Toyota Passo KGC10 BACK DOOR LOCK & HANDLE

Part #	Description	Period	Qty
68810C - HINGE ASSY, BACK DOOR, RH
68801-B1010	KGC1#,QNC10	05/2004 - 12/2006	1
68820C - HINGE ASSY, BACK DOOR, LH
68801-B1010	KGC1#,QNC10	05/2004 - 12/2006	1
68841A - CLIP(FOR TORSION BAR COVER)
90044-67474	KGC1#,QNC10	05/2004 - 12/2006	2
68859 - PACKING, BACK DOOR HINGE
68859-87201	KGC1#,QNC10	05/2004 - 12/2006	2
68859 - PACKING, BACK DOOR HINGE
68859-87201	KGC1#,QNC10	05/2004 - 12/2006	2
68950C - STAY ASSY, BACK DOOR, RH
68950-B1010	KGC1#,QNC10	05/2004 - 10/2005	1
68950-B1011	KGC1#,QNC10	11/2005 - 12/2006	1
68950-B1021	KGC10 ﾘﾔｳｨﾝﾄﾞｳﾜｲﾊﾟｰ無し	11/2005 - 12/2006	1
68950-B1020	KGC10 ﾘﾔｳｨﾝﾄﾞｳﾜｲﾊﾟｰ無し	05/2004 - 10/2005	1
68960 - STAY ASSY, BACK DOOR, LH
68960-B1011	KGC1#,QNC10	11/2005 - 12/2006	1
68960-B1020	KGC10 ﾘﾔｳｨﾝﾄﾞｳﾜｲﾊﾟｰ無し	05/2004 - 10/2005	1
68960-B1021	KGC10 ﾘﾔｳｨﾝﾄﾞｳﾜｲﾊﾟｰ無し	11/2005 - 12/2006	1
68960-B1010	KGC1#,QNC10	05/2004 - 10/2005	1
68960B - STAY ASSY, BACK DOOR, LH
68960-B9090	KGC10 ﾘﾔｳｨﾝﾄﾞｳﾜｲﾊﾟｰ無し	05/2004 - 12/2006	1
68960-B9080	KGC1#,QNC10	05/2004 - 12/2006	1
68961 - BOLT, BACK DOOR STAY
68961-B1010	KGC1#,QNC10	05/2004 - 12/2006	2
68961 - BOLT, BACK DOOR STAY
68961-B1010	KGC1#,QNC10	05/2004 - 12/2006	2
68970 - STAY ASSY, BACK DOOR, RH
68950-B9080	KGC1#,QNC10	05/2004 - 12/2006	1
68950-B9090	KGC10 ﾘﾔｳｨﾝﾄﾞｳﾜｲﾊﾟｰ無し	05/2004 - 12/2006	1
69211C - HANDLE, BACK DOOR OUTSIDE
69023-B1010	KGC1#,QNC10	05/2004 - 12/2006	1
69250E - COVER ASSY, DOOR OUTSIDE HANDLE
69250-B1050B2	KGC1#,QNC10 DK.BLUE M.M.,B42	05/2004 - 12/2006	1
69250-B1050G0	KGC1#,QNC10..G,X LIME GREEN ME.,G40	05/2004 - 12/2006	1
69250-B1050R0	KGC1#,QNC10 RED,R40	05/2004 - 12/2006	1
69250-B1050X7	KGC1#,QNC10 BLACK M.M.,X07	05/2004 - 12/2006	1
69250-B1050R3	KGC1#,QNC10..G,X MD CORAL ME.,R43	05/2004 - 12/2006	1
69250-B1050W9	KGC1#,QNC10 WHITE,W09	05/2004 - 12/2006	1
69250-B1050S8	KGC1#,QNC10 SILVER ME.,S28	05/2004 - 12/2006	1
69250-B1050T7	KGC1#,QNC10..G,X CHAMPAGNE ME.OP.,T17	05/2004 - 12/2006	1
69250-B1050W6	KGC1#,QNC10 WHITE PEARL.MC.,W16	05/2004 - 12/2006	1
69250-B1050B7	KGC1#,QNC10..G,X LT.BLUE ME.OP.,B57	05/2004 - 12/2006	1
69350P - LOCK ASSY, BACK DOOR, W/COURTESY LAMP SWITCH
69350-B1011	KGC1#,QNC10	07/2006 - 12/2006	1
69350-B1010	KGC1#,QNC10	05/2004 - 06/2006	1
69430C - STRIKER ASSY, BACK DOOR LOCK
69430-97401	KGC1#,QNC10	05/2004 - 12/2006	1
Common parts
68459-87201
90041-79104
90041-79288
90105-08148
90119-08061
91511-B0614

KGC10-AHSAK (2004)

(0405-1002)
