YM60-TBJDS3 (1986)
Toyota Lite/Townace Truck
(8610-9008)5F,5H ; (9008-9906)MTM
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33027A - PIN, SLOTTED SPRING(FOR SHIFT LEVER SHAFT SET) | ||||
| 90254-05001 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33203B - SEAL, OIL(FOR SHIFT LEVER SHAFT) | ||||
| 90311-18002 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33205 - SHAFT SUB-ASSY, SELECT LEVER | ||||
| 33262-28020 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33205A - SEAL, OIL(FOR SHIFT LEVER NO.2 SHAFT) | ||||
| 90313-13001 |
CM5#,6#,KM5#,YM55,6#..MTM |
1 | ||
| 33205D - WASHER(FOR OUTER LEVER OIL SETTING) | ||||
| 94612-11300 |
CM5#,6#,KM5#,YM55,6#..MTM |
1 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
CM50,55,6#,KM5#,YM55,60..MTM |
4 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
CM50,55,6#,KM5#,YM55,60..MTM |
4 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
CM50,55,6#,KM5#,YM55,60..MTM |
4 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
CM50,55,6#,KM5#,YM55,60..MTM |
4 | ||
| 33213B - BOLT(FOR SHIFT FORK SET) | ||||
| 90105-06052 |
YM60;CM50,55,6#,KM51..5F,5H |
1 | ||
| 33213B - BOLT(FOR SHIFT FORK SET) | ||||
| 90105-06052 |
YM60;CM50,55,6#,KM51..5F,5H |
1 | ||
| 33215 - FORK, 3RD & 4TH SHIFT | ||||
| 33213-28011 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33221 - ARM, REVERSE SHIFT | ||||
| 33221-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33221B - RING, E(FOR REVERSE SHIFT ARM) | ||||
| 96160-01000 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33225 - SHOE, SHIFT ARM | ||||
| 33225-35030 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33225A - RING, SHAFT SNAP(FOR SHIFT ARM SHOE) | ||||
| 96160-00800 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33228 - BRACKET, REVERSE SHIFT ARM | ||||
| 33228-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33228B - PIN, RING(FOR REVERSE SHIFT ARM BRACKET) | ||||
| 90253-11001 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
2 | ||
| 33231 - HEAD, REVERSE SHIFT | ||||
| 33231-26020 |
YM60..DX |
1 | ||
| 33232 - HEAD, 1ST & 2ND SHIFT | ||||
| 33232-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33241 - SHAFT, REVERSE SHIFT FORK | ||||
| 33244-26010 |
YM60..DX |
1 | ||
| 33244-26011 |
YM60..DX |
1 | ||
| 33243 - SHAFT, 1ST & 2ND SHIFT FORK | ||||
| 33242-26020 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33245 - SHAFT, 3RD & 4TH SHIFT FORK | ||||
| 33243-35050 |
YM60;CM50,55,6#,KM51..5F,5H |
1 | ||
| 33251 - LEVER, SHIFT & SELECT | ||||
| 33251-26040 |
YM60..DX |
1 | ||
| 33253 - LEVER, SHIFT OUTER, NO.1 | ||||
| 33253-27081 |
YM60..DX;CM5#,6#,KM51,YM55,65..5H |
1 | ||
| 33253A - PIN, LEVER LOCK (FOR SHIFT OUTER LEVER) | ||||
| 33281-16020 |
CM5#,6#,KM5#,YM55,6#..MTM |
1 | ||
| 33257 - LEVER, SELECT OUTER | ||||
| 33257-27110 |
YM60..DX;CM5#,6#,KM51,YM55,65..5H |
1 | ||
| 33261C - SHAFT, SHIFT & SELECT LEVER | ||||
| 33261-28011 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 90361-10002 |
CM50,55,6#,YM60..MTM 長さ=21.6,PIN,PIN |
1 | ||
| 90361-10003 |
CM50,55,6#,YM60..MTM 長さ=13.6,外径=9.5,PIN |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 90361-10002 |
CM50,55,6#,YM60..MTM 長さ=21.6,PIN,PIN |
1 | ||
| 90361-10003 |
CM50,55,6#,YM60..MTM 長さ=13.6,外径=9.5,PIN |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 90361-10002 |
CM50,55,6#,YM60..MTM 長さ=21.6,PIN,PIN |
1 | ||
| 90361-10003 |
CM50,55,6#,YM60..MTM 長さ=13.6,外径=9.5,PIN |
1 | ||
| 33265 - PIN, SHIFT INTER LOCK, NO.2 | ||||
| 90250-05020 |
YM60..DX 長さ=11.1,外径=4.8 |
1 | ||
| 90250-05020 |
YM60;CM50,55,6#,KM51..5F,5H 長さ=11.1,外径=4.8 |
2 | ||
| 33265 - PIN, SHIFT INTER LOCK, NO.2 | ||||
| 90250-05020 |
YM60..DX 長さ=11.1,外径=4.8 |
1 | ||
| 90250-05020 |
YM60;CM50,55,6#,KM51..5F,5H 長さ=11.1,外径=4.8 |
2 | ||
| 33272 - GASKET, SHIFT LEVER SHAFT HOUSING | ||||
| 33272-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12014 |
YM60;KM51..5F 外径=17 |
4 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12014 |
YM60;KM51..5F 外径=17 |
4 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12014 |
YM60;KM51..5F 外径=17 |
4 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12014 |
YM60;KM51..5F 外径=17 |
4 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YM60;CM5#,6#,KM51..5F,5H 長さ=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YM60;CM5#,6#,KM51..5F,5H 長さ=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YM60;CM5#,6#,KM51..5F,5H 長さ=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YM60;CM5#,6#,KM51..5F,5H 長さ=30.6 |
3 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
KM5#,YM55,60..4H |
3 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
KM5#,YM55,60..4H |
3 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
KM5#,YM55,60..4H |
3 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
KM5#,YM55,60..4H |
3 | ||
| 33282 - PIN, LEVER LOCK, NO.2 | ||||
| 33282-35010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33555D - BOOT, SHIFT LEVER | ||||
| 33555-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| Common parts | ||||
| 90119-08333 | ||||
| 91611-60850 | ||||
| 94130-60600 | ||||
| 94130-60800 | ||||
| 94512-00800 | ||||
| 94531-00600 | ||||
(8610-9008)YM60..DX
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33027A - PIN, SLOTTED SPRING(FOR SHIFT LEVER SHAFT SET) | ||||
| 90254-05001 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33203B - SEAL, OIL(FOR SHIFT LEVER SHAFT) | ||||
| 90311-18002 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33205 - SHAFT SUB-ASSY, SELECT LEVER | ||||
| 33262-28020 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33205A - SEAL, OIL(FOR SHIFT LEVER NO.2 SHAFT) | ||||
| 90313-13001 |
CM5#,6#,KM5#,YM55,6#..MTM |
1 | ||
| 33205D - WASHER(FOR OUTER LEVER OIL SETTING) | ||||
| 94612-11300 |
CM5#,6#,KM5#,YM55,6#..MTM |
1 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
CM50,55,6#,KM5#,YM55,60..MTM |
4 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
CM50,55,6#,KM5#,YM55,60..MTM |
4 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
CM50,55,6#,KM5#,YM55,60..MTM |
4 | ||
| 33213A - PIN, SLOTTED SPRING(FOR SHIFT FORK SET) | ||||
| 90254-05001 |
CM50,55,6#,KM5#,YM55,60..MTM |
4 | ||
| 33213B - BOLT(FOR SHIFT FORK SET) | ||||
| 90105-06052 |
YM60;CM50,55,6#,KM51..5F,5H |
1 | ||
| 33215 - FORK, 3RD & 4TH SHIFT | ||||
| 33213-28011 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33221 - ARM, REVERSE SHIFT | ||||
| 33221-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33221B - RING, E(FOR REVERSE SHIFT ARM) | ||||
| 96160-01000 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33225 - SHOE, SHIFT ARM | ||||
| 33225-35030 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33225A - RING, SHAFT SNAP(FOR SHIFT ARM SHOE) | ||||
| 96160-00800 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33228 - BRACKET, REVERSE SHIFT ARM | ||||
| 33228-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33228B - PIN, RING(FOR REVERSE SHIFT ARM BRACKET) | ||||
| 90253-11001 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
2 | ||
| 33231 - HEAD, REVERSE SHIFT | ||||
| 33231-26020 |
YM60..DX |
1 | ||
| 33232 - HEAD, 1ST & 2ND SHIFT | ||||
| 33232-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33241 - SHAFT, REVERSE SHIFT FORK | ||||
| 33244-26010 |
YM60..DX |
1 | ||
| 33244-26011 |
YM60..DX |
1 | ||
| 33243 - SHAFT, 1ST & 2ND SHIFT FORK | ||||
| 33242-26020 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33245 - SHAFT, 3RD & 4TH SHIFT FORK | ||||
| 33243-35050 |
YM60;CM50,55,6#,KM51..5F,5H |
1 | ||
| 33251 - LEVER, SHIFT & SELECT | ||||
| 33251-26040 |
YM60..DX |
1 | ||
| 33253 - LEVER, SHIFT OUTER, NO.1 | ||||
| 33253-27081 |
YM60..DX;CM5#,6#,KM51,YM55,65..5H |
1 | ||
| 33253A - PIN, LEVER LOCK (FOR SHIFT OUTER LEVER) | ||||
| 33281-16020 |
CM5#,6#,KM5#,YM55,6#..MTM |
1 | ||
| 33257 - LEVER, SELECT OUTER | ||||
| 33257-27110 |
YM60..DX;CM5#,6#,KM51,YM55,65..5H |
1 | ||
| 33261C - SHAFT, SHIFT & SELECT LEVER | ||||
| 33261-28011 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 90361-10002 |
CM50,55,6#,YM60..MTM 長さ=21.6,PIN,PIN |
1 | ||
| 90361-10003 |
CM50,55,6#,YM60..MTM 長さ=13.6,外径=9.5,PIN |
1 | ||
| 33264 - PIN, OR BALL, SHIFT INTER LOCK, NO.1 | ||||
| 90361-10002 |
CM50,55,6#,YM60..MTM 長さ=21.6,PIN,PIN |
1 | ||
| 90361-10003 |
CM50,55,6#,YM60..MTM 長さ=13.6,外径=9.5,PIN |
1 | ||
| 33265 - PIN, SHIFT INTER LOCK, NO.2 | ||||
| 90250-05020 |
YM60..DX 長さ=11.1,外径=4.8 |
1 | ||
| 90250-05020 |
YM60;CM50,55,6#,KM51..5F,5H 長さ=11.1,外径=4.8 |
2 | ||
| 33272 - GASKET, SHIFT LEVER SHAFT HOUSING | ||||
| 33272-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12014 |
YM60;KM51..5F 外径=17 |
4 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12014 |
YM60;KM51..5F 外径=17 |
4 | ||
| 33275 - SEAT, SHIFT DETENT BALL SPRING, NO.1 | ||||
| 90341-12014 |
YM60;KM51..5F 外径=17 |
4 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YM60;CM5#,6#,KM51..5F,5H 長さ=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YM60;CM5#,6#,KM51..5F,5H 長さ=30.6 |
3 | ||
| 33275A - SPRING, COMPRESSION (FOR SHIFT DETENT BALL LOW SIDE) | ||||
| 90501-14062 |
YM60;CM5#,6#,KM51..5F,5H 長さ=30.6 |
3 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
KM5#,YM55,60..4H |
3 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
KM5#,YM55,60..4H |
3 | ||
| 33275B - BALL, SHAFT DETENT | ||||
| 90360-10003 |
KM5#,YM55,60..4H |
3 | ||
| 33282 - PIN, LEVER LOCK, NO.2 | ||||
| 33282-35010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| 33555D - BOOT, SHIFT LEVER | ||||
| 33555-28010 |
YM60;CM5#,6#,KM51,YM55,65..5F,5H |
1 | ||
| Common parts | ||||
| 90119-08333 | ||||
| 91611-60850 | ||||
| 94110-40600 | ||||
| 94110-40800 | ||||
| 94512-00600 | ||||
| 94512-00800 | ||||
