KGC10-AHSAK (2004)
Toyota Passo
(0405-1002)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 62111B - CLIP(FOR COWL SIDE TRIM) | ||||
| 90044-67397N1 |
KGC1#,QNC10 BLACK |
2 | ||
| 62111B - CLIP(FOR COWL SIDE TRIM) | ||||
| 90044-67397N1 |
KGC1#,QNC10 BLACK |
2 | ||
| 62111C - BOARD, COWL SIDE TRIM, RH | ||||
| 62111-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 62112 - BOARD, COWL SIDE TRIM, LH | ||||
| 62112-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 62117A - COVER, COWL SIDE TRIM SERVICE HOLE | ||||
| 62117-B1020B0 |
KGC1#,QNC10 DK.GRAY,TRIM1#,ﾋﾀﾞﾘｶﾞﾜﾊﾂｴﾝﾄｳｶｸﾉｳｱﾘ |
1 | ||
| 62211 - GARNISH, FRONT PILLAR, RH | ||||
| 62211-B1020B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62211-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62212 - GARNISH, FRONT PILLAR, LH | ||||
| 62212-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62212-B1020B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62411B - GARNISH, CENTER PILLAR, UPPER RH | ||||
| 62411-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62411-B1020B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62412B - GARNISH, CENTER PILLAR, UPPER LH | ||||
| 62412-B1020B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62412-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62413A - GARNISH, CENTER PILLAR, LOWER RH | ||||
| 62413-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 62413C - CLIP (FOR CENTER LOWER GARNISH) | ||||
| 67771-B2010 |
KGC1#,QNC10 |
4 | ||
| 62414A - GARNISH, CENTER PILLAR, LOWER LH | ||||
| 62414-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 62471A - GARNISH, ROOF SIDE, INNER RH | ||||
| 62471-B1050B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1020B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞ ﾄﾚｲ ﾄﾘﾑ & ﾄﾉｶﾊﾞｰ−有り,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1010B0 |
KGC1#,QNC10 LT.GRAY |
1 | ||
| 62471-B1010B0 |
KGC1#,QNC10 LT.GRAY |
1 | ||
| 62471-B1050B0 |
KGC1#,QNC10 D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1060B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞ ﾄﾚｲ ﾄﾘﾑ & ﾄﾉｶﾊﾞｰ−有り&SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1020B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞﾄﾚｲﾂｷ,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1060B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞﾄﾚｲﾂｷ&D/P,ｻｲﾄﾞｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62471F - CLIP (FOR ROOF SIDE, INNER UPPER GARNISH) | ||||
| 67771-B2010 |
KGC1#,QNC10 左側 |
6 | ||
| 62472A - GARNISH, ROOF SIDE, INNER LH | ||||
| 62472-B1030B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1040B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞ ﾄﾚｲ ﾄﾘﾑ & ﾄﾉｶﾊﾞｰ−有り&SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1020B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞﾄﾚｲｱﾘ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1040B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞﾄﾚｲｱﾘ & D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1020B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞ ﾄﾚｲ ﾄﾘﾑ & ﾄﾉｶﾊﾞｰ−有り,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1030B0 |
KGC1#,QNC10 D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62472-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 67913 - PLATE, FRONT DOOR SCUFF, RH | ||||
| 67913-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 67914 - PLATE, FRONT DOOR SCUFF, LH | ||||
| 67914-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 67917A - PLATE, REAR DOOR SCUFF, RH | ||||
| 67917-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 67918A - PLATE, REAR DOOR SCUFF, LH | ||||
| 67918-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| Linked diagrams | ||||
| 7104 | ||||
| 8401 | ||||
(0405-1002)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 61719C - BRACKET, ROOF SIDE RAIL, RH | ||||
| 61719-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,NO.2 |
1 | ||
| 61707-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,NO.1 |
1 | ||
| 61719C - BRACKET, ROOF SIDE RAIL, RH | ||||
| 61719-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,NO.2 |
1 | ||
| 61707-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,NO.1 |
1 | ||
| 61729B - BRACKET, ROOF SIDE RAIL, LH | ||||
| 61729-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,NO.2 |
1 | ||
| 61708-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,NO.1 |
1 | ||
| 61729B - BRACKET, ROOF SIDE RAIL, LH | ||||
| 61729-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,NO.2 |
1 | ||
| 61708-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,NO.1 |
1 | ||
| 62111B - CLIP(FOR COWL SIDE TRIM) | ||||
| 90044-67397N1 |
KGC1#,QNC10 BLACK |
2 | ||
| 62111B - CLIP(FOR COWL SIDE TRIM) | ||||
| 90044-67397N1 |
KGC1#,QNC10 BLACK |
2 | ||
| 62111C - BOARD, COWL SIDE TRIM, RH | ||||
| 62111-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 62112 - BOARD, COWL SIDE TRIM, LH | ||||
| 62112-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 62117A - COVER, COWL SIDE TRIM SERVICE HOLE | ||||
| 62117-B1020B0 |
KGC1#,QNC10 DK.GRAY,TRIM1#,ﾋﾀﾞﾘｶﾞﾜﾊﾂｴﾝﾄｳｶｸﾉｳｱﾘ |
1 | ||
| 62170A - AIR BAG ASSY, CURTAIN SHIELD, RH | ||||
| 62170-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ |
1 | ||
| 62180A - AIR BAG ASSY, CURTAIN SHIELD, LH | ||||
| 62180-B1010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ |
1 | ||
| 62211 - GARNISH, FRONT PILLAR, RH | ||||
| 62211-B1020B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62211-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62211T - CLIP(FOR FRONT PILLAR GARNISH) | ||||
| 62217-44010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,左側 |
1 | ||
| 62212 - GARNISH, FRONT PILLAR, LH | ||||
| 62212-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62212-B1020B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62217G - CLIP, FRONT PILLAR GARNISH | ||||
| 62217-44010 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,右側 |
1 | ||
| 62411B - GARNISH, CENTER PILLAR, UPPER RH | ||||
| 62411-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62411-B1020B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62412B - GARNISH, CENTER PILLAR, UPPER LH | ||||
| 62412-B1020B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62412-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62413A - GARNISH, CENTER PILLAR, LOWER RH | ||||
| 62413-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 62413C - CLIP (FOR CENTER LOWER GARNISH) | ||||
| 67771-B2010 |
KGC1#,QNC10 |
4 | ||
| 62414A - GARNISH, CENTER PILLAR, LOWER LH | ||||
| 62414-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 62471A - GARNISH, ROOF SIDE, INNER RH | ||||
| 62471-B1050B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1020B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞ ﾄﾚｲ ﾄﾘﾑ & ﾄﾉｶﾊﾞｰ−有り,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1010B0 |
KGC1#,QNC10 LT.GRAY |
1 | ||
| 62471-B1010B0 |
KGC1#,QNC10 LT.GRAY |
1 | ||
| 62471-B1050B0 |
KGC1#,QNC10 D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1060B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞ ﾄﾚｲ ﾄﾘﾑ & ﾄﾉｶﾊﾞｰ−有り&SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1020B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞﾄﾚｲﾂｷ,LT.GRAY,TRIM1# |
1 | ||
| 62471-B1060B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞﾄﾚｲﾂｷ&D/P,ｻｲﾄﾞｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62471F - CLIP (FOR ROOF SIDE, INNER UPPER GARNISH) | ||||
| 67771-B2010 |
KGC1#,QNC10 左側 |
6 | ||
| 62472A - GARNISH, ROOF SIDE, INNER LH | ||||
| 62472-B1030B0 |
KGC1#,QNC10 SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1040B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞ ﾄﾚｲ ﾄﾘﾑ & ﾄﾉｶﾊﾞｰ−有り&SRS ｴｱﾊﾞｯｸﾞ−D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1020B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞﾄﾚｲｱﾘ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1040B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞﾄﾚｲｱﾘ & D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1020B0 |
KGC1#,QNC10 ﾊﾟｯｹｰｼﾞ ﾄﾚｲ ﾄﾘﾑ & ﾄﾉｶﾊﾞｰ−有り,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1030B0 |
KGC1#,QNC10 D/P,ｻｲﾄﾞ,ｴｱｶｰﾃﾝ,LT.GRAY,TRIM1# |
1 | ||
| 62472-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 62472-B1010B0 |
KGC1#,QNC10 LT.GRAY,TRIM1# |
1 | ||
| 67913 - PLATE, FRONT DOOR SCUFF, RH | ||||
| 67913-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 67914 - PLATE, FRONT DOOR SCUFF, LH | ||||
| 67914-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 67917A - PLATE, REAR DOOR SCUFF, RH | ||||
| 67917-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| 67918A - PLATE, REAR DOOR SCUFF, LH | ||||
| 67918-B1010B0 |
KGC1#,QNC10 DK.GRAY,TRIM1# |
1 | ||
| Common parts | ||||
| 67771-B2010 | ||||
| 90041-20070 | ||||
| 90467-10167 | ||||
| Linked diagrams | ||||
| 7104 | ||||
| 8401 | ||||
