ZRT260-CEXEP (2010)
Toyota Premio/Allion
(1004-1606)ALN
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47749F - CLIP, PIN HOLD | ||||
| 47749-58010 |
NZT260,ZRT26#..CBU |
2 | ||
| 52021 - REINFORCEMENT SUB-ASSY, FRONT BUMPER | ||||
| 52021-20270 |
NZT260,ZRT26#..CBU |
1 | ||
| 52115A - SUPPORT, FRONT BUMPER SIDE, RH | ||||
| 52115-20420 |
NZT260,ZRT26#..ALN..CBU |
1 | ||
| 52116A - SUPPORT, FRONT BUMPER SIDE, LH | ||||
| 52116-20290 |
NZT260,ZRT26#..ALN..CBU |
1 | ||
| 52119A - COVER, FRONT BUMPER | ||||
| 52119-20B20C0 |
NZT260,ZRT26#..ALN..CBU BLACK MC.,209 |
1 | ||
| 52119-20B20J0 |
NZT260,ZRT26#..ALN..CBU DK.BLUE MC.,8S6 |
1 | ||
| 52119-20B20E0 |
NZT260,ZRT26#..ALN..CBU BEIGE ME.,4T8 |
1 | ||
| 52119-20B20D0 |
NZT260,ZRT26#..ALN..CBU BLACKISH RED MC.,3R0 |
1 | ||
| 52119-20B20A1 |
NZT260,ZRT26#..ALN..CBU WHITE PEARL CS.,070 |
1 | ||
| 52119-20B20A0 |
NZT260,ZRT26#..ALN..CBU SUPER WHITE 2,040 |
1 | ||
| 52119-20B20B0 |
NZT260,ZRT26#..ALN..CBU SILVER ME.,1F7 |
1 | ||
| 52119-20B20B1 |
NZT260,ZRT26#..ALN..CBU GRAY ME.,1G3 |
1 | ||
| 52119-20B20C1 |
NZT260,ZRT26#..ALN..CBU BLACK,202 |
1 | ||
| 52119-20B20H0 |
NZT260,ZRT26#..ALN..CBU CLEAR STREAM ME.,787 |
1 | ||
| 52119-20B20C1 |
NZT260,ZRT26#..ALN..CBU BLACK,202 |
1 | ||
| 52119-20B20D0 |
NZT260,ZRT26#..ALN..CBU BLACKISH RED MC.,3R0 |
1 | ||
| 52119-20B20B1 |
NZT260,ZRT26#..ALN..CBU GRAY ME.,1G3 |
1 | ||
| 52119-20B70A1 |
NZT260,ZRT26#..ALN..CBU WHITE PEARL CS.,070 |
1 | ||
| 52119-20B20A0 |
NZT260,ZRT26#..ALN..CBU SUPER WHITE 2,040 |
1 | ||
| 52119-20B20H0 |
NZT260,ZRT26#..ALN..CBU CLEAR STREAM ME.,787 |
1 | ||
| 52119-20B20B0 |
NZT260,ZRT26#..ALN..CBU SILVER ME.,1F7 |
1 | ||
| 52119C - CLIP, FRONT BUMPER COVER | ||||
| 90467-05114 |
NZT260,ZRT26#..CBU |
2 | ||
| 52119D - SCREW, NO.1 | ||||
| 90159-60215 |
ZRT260,265..ALN..CBU Lﾊﾟｯｹｰｼﾞ OR Gﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ |
6 | ||
| 90159-60215 |
NZT260..CBU;ZRT26#..ALN..CBU |
6 | ||
| 90159-60215 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
6 | ||
| 90159-60215 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
6 | ||
| 90159-60488 |
NZT260,ZRT26#..CBU |
6 | ||
| 52119D - SCREW, NO.1 | ||||
| 90159-60215 |
ZRT260,265..ALN..CBU Lﾊﾟｯｹｰｼﾞ OR Gﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ |
6 | ||
| 90159-60215 |
NZT260..CBU;ZRT26#..ALN..CBU |
6 | ||
| 90159-60215 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
6 | ||
| 90159-60215 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
6 | ||
| 90159-60488 |
NZT260,ZRT26#..CBU |
6 | ||
| 52127D - COVER, FRONT BUMPER HOLE, RH | ||||
| 52127-20270 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−HDDﾅﾋﾞｹﾞｰｼｮﾝ AM/FM CD 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20250 |
ZRT26#..ALN..CBU |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU Lﾊﾟｯｹｰｼﾞ OR Gﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ |
1 | ||
| 52127D - COVER, FRONT BUMPER HOLE, RH | ||||
| 52127-20270 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−HDDﾅﾋﾞｹﾞｰｼｮﾝ AM/FM CD 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20250 |
ZRT26#..ALN..CBU |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
1 | ||
| 52127-20270 |
ZRT260,265..ALN..CBU Lﾊﾟｯｹｰｼﾞ OR Gﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ |
1 | ||
| 52128B - COVER, FRONT BUMPER HOLE, LH | ||||
| 52128-20230 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−HDDﾅﾋﾞｹﾞｰｼｮﾝ AM/FM CD 6ｽﾋﾟｰｶ |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU Lﾊﾟｯｹｰｼﾞ OR Gﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ |
1 | ||
| 52128-20150 |
ZRT26#..ALN..CBU |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
1 | ||
| 52128B - COVER, FRONT BUMPER HOLE, LH | ||||
| 52128-20230 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−HDDﾅﾋﾞｹﾞｰｼｮﾝ AM/FM CD 6ｽﾋﾟｰｶ |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU Sﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−5.8ｲﾝﾁﾓﾆﾀ CD 6ｽﾋﾟｰｶ |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU Lﾊﾟｯｹｰｼﾞ OR Gﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ |
1 | ||
| 52128-20150 |
ZRT26#..ALN..CBU |
1 | ||
| 52128-20230 |
ZRT260,265..ALN..CBU EXﾊﾟｯｹｰｼﾞ OR G−plusﾊﾟｯｹｰｼﾞ&ｴｱﾛﾊﾟｯｹｰｼﾞ&ｵｰﾃﾞｨｵ−ﾗｼﾞｵﾚｽ 6ｽﾋﾟｰｶ |
1 | ||
| 52161C - PIECE, FRONT BUMPER | ||||
| 52161-16010 |
NZT260,ZRT26#..ALN..CBU |
4 | ||
| 52521B - RETAINER, FRONT BUMPER, UPPER | ||||
| 52521-20240 |
NZT260,ZRT26#..ALN..CBU |
1 | ||
| 52541 - PROTECTOR, FRONT BUMPER | ||||
| 52541-20020 |
NZT260,ZRT26#..ALN..CBU |
1 | ||
| 52542A - PROTECTOR, FRONT BUMPER, NO.2 | ||||
| 52542-20020 |
NZT260,ZRT26#..ALN..CBU |
1 | ||
| 52611 - ABSORBER, FRONT BUMPER ENERGY | ||||
| 52611-20240 |
NZT260,ZRT26#..CBU |
1 | ||
| 52618 - ABSORBER, FRONT BUMPER, LOWER | ||||
| 52618-20030 |
NZT260,ZRT26#..CBU |
1 | ||
| 53112E - GRILLE, RADIATOR, LOWER NO.1 | ||||
| 53112-20320 |
NZT260,ZRT26#..ALN..CBU 塗装不要 |
1 | ||
| 53879H - RETAINER, FRONT FENDER LINER | ||||
| 53879-58010 |
NZT260,ZRT26#..CBU |
2 | ||
| 76851G - GROMMET, SCREW, NO.1 | ||||
| 90189-06237 |
NZT260,ZRT26#..CBU |
4 | ||
| 90189-06193 |
NZT260,ZRT26#..CBU |
4 | ||
| 76851G - GROMMET, SCREW, NO.1 | ||||
| 90189-06237 |
NZT260,ZRT26#..CBU |
4 | ||
| 90189-06193 |
NZT260,ZRT26#..CBU |
4 | ||
| Common parts | ||||
| 90119-06818 | ||||
| 90119-08630 | ||||
| 90159-50311 | ||||
| 90159-60431 | ||||
| 90176-08054 | ||||
| 90179-06127 | ||||
| 90189-05096 | ||||
| 90467-08185 | ||||
| Linked diagrams | ||||
| 5301 | ||||
| 7501 | ||||
| 8101 | ||||
| 8102 | ||||
| 8417 | ||||
