CM36V-PDZ (1985)
Toyota Liteace Van,Wagon
(8509- )CM3#,KM3#,YM30
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 48107 - ARM SUB-ASSY, ANCHOR, RH | ||||
| 48107-27030 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 48108 - ARM SUB-ASSY, ANCHOR, LH | ||||
| 48108-27020 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 48161 - SPRING, TORSION BAR, RH | ||||
| 48161-27080 |
CM3#,KM3#,YM30 |
1 | ||
| 48161-27170 |
CM3#,KM3#,YM30 |
1 | ||
| 48162 - SPRING, TORSION BAR, LH | ||||
| 48162-27170 |
CM3#,KM3#,YM30 |
1 | ||
| 48162-27080 |
CM3#,KM3#,YM30 |
1 | ||
| 48169 - SWIVEL, ANCHOR ARM | ||||
| 48169-27020 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 48173 - SEAT, ANCHOR ARM ADJUSTER | ||||
| 48173-27010 |
CM3#,4#,KM3#,YM30,40 LH |
1 | ||
| 48173-27020 |
CM3#,4#,KM3#,YM30,40 RH |
1 | ||
| 48173A - BOLT, HEXAGON(FOR ANCHOR ARM ADJUSTING) | ||||
| 90101-12059 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 48173B - HOSE(FOR ANCHOR ARM ADJUSTING BOLT) | ||||
| 90446-14001 |
CM3#,4#,KM3#,YM30,40 |
1 | ||
| 48174 - COVER, TORSION BAR DUST | ||||
| 48175-27010 |
CM3#,4#,KM3#,YM30,40 RR |
2 | ||
| 48174-27010 |
CM3#,4#,KM3#,YM30,40 FR |
2 | ||
| 48174 - COVER, TORSION BAR DUST | ||||
| 48175-27010 |
CM3#,4#,KM3#,YM30,40 RR |
2 | ||
| 48174-27010 |
CM3#,4#,KM3#,YM30,40 FR |
2 | ||
| 48510 - ABSORBER ASSY, SHOCK, FRONT RH | ||||
| 48500-29345 |
CM3#,KM3#,YM30 |
1 | ||
| 48500-27060 |
CM3#,KM3#,YM30 |
1 | ||
| 48510 - ABSORBER ASSY, SHOCK, FRONT RH | ||||
| 48500-29345 |
CM3#,KM3#,YM30 |
1 | ||
| 48500-27060 |
CM3#,KM3#,YM30 |
1 | ||
| 48510B - RETAINER, CUSHION, NO.1(FOR FRONT SHOCK ABSORBER) | ||||
| 90948-02002 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 48510C - RETAINER, CUSHION, NO.2(FOR FRONT SHOCK ABSORBER) | ||||
| 90948-02017 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 48510J - CUSHION, FRONT SHOCK ABSORBER, NO.1 | ||||
| 90948-01003 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 48510P - CUSHION, FRONT SHOCK ABSORBER, NO.2 | ||||
| 90948-01029 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 48510Q - RETAINER, CUSHION, NO.3(FOR FRONT SHOCK ABSORBER) | ||||
| 90948-02076 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 48520 - ABSORBER ASSY, SHOCK, FRONT LH | ||||
| 48500-27060 |
CM3#,KM3#,YM30 |
1 | ||
| 48500-29345 |
CM3#,KM3#,YM30 |
1 | ||
| 48520 - ABSORBER ASSY, SHOCK, FRONT LH | ||||
| 48500-27060 |
CM3#,KM3#,YM30 |
1 | ||
| 48500-29345 |
CM3#,KM3#,YM30 |
1 | ||
| 48660 - BAR ASSY, STRUT, RH | ||||
| 48660-27020 |
CM3#,KM3#,YM30 |
1 | ||
| 48670 - BAR ASSY, STRUT, LH | ||||
| 48670-27020 |
CM3#,KM3#,YM30 |
1 | ||
| 48674 - CUSHION, STRUT BAR | ||||
| 48674-29026 |
CM3#,KM3#,YM30 |
4 | ||
| 48674A - RETAINER, CUSHION(FOR STRUT BAR CUSHION) | ||||
| 90948-02030 |
CM3#,KM3#,YM30 |
4 | ||
| 48674A - RETAINER, CUSHION(FOR STRUT BAR CUSHION) | ||||
| 90948-02030 |
CM3#,KM3#,YM30 |
4 | ||
| 48674B - COLLAR(FOR STRUT BAR CUSHION) | ||||
| 90387-18090 |
CM3#,KM3#,YM30 |
2 | ||
| 48811 - BAR, STABILIZER, FRONT | ||||
| 48811-27041 |
CM3#,KM3#,YM30 |
1 | ||
| 48811-27040 |
CM3#,KM3#,YM30 |
1 | ||
| 48815 - BUSH, FRONT STABILIZER BAR, NO.1 | ||||
| 48815-14020 |
CM3#,KM3#,YM30 |
2 | ||
| 48817 - CUSHION, FRONT STABILIZER | ||||
| 90948-01002 |
CM3#,4#,KM3#,YM30,40 |
8 | ||
| 48817 - CUSHION, FRONT STABILIZER | ||||
| 90948-01002 |
CM3#,4#,KM3#,YM30,40 |
8 | ||
| 48817 - CUSHION, FRONT STABILIZER | ||||
| 90948-01002 |
CM3#,4#,KM3#,YM30,40 |
8 | ||
| 48817 - CUSHION, FRONT STABILIZER | ||||
| 90948-01002 |
CM3#,4#,KM3#,YM30,40 |
8 | ||
| 48817A - RETAINER, CUSHION, NO.1(FOR FRONT STABILIZER BAR) | ||||
| 90948-02004 |
CM3#,4#,KM3#,YM30,40 |
8 | ||
| 48817A - RETAINER, CUSHION, NO.1(FOR FRONT STABILIZER BAR) | ||||
| 90948-02004 |
CM3#,4#,KM3#,YM30,40 |
8 | ||
| 48817A - RETAINER, CUSHION, NO.1(FOR FRONT STABILIZER BAR) | ||||
| 90948-02004 |
CM3#,4#,KM3#,YM30,40 |
8 | ||
| 48817A - RETAINER, CUSHION, NO.1(FOR FRONT STABILIZER BAR) | ||||
| 90948-02004 |
CM3#,4#,KM3#,YM30,40 |
8 | ||
| 48817B - RETAINER, CUSHION, NO.2(FOR FRONT STABILIZER BAR) | ||||
| 90948-02005 |
CM3#,4#,KM3#,YM30,40 |
2 | ||
| 48817C - COLLAR(FOR STABILIZER BAR) | ||||
| 90440-14004 |
CM3#,KM3#,YM30 |
2 | ||
| 48817D - BOLT(FOR FRONT STABILIZER) | ||||
| 90101-10090 |
CM3#,KM3#,YM30 |
2 | ||
| 48817D - BOLT(FOR FRONT STABILIZER) | ||||
| 90101-10090 |
CM3#,KM3#,YM30 |
2 | ||
| 48824 - BRACKET, STABILIZER, FRONT | ||||
| 48824-12040 |
CM3#,KM3#,YM30 |
2 | ||
| 48827 - BRACKET, FRONT STABILIZER, NO.2 RH | ||||
| 48824-27030 |
CM3#,KM3#,YM30 |
1 | ||
| 48828 - BRACKET, FRONT STABILIZER, NO.2 LH | ||||
| 48829-27030 |
CM3#,KM3#,YM30 |
1 | ||
| Common parts | ||||
| 90105-10057 | ||||
| 90170-12004 | ||||
| 90170-18154 | ||||
| 90179-08146 | ||||
| 90179-10058 | ||||
| 90206-18001 | ||||
| 91651-60820 | ||||
| 94110-41000 | ||||
| 94120-41000 | ||||
| 94182-11000 | ||||
