LA350A-GBRF (2017)
Toyota Pixis Epoch
Production
May 2017
-
Sep 9999
Engine
KFVE
Transmission
CVT
Displacement
2500cc
Power
168 HP (125 kW)
ILLUST NO. 2 OF 2(1705- )
Click highlighted areas on diagram
ILLUST NO.2 OF 2
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 44510 - ACTUATOR ASSY, BRAKE | ||||
| 44050-B2K10 |
LA350..B,G,L,X |
1 | ||
| 44521A - COLLAR, BRAKE ACTUATOR CASE, NO.1 | ||||
| 44521-B1010 |
LA350,360 |
3 | ||
| 44521A - COLLAR, BRAKE ACTUATOR CASE, NO.1 | ||||
| 44521-B1010 |
LA350,360 |
3 | ||
| 44521A - COLLAR, BRAKE ACTUATOR CASE, NO.1 | ||||
| 44521-B1010 |
LA350,360 |
3 | ||
| 44546A - CUSHION, BRAKE ACTUATOR BOLT | ||||
| 44546-12110 |
LA350,360 |
3 | ||
| 44546A - CUSHION, BRAKE ACTUATOR BOLT | ||||
| 44546-12110 |
LA350,360 |
3 | ||
| 44546A - CUSHION, BRAKE ACTUATOR BOLT | ||||
| 44546-12110 |
LA350,360 |
3 | ||
| 44591 - BRACKET, BRAKE ACTUATOR, NO.1 | ||||
| 44591-B2200 |
LA350,360 |
1 | ||
| Common parts | ||||
| 90119-06834 | ||||
| 94151-80801 | ||||
| Linked diagrams | ||||
| 1107 | ||||
| 8202 | ||||
ILLUST NO. 1 OF 2(1705- )
Click highlighted areas on diagram
ILLUST NO.1 OF 2
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 47311 - TUBE, FRONT BRAKE, NO.1 | ||||
| 47311-B2590 |
LA350,360 |
1 | ||
| 47311 - TUBE, FRONT BRAKE, NO.1 | ||||
| 47311-B2590 |
LA350,360 |
1 | ||
| 47312 - TUBE, FRONT BRAKE, NO.2 | ||||
| 47312-B2480 |
LA350,360 |
1 | ||
| 47312 - TUBE, FRONT BRAKE, NO.2 | ||||
| 47312-B2480 |
LA350,360 |
1 | ||
| 47313 - TUBE, FRONT BRAKE, NO.3 | ||||
| 47313-B2600 |
LA350,360 |
1 | ||
| 47313 - TUBE, FRONT BRAKE, NO.3 | ||||
| 47313-B2600 |
LA350,360 |
1 | ||
| 47313A - HOSE, FLEXIBLE, NO.1(FOR FRONT) | ||||
| 90049-22315 |
LA350,360 |
1 | ||
| 47313B - BOLT, UNION(FOR FRONT FLEXIBLE HOSE) | ||||
| 90401-10058 |
LA350,360 |
2 | ||
| 47313B - BOLT, UNION(FOR FRONT FLEXIBLE HOSE) | ||||
| 90401-10058 |
LA350,360 |
2 | ||
| 47313J - HOSE, FLEXIBLE, NO.2(FOR FRONT) | ||||
| 90049-22316 |
LA350,360 |
1 | ||
| 47313P - GASKET(FOR FRONT FLEXIBLE HOSE) | ||||
| 47389-50020 |
LA350,360 |
2 | ||
| 47313P - GASKET(FOR FRONT FLEXIBLE HOSE) | ||||
| 47389-50020 |
LA350,360 |
2 | ||
| 47314 - TUBE, FRONT BRAKE, NO.4 | ||||
| 47314-B2330 |
LA350,360 |
1 | ||
| 47314 - TUBE, FRONT BRAKE, NO.4 | ||||
| 47314-B2330 |
LA350,360 |
1 | ||
| 47318F - HOSE, FLEXIBLE(FOR REAR RH) | ||||
| 90049-22202 |
LA350..B,G,L,X |
1 | ||
| 47319F - HOSE, FLEXIBLE(FOR REAR LH) | ||||
| 90049-22202 |
LA350..B,G,L,X |
1 | ||
| 47322 - TUBE, REAR BRAKE, NO.2 | ||||
| 47322-B2720 |
LA350..B,G,L,X |
1 | ||
| 47322 - TUBE, REAR BRAKE, NO.2 | ||||
| 47322-B2720 |
LA350..B,G,L,X |
1 | ||
| 47324 - TUBE, REAR BRAKE, NO.4 | ||||
| 47324-B2720 |
LA350..B,G,L,X |
1 | ||
| 47324 - TUBE, REAR BRAKE, NO.4 | ||||
| 47324-B2720 |
LA350..B,G,L,X |
1 | ||
| 47325 - TUBE, REAR BRAKE, NO.5 | ||||
| 47325-B2060 |
LA350..B,G,L,X |
1 | ||
| 47326 - TUBE, REAR BRAKE, NO.6 | ||||
| 47326-B2060 |
LA350..B,G,L,X |
1 | ||
| 47371A - CLAMP, BRAKE TUBE, NO.1 | ||||
| 47372-B2030 |
LA350,360 |
1 | ||
| 47371G - CLAMP, BRAKE TUBE, NO.11 | ||||
| 90044-65441 |
LA350,360 |
2 | ||
| 47371G - CLAMP, BRAKE TUBE, NO.11 | ||||
| 90044-65441 |
LA350,360 |
2 | ||
| 47371H - CLAMP, BRAKE TUBE, NO.12 | ||||
| 90044-65441 |
LA350,360 |
4 | ||
| 47371H - CLAMP, BRAKE TUBE, NO.12 | ||||
| 90044-65441 |
LA350,360 |
4 | ||
| 47371H - CLAMP, BRAKE TUBE, NO.12 | ||||
| 90044-65441 |
LA350,360 |
4 | ||
| 47371H - CLAMP, BRAKE TUBE, NO.12 | ||||
| 90044-65441 |
LA350,360 |
4 | ||
| 47372 - CLAMP, BRAKE TUBE, NO.2 | ||||
| 90044-64889 |
LA350 |
2 | ||
| 90044-64918 |
LA350 |
2 | ||
| 47373B - CLAMP, BRAKE TUBE, NO.3 | ||||
| 90044-64891 |
LA350,360 |
1 | ||
| 47374B - CLAMP, BRAKE TUBE, NO.4 | ||||
| 90044-64892 |
LA350,360 |
1 | ||
| 47375 - CLAMP, BRAKE TUBE, NO.5 | ||||
| 47372-B2070 |
LA350,360 |
1 | ||
| Common parts | ||||
| 91551-80816 | ||||
| Linked diagrams | ||||
| 4702 | ||||
| 7701 | ||||
