GX71-XEMME (1984)

Toyota Mark 2

Production Aug 1984 - Aug 1988
Engine 1GEU
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8408- )

Click highlighted areas on diagram

diagram 64646A 74515 74519 74519 74519 74529 74531 74532 74541 74541B 74562 74563 74571 74571 74574 74578 74579
Part # Description Qty Price
64646A - PLATE, LUGGAGE LOCK CAUTION
64646-22010

GX71,LX70,MX71,SX70,YX70..GD,GL,GR,GT,LG,LS

 1
74519 - PLATE, FUEL CAUTION
74559-14010

GX7#,MX71,SX70,YX76

 1
74519 - PLATE, FUEL CAUTION
74559-14010

GX7#,MX71,SX70,YX76

 1
74519 - PLATE, FUEL CAUTION
74559-14010

GX7#,MX71,SX70,YX76

 1
74529 - PLATE, CHILD PROOF OR CHILD PROTECTOR LOCK CAUTION
69339-12010

GX7#,LX7#,MX71,SX70,YX7#

 2
74541 - PLATE, TIRE PRESSURE CAUTION
42661-22320

GX71,LX70,MX71,SX70..GD,GL,GR,LG,LS,STD

 1
42661-22321

GX7#,LX70,SX70..GD,GL,GR,LG,LS,STD

 1
42661-22430

GX71..LG,LS

 1
74541B - PLATE, COMPACT SPARE TIRE CAUTION
42668-40010

GX71,LX70,MX71,SX70,YX70

 1
74562 - PLATE, EMISSION CONTROL SYSTEM INFORMATION
74562-22340

GX7#..EFI

 1
74562-14380

GX7#..EFI

 1
74563 - PLATE, EMISSION CONTROL DEVICE IDENTIFICATION
74563-22140

GX71..EFI

 1
74571 - PLATE, BRAKE FLUID CAUTION
74571-27022

GX7#,LX7#,MX71,SX70,YX7#

 1
74571-27021

GX71,LX70,MX71,SX70,YX70

 1
47288-32010

GX7#,LX7#,SX70,YX7#

 1
74571 - PLATE, BRAKE FLUID CAUTION
74571-27022

GX7#,LX7#,MX71,SX70,YX7#

 1
74571-27021

GX71,LX70,MX71,SX70,YX70

 1
47288-32010

GX7#,LX7#,SX70,YX7#

 1
74579 - PLATE, UNLEADED FUEL CAUTION
74579-30011

GX7#,MX71,SX70,YX76

 1
