GX60-XTPFE (1980)

Toyota Mark 2

Production Sep 1980 - Aug 1982
Engine 1GEU
Transmission 4FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(8009- )

Click highlighted areas on diagram

diagram 1709 74519 74519 74519 74519 74526 74529 74541 74541B 74562 74563 74571 74578 74579
Part # Description Qty Price
74519 - PLATE, FUEL CAUTION
74559-14010

GX6#,MX61,63,RX6#,SX60,TX6#

 1
74519 - PLATE, FUEL CAUTION
74559-14010

GX6#,MX61,63,RX6#,SX60,TX6#

 1
74519 - PLATE, FUEL CAUTION
74559-14010

GX6#,MX61,63,RX6#,SX60,TX6#

 1
74519 - PLATE, FUEL CAUTION
74559-14010

GX6#,MX61,63,RX6#,SX60,TX6#

 1
74526 - PLATE, RECLINING ADJUSTER CAUTION
72547-20010

GX6#,LX6#,MX6#,RX6#,SX60,TX6#

 2
74529 - PLATE, CHILD PROOF OR CHILD PROTECTOR LOCK CAUTION
69339-20030

GX6#,LX6#,MX6#,RX6#,SX60,TX6#

 2
74562 - PLATE, EMISSION CONTROL SYSTEM INFORMATION
74562-22251

GX6#

 1
74562-22250

GX6#

 1
74571 - PLATE, BRAKE FLUID CAUTION
74571-27011

GX6#,LX6#,MX6#,RX6#,SX60,TX6#

 1
74579 - PLATE, UNLEADED FUEL CAUTION
74579-30011

GX6#,MX61,63,RX6#,SX60,TX6#

 1
Linked diagrams
1709
