CM30G-MD (1985)
Toyota Liteace Van,Wagon
(8509- )CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,SUC,XL7
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 62610 - SASH ASSY, SIDE WINDOW OUTER, NO.1 (FOR SLIDE TYPE) | ||||
| 62707-95702 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,SUC,XL7 RH |
1 | ||
| 67044-95701 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SUC,XL7 LH |
1 | ||
| 62611 - SPACER, SIDE WINDOW SUPPORT, NO.1 | ||||
| 62279-95701 |
CM30,40,KM30,YM30,40 |
8 | ||
| 62651 - GLASS, SIDE WINDOW, NO.1, FRONT (FOR SLIDE TYPE) | ||||
| 62711-95703 |
CM30,KM30..DLX,SW *TEM,厚さ=4.0,RH,*TEM,T=4.0 |
1 | ||
| 62711-95703 |
CM30,40,KM30,YM40..DLX,SW *TEM,厚さ=4.0,RH,*TEM,T=4.0 |
1 | ||
| 62733-95706 |
CM30,40,KM30,YM40..DLX,SW *TEM,厚さ=4.0,LH,*TEM,T=4.0 |
1 | ||
| 62651A - GLASS, SIDE WINDOW, NO.1, REAR (FOR SLIDE TYPE) | ||||
| 62713-95712 |
CM30,KM30..DLX *TEM,厚さ=4.0,RH,*TEM,T=4.0 |
1 | ||
| 62736-95703 |
CM30,KM30..DLX,SW *TEM,厚さ=4.0,LH,*TEM,T=4.0 |
1 | ||
| 62691 - LOCK, SIDE WINDOW, NO.1 GLASS (FOR SLIDE TYPE) | ||||
| 62910-95702 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,SUC,XL7 |
4 | ||
| 62691A - PACKING, SIDE WINDOW LOCK, NO.1 | ||||
| 62792-95A00 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,SUC,XL7 |
4 | ||
| 62691B - RETAINER, SIDE WINDOW LOCK, NO.1 | ||||
| 62793-95704 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,SUC,XL7 |
4 | ||
| 62712H - GLASS, SIDE WINDOW, NO.2(FOR HINGE TYPE) | ||||
| 62715-95703 |
CM30,KM30..DLX *TEM,厚さ=4.0,RH,*TEM,T=4.0 |
1 | ||
| 62715A - GLASS, SIDE WINDOW, NO.2(FOR FIXED TYPE) | ||||
| 62716-95700 |
CM30,40,KM30,YM40..DLX,SW *TEM,厚さ=3.5,LH,*TEM,T=3.5 |
1 | ||
| 62731 - PLATE, QUARTER OR SIDE WINDOW HINGE | ||||
| 62734-95705 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,XL7 |
2 | ||
| 62733 - RETAINER, QUARTER OR SIDE WINDOW HINGE | ||||
| 63273-95701 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,XL7 |
3 | ||
| 62733 - RETAINER, QUARTER OR SIDE WINDOW HINGE | ||||
| 63273-95701 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,XL7 |
3 | ||
| 62749A - SEAL, SIDE WINDOW, UPPER | ||||
| 62749-95701 |
CM30,40,KM30,YM30,40 RH |
1 | ||
| 62749-95702 |
CM30,40,KM30,YM30,40 LH |
1 | ||
| 62749B - SEAL, SIDE WINDOW FRAME | ||||
| 62749-95704 |
CM30,40,KM30,YM30,40 |
2 | ||
| 62750A - WEATHERSTRIP, SIDE WINDOW, NO.2(FOR HINGE TYPE) | ||||
| 62743-95704 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,XL7 RH |
1 | ||
| 62743-95705 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,XL7 COLD SPEC,RH |
1 | ||
| 62755A - WEATHERSTRIP, SIDE WINDOW, NO.2(FOR FIXED TYPE) | ||||
| 62743-95702 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,XL7 |
1 | ||
| 62779 - PACKING, SIDE WINDOW GLASS, NO.1 | ||||
| 62719-95701 |
CM30,40,KM30,YM30,40 |
6 | ||
| 62783A - SASH, SIDE WINDOW, CENTER | ||||
| 62783-95700 |
CM30,40,KM30,YM30,40 |
2 | ||
| 62910 - LOCK ASSY, QUARTER OR SIDE WINDOW, RH | ||||
| 62950-9570001 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,XL7 BLACK,BLACK |
1 | ||
| 62950-9570301 |
CM30,40,KM30,YM30,40..DLX,FXV,GXL,SCA,XL7 BLACK,BLACK |
1 | ||
| Common parts | ||||
| 90149-60004 | ||||
| 90159-60010 | ||||
| 90159-60120 | ||||
| 90164-40050 | ||||
| 90202-11001 | ||||
| 90385-11005 | ||||
