S321M-ZQGF3 (2015)
Toyota Pixis Van
Production
Mar 2015
-
Nov 2017
Engine
KFVE
Transmission
Displacement
2500cc
Power
168 HP (125 kW)
(1112-1711)
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81550 - LAMP ASSY, REAR COMBINATION, RH | ||||
| 81550-B5020 |
S321,331..PS2 |
1 | ||
| 81550H - BULB, TAIL & STOP LAMP | ||||
| 90049-51130 |
S321,331..PS2 |
2 | ||
| 81550L - BULB, REAR TURN SIGNAL LAMP | ||||
| 90049-51143 |
S321,331..PS2 |
2 | ||
| 81550N - BULB, BACK UP LAMP | ||||
| 90981-11059 |
S321,331..PS2 |
2 | ||
| 81550W - SCREW(FOR RR COMBINATION LAMP) | ||||
| 81559-87605 |
S321,331..PS2 長さ=35,径=5 |
2 | ||
| 81551D - LENS & BODY, REAR COMBINATION LAMP, RH | ||||
| 81551-97509 |
S321,331..PS2 |
1 | ||
| 81555 - SOCKET & WIRE SUB-ASSY, REAR COMBINATION LAMP, RH | ||||
| 81555-97503 |
S321,331..PS2 |
1 | ||
| 81560 - LAMP ASSY, REAR COMBINATION, LH | ||||
| 81560-B5020 |
S321,331..PS2 |
1 | ||
| 81561D - LENS & BODY, REAR COMBINATION LAMP, LH | ||||
| 81561-97509 |
S321,331..PS2 |
1 | ||
| 81565A - SOCKET & WIRE SUB-ASSY, REAR COMBINATION LAMP, LH | ||||
| 81555-97503 |
S321,331..PS2 |
1 | ||
| Common parts | ||||
| 90041-89048 | ||||
| Linked diagrams | ||||
| 8202 | ||||
