB-ASSY, COOLER, NO.1 | ||||
| 88501-26210 |
NZT260,ZRT26#..CBU |
1 | ||
| 88501-72020 |
NZT260,ZRT26#..CBU |
1 | ||
| 88501-26211 |
NZT260,ZRT26#..CBU |
1 | ||
| 88515 - VALVE, COOLER EXPANSION | ||||
| 88515-42090 |
NZT260,ZRT26#..CBU |
1 | ||
| 88515-42090 |
NZT260,ZRT26#..CBU |
1 | ||
| 88539J - HOSE, DRAIN COOLER | ||||
| 88539-12190 |
NZT260,ZRT26#..CBU |
1 | ||
| 88548B - CASE, AIR FILTER | ||||
| 88548-42010 |
NZT260,ZRT26#..CBU |
1 | ||
| 88625 - THERMISTOR, COOLER, NO.1 | ||||
| 88625-26090 |
NZT260,ZRT26#..CBU |
1 | ||
| 88650N - AMPLIFIER ASSY, AIR CONDITIONER | ||||
| 88650-20A30 |
ZRT26#..CBU 寒冷地仕様 |
1 | ||
| 88650-20A40 |
ZRT26#..CBU |
1 | ||
| 88650-20A50 |
ZRT260,265..CBU Standard Package *(U) or “Version C”*(C)&寒冷地仕様 |
1 | ||
| 88650-20A60 |
ZRT260,265..CBU Standard Package *(U) or “Version C”*(C) |
1 | ||
| Common parts | ||||
| 87128-42010 | ||||
| 90099-00318 | ||||
| 90099-14120 | ||||
| 90099-14121 | ||||
| 90119-06144 | ||||
| 90119-06942 | ||||
| 90159-60303 | ||||
| 90159-60383 | ||||
| 90179-06282 | ||||
