YM21G-HX (1982)

Toyota Lite/Townace Truck

Production Oct 1982 - Aug 1985
Engine 2YU
Transmission 3FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(7910-8508)WG

Click highlighted areas on diagram

diagram 74517 74518 74519 74519 74541 74551A 74551A 74562 74563 74566A 74571 74579 74598
Part # Description Qty Price
74519 - PLATE, FUEL CAUTION
74559-14010

KM2#,TM20,YM2#

 1
74519 - PLATE, FUEL CAUTION
74559-14010

KM2#,TM20,YM2#

 1
74541 - PLATE, TIRE PRESSURE CAUTION
74552-27133

CM20,YM21..07S,08S,09S

 1
74562 - PLATE, EMISSION CONTROL SYSTEM INFORMATION
74562-27040

YM21

 1
74562-27041

YM21

 1
74563 - PLATE, EMISSION CONTROL DEVICE IDENTIFICATION
74563-27030

YM21

 1
74571 - PLATE, BRAKE FLUID CAUTION
74571-27020

CM2#,KM21,YM2#

 1
74571-27021

CM2#,KM21,YM2#

 1
74579 - PLATE, UNLEADED FUEL CAUTION
74579-30011

TM20,YM21

 1
