KM31V-MNF (1985)
Toyota Liteace Van,Wagon
(8509- )DLX,SUC,SUP,SW,XL7
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45201A - BEARING(FOR STEERING MAIN SHAFT) | ||||
| 90363-28001 |
CM3#,4#,KM3#,YM30,40 LWR |
1 | ||
| 90363-18001 |
CM3#,4#,KM3#,YM30,40 UPR |
1 | ||
| 45201A - BEARING(FOR STEERING MAIN SHAFT) | ||||
| 90363-28001 |
CM3#,4#,KM3#,YM30,40 LWR |
1 | ||
| 90363-18001 |
CM3#,4#,KM3#,YM30,40 UPR |
1 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 |
CM3#,4#,KM3#,YM30,40 厚さ=1.20 |
1 | ||
| 45201G - SPRING, COMPRESSION(FOR STEERING MAIN SHAFT) | ||||
| 90501-45011 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45205 - TUBE SUB-ASSY, STEERING COLUMN | ||||
| 45205-27090 |
CM3#,4#,KM3#,YM40..DLX,SUC,SUP,SW,XL7 |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-22050 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45215 - COLLAR, MAIN SHAFT BEARING THRUST | ||||
| 45215-22011 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45220 - SHAFT ASSY, STEERING INTERMEDIATE | ||||
| 45220-27070 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45230 - COUPLING ASSY, FLEXIBLE | ||||
| 45230-27030 |
CM3#,KM30,31,36,YM30 W/POWER STEERING |
1 | ||
| 45230-27020 |
CM3#,KM3#..CBR,DSL |
1 | ||
| 45230-27020 |
CM3#,KM3#..DLX,SUP,SW,XL7 |
1 | ||
| 45275 - BRACKET, STEERING COLUMN, UPPER | ||||
| 45280-27100 |
CM35,36,KM30,31,36..(3FC,4F,4FC,5F)..(DLX,SUP,SW,XL7) |
1 | ||
| 45280-27100 |
CM35,36,KM30,31,36..3FC,4F,4FC,5F |
1 | ||
| 45280-27101 |
CM35,36,KM30,31,36..(3FC,4F,4FC,5F)..(DLX,SUP,SW,XL7) |
1 | ||
| 45281 - HOUSING, STEERING COLUMN | ||||
| 45287-2708004 |
CM35,36,KM30,31,36..3FC,4F,4FC,5F LWR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45287-2708006 |
CM35,36,41,KM31,36..3FC,4FC,5F LWR,BROWN,BROWN,TRIM4# |
1 | ||
| 45286-2714004 |
CM35,36,KM30,31,36..3FC,4F,4FC,5F UPR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45286-2714004 |
CM35,36,KM30,31,36..(3FC,4F,4FC,5F)..(DLX,SUP,SW,XL7) UPR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45286-2714006 |
CM35,36,41,KM31,36..3FC,4FC,5F UPR,BROWN,BROWN,TRIM4# |
1 | ||
| 45287-2708004 |
CM35,36,KM30,31,36..(3FC,4F,4FC,5F)..(DLX,SUP,SW,XL7) LWR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45286-2717004 |
CM35,36,KM30,31,36..(3FC,4F,4FC,5F)..(DLX,SUP,SW,XL7) UPR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45286-2717006 |
CM35,36,41,KM31,36..3FC,4FC,5F UPR,BROWN,BROWN,TRIM4# |
1 | ||
| 45281 - HOUSING, STEERING COLUMN | ||||
| 45287-2708004 |
CM35,36,KM30,31,36..3FC,4F,4FC,5F LWR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45287-2708006 |
CM35,36,41,KM31,36..3FC,4FC,5F LWR,BROWN,BROWN,TRIM4# |
1 | ||
| 45286-2714004 |
CM35,36,KM30,31,36..3FC,4F,4FC,5F UPR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45286-2714004 |
CM35,36,KM30,31,36..(3FC,4F,4FC,5F)..(DLX,SUP,SW,XL7) UPR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45286-2714006 |
CM35,36,41,KM31,36..3FC,4FC,5F UPR,BROWN,BROWN,TRIM4# |
1 | ||
| 45287-2708004 |
CM35,36,KM30,31,36..(3FC,4F,4FC,5F)..(DLX,SUP,SW,XL7) LWR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45286-2717004 |
CM35,36,KM30,31,36..(3FC,4F,4FC,5F)..(DLX,SUP,SW,XL7) UPR,BLUE,BLUE,TRIM4#,8# |
1 | ||
| 45286-2717006 |
CM35,36,41,KM31,36..3FC,4FC,5F UPR,BROWN,BROWN,TRIM4# |
1 | ||
| 45281E - PLATE, SAFETY CAUTION | ||||
| 45283-22010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45292 - SEAL, MAIN SHAFT LOWER DUST | ||||
| 45292-27010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45390 - SHAFT ASSY, STEERING TORQUE | ||||
| 45390-27010 |
CM3#,KM3#..CBR,DSL |
1 | ||
| 45390-27010 |
CM3#,KM3#..DLX,SUP,SW,XL7 |
1 | ||
| 45390-27020 |
CM3#,KM30,31,36,YM30 W/POWER STEERING |
1 | ||
| Common parts | ||||
| 90101-08070 | ||||
| 90119-08042 | ||||
| 90119-10415 | ||||
| 90164-50048 | ||||
| 90170-08194 | ||||
| 90201-11313 | ||||
| 91611-60618 | ||||
| 91661-60820 | ||||
| 91666-40620 | ||||
| 94110-40800 | ||||
| 94512-00800 | ||||
(8509- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45222E - COVER, DUST(FOR STEERING BEVEL GEAR) | ||||
| 45222-27030 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 45222E - COVER, DUST(FOR STEERING BEVEL GEAR) | ||||
| 45222-27030 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 45308D - SEAL, OIL(FOR STEERING BEVEL GEAR HOUSING) | ||||
| 90311-15001 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 45308D - SEAL, OIL(FOR STEERING BEVEL GEAR HOUSING) | ||||
| 90311-15001 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 45312A - BRACKET, STEERING BEVEL GEAR HOUSING | ||||
| 45312-27070 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45380 - GEAR ASSY, STEERING BEVEL | ||||
| 45380-27010 |
CM3#,KM3#,YM30 |
1 | ||
| 45380-27010 |
CM3#,KM3#..DLX,SUP,SW,XL7 W/POWER STEERING |
1 | ||
| 45380-28010 |
CM3#,KM3#..DLX,SUP,SW,XL7 |
1 | ||
| 45380A - WASHER(FOR STEERING BEVEL GEAR) | ||||
| 90209-18002 |
CM3#,4#,KM3#,YM30,40 厚さ=1.90,ﾏｰｸ 2,T=1.90 |
1 | ||
| 90209-18005 |
CM3#,4#,KM3#,YM30,40 厚さ=2.05,ﾏｰｸ 5,T=2.05 |
1 | ||
| 90209-18007 |
CM3#,4#,KM3#,YM30,40 厚さ=2.15,ﾏｰｸ 7,T=2.15 |
1 | ||
| 90209-18006 |
CM3#,4#,KM3#,YM30,40 厚さ=2.10,ﾏｰｸ 6,T=2.10 |
1 | ||
| 90209-18004 |
CM3#,4#,KM3#,YM30,40 厚さ=2.00,ﾏｰｸ 4,T=2.00 |
1 | ||
| 90209-18008 |
CM3#,4#,KM3#,YM30,40 厚さ=2.20,ﾏｰｸ 8,T=2.20 |
1 | ||
| 90209-18003 |
CM3#,4#,KM3#,YM30,40 厚さ=1.95,ﾏｰｸ 3,T=1.95 |
1 | ||
| 45383B - SPRING, COMPRESSION(FOR STEERING BEVEL GEAR) | ||||
| 90501-18063 |
CM3#,4#,KM3#,YM30,40 RR |
1 | ||
| 90501-20080 |
CM3#,4#,KM3#,YM30,40 FR |
1 | ||
| 45383B - SPRING, COMPRESSION(FOR STEERING BEVEL GEAR) | ||||
| 90501-18063 |
CM3#,4#,KM3#,YM30,40 RR |
1 | ||
| 90501-20080 |
CM3#,4#,KM3#,YM30,40 FR |
1 | ||
| 45383C - BEARING, RADIAL BALL(FOR STEERING BEVEL GEAR) | ||||
| 90363-15010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45384A - COVER, STEERING BEVEL GEAR | ||||
| 45384-27010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45385A - SEAT, LOCK BOLT(FOR STEERING BEVEL GEAR) | ||||
| 45385-27010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45385B - BOLT, SET(FOR LOCK BOLT SEAT) | ||||
| 90113-08006 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45388 - PLATE, STEERING BEVEL GEAR | ||||
| 45388-27010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45389 - HOLDER, STEERING BEVEL GEAR SPRING | ||||
| 45389-27021 |
CM3#,4#,KM3#,YM30,40 RR |
1 | ||
| 45389-27020 |
CM3#,4#,KM3#,YM30,40 RR |
1 | ||
| 45389-27010 |
CM3#,4#,KM3#,YM30,40 FR |
1 | ||
| 45389 - HOLDER, STEERING BEVEL GEAR SPRING | ||||
| 45389-27021 |
CM3#,4#,KM3#,YM30,40 RR |
1 | ||
| 45389-27020 |
CM3#,4#,KM3#,YM30,40 RR |
1 | ||
| 45389-27010 |
CM3#,4#,KM3#,YM30,40 FR |
1 | ||
| 45545B - SCREW, PINION BEARING ADJUSTING(FOR STEERING BEVEL GEAR | ||||
| 45545-27020 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45545-10010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45545C - NUT(FOR STEERING BEVEL GEAR PINION BEARING ADJUST SCREW | ||||
| 90179-38001 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| Common parts | ||||
| 90101-10150 | ||||
| 90119-06255 | ||||
| 90170-08021 | ||||
| 90364-18006 | ||||
| 90364-18007 | ||||
| 91611-61035 | ||||
| 91651-61030 | ||||
| 94512-01000 | ||||
(8708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45266 - COVER, STEERING INTERMEDIATE SHAFT DUST | ||||
| 45266-27020 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45266 - COVER, STEERING INTERMEDIATE SHAFT DUST | ||||
| 45266-27020 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45635A - SUPPORT, INTER LINK JOINT PROTECTOR | ||||
| 45635-27010 |
CM3#,KM3#,YM30 |
1 | ||
| 45635A - SUPPORT, INTER LINK JOINT PROTECTOR | ||||
| 45635-27010 |
CM3#,KM3#,YM30 |
1 | ||
| 45636 - PROTECTOR, INTERMEDIATE LINK JOINT, UPPER | ||||
| 45636-27010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45636 - PROTECTOR, INTERMEDIATE LINK JOINT, UPPER | ||||
| 45636-27010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45637 - PROTECTOR, INTER LINK JOINT, LWR NO.1 | ||||
| 45637-27010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 45637 - PROTECTOR, INTER LINK JOINT, LWR NO.1 | ||||
| 45637-27010 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| Common parts | ||||
| 90201-08300 | ||||
| 90468-12010 | ||||
| 91611-60816 | ||||
| 91651-40618 | ||||
| 91651-60820 | ||||
