Toyota Mark 2 MX63 REAR SEAT & SEAT TRACK

Manufacturers Home
Toyota
JP
MARK 2
MX63-XTPQE (1980)
7102 - REAR SEAT & SEAT TRACK

MX63-XTPQE (1980)

Toyota Mark 2

Production Sep 1980 - Aug 1982

Engine 5MEU

Transmission 4FC ATM

Displacement 2500cc

Power 168 HP (125 kW)

ILLUST NO. 1 OF 2(8009-8208)GR ; (8009-8208)GX60,LX60..HT,SED..GL,LE,LG ; (8009-8208)GX61,MX61,RX6#,

Click highlighted areas on diagram

Part #	Description	Period	Qty
71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE)
71075-9583005	GX61,MX61,63..HT..GD FB,GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
71075-9583004	GX61,MX61,63..HT..GD FB,BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
71075-9583003	GX61,MX61,63..HT..GD FB,GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
71077B - COVER, REAR SEAT BACK (FOR BENCH TYPE)
71077-9582503	GX61,MX61,63..HT..GD FB,GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
71077-9582505	GX61,MX61,63..HT..GD FB,GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
71077-9582504	GX61,MX61,63..HT..GD FB,BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE)
71460-9582204	GX61,MX61,63..HT..GD FB,BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
71460-9582205	GX61,MX61,63..HT..GD FB,GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
71460-9582203	GX61,MX61,63..HT..GD FB,GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
71460T - PAD SUB-ASSY, REAR SEAT CUSHION, NO.1
71611-95800	GX61,MX61,63..HT..GD..(EFI,TBO)	09/1980 - 07/1984	1
71460U - PAD SUB-ASSY, REAR SEAT CUSHION, NO.2
71621-22060	GX6#,MX61,63,RX6#,SX60,TX60..HT	09/1980 - 07/1984	1
71480B - BACK ASSY, REAR SEAT (FOR BENCH TYPE)
71480-9582505	GX61,MX61,63..HT..GD FB,GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
71480-9582503	GX61,MX61,63..HT..GD FB,GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
71480-9582504	GX61,MX61,63..HT..GD FB,BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
71480C - PAD SUB-ASSY, REAR SEAT BACK, NO.1 (FOR BENCH TYPE)
71651-95800	GX61,MX61,63..HT..GD..(EFI,TBO)	09/1980 - 07/1984	1
71650 - SPRING ASSY, REAR SEAT CUSHION
71650-22050	GX6#,MX61,63,RX6#,TX60..HT	09/1980 - 08/1982	1
71670 - SPRING ASSY, REAR SEAT BACK(FOR BENCH SEAT)
71670-95806	GX61,MX61,63..HT..GD	09/1980 - 07/1984	1
71671 - PAD, REAR SEAT BACK SILENCER, A
71671-22090	GX6#,MX61,63,RX60..HT..(GD,GR,LE,LG)	09/1980 - 08/1982	1
71812B - CLIP(FOR REAR SEAT CUSHION COVER)
90468-18071	GX6#,LX6#,MX6#,RX6#,SX60,TX6#	09/1980 - 07/1984	1
71812B - CLIP(FOR REAR SEAT CUSHION COVER)
90468-18071	GX6#,LX6#,MX6#,RX6#,SX60,TX6#	09/1980 - 07/1984	1
71893 - GARNISH, REAR SEAT BACK SIDE, LOWER RH
71893-22010	GX6#,MX61,63,RX6#,SX60,TX60..HT	09/1980 - 07/1984	2
72693 - HOOK, REAR SEAT CUSHION LOCK
72693-22010	GX6#,MX63,RX6#,TX60..HT	09/1980 - 08/1982	2
72693 - HOOK, REAR SEAT CUSHION LOCK
72693-22010	GX6#,MX63,RX6#,TX60..HT	09/1980 - 08/1982	2
72830 - ARMREST ASSY, REAR SEAT, CENTER
72830-2208003	GX61,MX61,63..GD GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
72830-2208005	GX61,MX61,63..GD GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
72830-2208004	GX61,MX61,63..GD BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
Common parts
90468-12070
91656-40630
91665-60825

ILLUST NO. 1 OF 2(8009- )GD

Click highlighted areas on diagram

Part #	Description	Period	Qty
71075B - COVER, REAR SEAT CUSHION (FOR BENCH TYPE)
71075-9583005	GX61,MX61,63..HT..GD FB,GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
71075-9583004	GX61,MX61,63..HT..GD FB,BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
71075-9583003	GX61,MX61,63..HT..GD FB,GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
71077B - COVER, REAR SEAT BACK (FOR BENCH TYPE)
71077-9582503	GX61,MX61,63..HT..GD FB,GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
71077-9582505	GX61,MX61,63..HT..GD FB,GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
71077-9582504	GX61,MX61,63..HT..GD FB,BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
71460B - CUSHION ASSY, REAR SEAT (FOR BENCH TYPE)
71460-9582204	GX61,MX61,63..HT..GD FB,BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
71460-9582205	GX61,MX61,63..HT..GD FB,GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
71460-9582203	GX61,MX61,63..HT..GD FB,GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
71460T - PAD SUB-ASSY, REAR SEAT CUSHION, NO.1
71611-95800	GX61,MX61,63..HT..GD..(EFI,TBO)	09/1980 - 07/1984	1
71460U - PAD SUB-ASSY, REAR SEAT CUSHION, NO.2
71621-22060	GX6#,MX61,63,RX6#,SX60,TX60..HT	09/1980 - 07/1984	1
71480B - BACK ASSY, REAR SEAT (FOR BENCH TYPE)
71480-9582505	GX61,MX61,63..HT..GD FB,GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
71480-9582503	GX61,MX61,63..HT..GD FB,GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
71480-9582504	GX61,MX61,63..HT..GD FB,BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
71480C - PAD SUB-ASSY, REAR SEAT BACK, NO.1 (FOR BENCH TYPE)
71651-95800	GX61,MX61,63..HT..GD..(EFI,TBO)	09/1980 - 07/1984	1
71650 - SPRING ASSY, REAR SEAT CUSHION
71650-22050	GX6#,MX61,63,RX6#,TX60..HT	09/1980 - 08/1982	1
71670 - SPRING ASSY, REAR SEAT BACK(FOR BENCH SEAT)
71670-95806	GX61,MX61,63..HT..GD	09/1980 - 07/1984	1
71671 - PAD, REAR SEAT BACK SILENCER, A
71671-22090	GX6#,MX61,63,RX60..HT..(GD,GR,LE,LG)	09/1980 - 08/1982	1
71736 - FASTENER SUB-ASSY, SEAT COVER, A (FOR REAR SEAT)
71703-2201003	GX61,MX61,63..GD GRAY,GRAY,TRIM2#	09/1980 - 08/1982	32
71703-2201005	GX61,MX61,63..GD GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	32
71703-2201004	GX61,MX61,63..GD BLUE,BLUE,TRIM8#	09/1980 - 08/1982	32
71736 - FASTENER SUB-ASSY, SEAT COVER, A (FOR REAR SEAT)
71703-2201003	GX61,MX61,63..GD GRAY,GRAY,TRIM2#	09/1980 - 08/1982	32
71703-2201005	GX61,MX61,63..GD GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	32
71703-2201004	GX61,MX61,63..GD BLUE,BLUE,TRIM8#	09/1980 - 08/1982	32
71737 - RETAINER, SEAT COVER FASTENER, B (FOR REAR SEAT)
71701-22070	GX61,MX61,63..GD..(EFI,TBO)	09/1980 - 07/1984	4
71737 - RETAINER, SEAT COVER FASTENER, B (FOR REAR SEAT)
71701-22070	GX61,MX61,63..GD..(EFI,TBO)	09/1980 - 07/1984	4
71812B - CLIP(FOR REAR SEAT CUSHION COVER)
90468-18071	GX6#,LX6#,MX6#,RX6#,SX60,TX6#	09/1980 - 07/1984	1
71812B - CLIP(FOR REAR SEAT CUSHION COVER)
90468-18071	GX6#,LX6#,MX6#,RX6#,SX60,TX6#	09/1980 - 07/1984	1
71893 - GARNISH, REAR SEAT BACK SIDE, LOWER RH
71893-22010	GX6#,MX61,63,RX6#,SX60,TX60..HT	09/1980 - 07/1984	2
71970 - HEADREST ASSY, REAR SEAT
71940-2205004	GX61,MX61,63..GD BLUE,BLUE,TRIM8#	09/1980 - 08/1982	2
71940-2205003	GX61,MX61,63..GD GRAY,GRAY,TRIM2#	09/1980 - 08/1982	2
71940-2205005	GX61,MX61,63..GD GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	2
71970 - HEADREST ASSY, REAR SEAT
71940-2205004	GX61,MX61,63..GD BLUE,BLUE,TRIM8#	09/1980 - 08/1982	2
71940-2205003	GX61,MX61,63..GD GRAY,GRAY,TRIM2#	09/1980 - 08/1982	2
71940-2205005	GX61,MX61,63..GD GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	2
72693 - HOOK, REAR SEAT CUSHION LOCK
72693-22010	GX6#,MX63,RX6#,TX60..HT	09/1980 - 08/1982	2
72693 - HOOK, REAR SEAT CUSHION LOCK
72693-22010	GX6#,MX63,RX6#,TX60..HT	09/1980 - 08/1982	2
72830 - ARMREST ASSY, REAR SEAT, CENTER
72830-2208003	GX61,MX61,63..GD GRAY,GRAY,TRIM2#	09/1980 - 08/1982	1
72830-2208005	GX61,MX61,63..GD GREIGE,BEIGE,TRIM4#	09/1980 - 08/1982	1
72830-2208004	GX61,MX61,63..GD BLUE,BLUE,TRIM8#	09/1980 - 08/1982	1
72830B - BUSH(FOR REAR SEAT CENTER ARMREST)
90386-06002	GX6#,MX61,63,RX60..HT..(GD,GR,LE,LG)	09/1980 - 08/1982	2
72830B - BUSH(FOR REAR SEAT CENTER ARMREST)
90386-06002	GX6#,MX61,63,RX60..HT..(GD,GR,LE,LG)	09/1980 - 08/1982	2
73183A - GUIDE, REAR SEAT LAP BELT, INNER
73183-20010	GX61,MX61,63..GD	09/1980 - 07/1984	2
Common parts
90179-06070
90468-12070
91656-40630
91665-60825
93385-16016

ILLUST NO. 2 OF 2(8009- )

Click highlighted areas on diagram

Part #	Description	Period	Qty	Price
Common parts
90580-20001
90580-20006
90580-20014
90580-20020
90580-20029
90580-20032
90580-20051
90580-20052
90580-20069
90580-20091
90580-20099
90580-20106
90580-20108
90580-20110
90580-20111
90580-20129
90580-20152
90580-20153
90580-20155

MX63-XTPQE (1980)

ILLUST NO. 1 OF 2(8009-8208)GR ; (8009-8208)GX60,LX60..HT,SED..GL,LE,LG ; (8009-8208)GX61,MX61,RX6#,

ILLUST NO. 1 OF 2(8009- )GD

ILLUST NO. 2 OF 2(8009- )
