CM65-TBQDS (1986)
Toyota Lite/Townace Truck
(9902- )CM51,55,60,65,KM51,YM55,6#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04495 - SHOE KIT, REAR BRAKE | ||||
| 04495-28061 |
CM60,65,YM6# |
1 | ||
| 04497-28041 |
CM60,65,YM6# ﾘﾋﾞﾙﾄ |
1 | ||
| 04497-28040 |
CM6#,YM60 ﾘﾋﾞﾙﾄ |
1 | ||
| 04495-28041 |
CM6#,YM60 |
1 | ||
| 04495-28040 |
CM6#,YM60 |
1 | ||
| 04906 - CUP KIT, REAR WHEEL CYLINDER | ||||
| 04906-30080 |
CM52,6#,YM6# |
1 | ||
| 47043 - PLATE SUB-ASSY, BRAKE BACKING, REAR RH | ||||
| 47043-28050 |
CM60,65,YM6# |
1 | ||
| 47043D - BOLT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 42184-30021 |
CM60,65,YM6# |
8 | ||
| 47043F - NUT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 90179-10030 |
CM60,65,YM6# |
8 | ||
| 47044 - PLATE SUB-ASSY, BRAKE BACKING, REAR LH | ||||
| 47044-28050 |
CM60,65,YM6# |
1 | ||
| 47430C - SPRING(FOR REAR BRAKE SHOE HOLD DOWN) | ||||
| 90501-20756 |
CM60,65,YM6# |
4 | ||
| 47430D - SPRING, TENSION(FOR REAR BRAKE SHOE RETURN) | ||||
| 90506-23003 |
CM60,65,YM6# |
2 | ||
| 47430E - SPRING, TENSION(FOR REAR BRAKE SHOE RETURN) | ||||
| 90506-23030 |
CM60,65,YM6# |
2 | ||
| 47430G - SPRING, TENSION(FOR REAR BRAKE AUTOMATIC ADJUST LEVER) | ||||
| 90506-12480 |
CM60,65,YM6# |
2 | ||
| 47457 - PIN, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47447-30020 |
CM60,65,YM6# |
4 | ||
| 47459 - CUP, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47449-30020 |
CM5#,6#,KM5#,YM55,6# |
8 | ||
| 47459 - CUP, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47449-30020 |
CM5#,6#,KM5#,YM55,6# |
8 | ||
| 47460 - ADJUSTER ASSY, SHOE, RH(FOR REAR BRAKE) | ||||
| 47062-30040 |
CM60,65,YM6# |
1 | ||
| 47062-30020 |
CM6#,YM60 |
1 | ||
| 47470 - ADJUSTER ASSY, SHOE, LH(FOR REAR BRAKE) | ||||
| 47061-30020 |
CM6#,YM60 |
1 | ||
| 47061-30040 |
CM60,65,YM6# |
1 | ||
| 47496 - PLUG, HOLE(FOR REAR BRAKE) | ||||
| 47491-20011 |
CM5#,6#,KM5#,YM55,6# |
2 | ||
| 47497 - PLUG, HOLE NO.2(FOR REAR BRAKE) | ||||
| 47492-28010 |
CM5#,6#,KM5#,YM55,6# |
2 | ||
| 47547R - PLUG, BLEEDER(FOR DRUM BRAKE, REAR) | ||||
| 47547-20030 |
CM60,65,YM6# |
2 | ||
| 47548R - CAP, BLEEDER PLUG(FOR DRUM BRAKE, REAR) | ||||
| 31478-30010 |
CM5#,6#,KM5#,YM55,6# |
2 | ||
| 47550 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR RH, FRONT OR UPPER) | ||||
| 47550-30120 |
CM60,65,YM6# |
1 | ||
| 47550C - SPRING, COMPRESSION(FOR REAR WHEEL BRAKE CYLINDER) | ||||
| 47509-22010 |
CM52,6#,YM6# |
2 | ||
| 47570 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR LH, FRONT OR UPPER) | ||||
| 47550-30120 |
CM60,65,YM6# |
1 | ||
| 47601 - LEVER SUB-ASSY, PARKING BRAKE SHOE, RH(FOR REAR BRAKE) | ||||
| 47601-28010 |
CM60,65,YM6# |
1 | ||
| 47601B - SHIM, REAR PARKING BRAKE SHOE LEVER | ||||
| 90564-09003 |
CM60,65,YM6# 厚さ=0.5 |
1 | ||
| 90564-09185 |
CM60,65,YM6# 厚さ=0.6 |
1 | ||
| 90564-09001 |
CM60,65,YM6# 厚さ=0.2 |
1 | ||
| 90564-09184 |
CM60,65,YM6# 厚さ=0.3 |
1 | ||
| 90564-09002 |
CM60,65,YM6# 厚さ=0.4 |
1 | ||
| 90564-09186 |
CM60,65,YM6# 厚さ=0.9 |
1 | ||
| 47601C - WASHER, C(FOR REAR BRAKE) | ||||
| 90213-06013 |
CM60,65,YM6# 厚さ=1.2 |
1 | ||
| 90213-07010 |
CM52,6#,YM6# 厚さ=1.6 |
1 | ||
| 47602 - LEVER SUB-ASSY, PARKING BRAKE SHOE, LH (FOR REAR BRAKE) | ||||
| 47602-28010 |
CM60,65,YM6# |
1 | ||
| 47663 - LEVER, AUTOMATIC ADJUST, RH(FOR REAR BRAKE) | ||||
| 47644-30010 |
CM60,65,YM6# |
1 | ||
| 47664 - LEVER, AUTOMATIC ADJUST, LH(FOR REAR BRAKE) | ||||
| 47643-30010 |
CM60,65,YM6# |
1 | ||
| Common parts | ||||
| 90119-06084 | ||||
(8610-9902)CM5#,60,65,KM5#,YM55,6#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04495 - SHOE KIT, REAR BRAKE | ||||
| 04495-28061 |
CM60,65,YM6# |
1 | ||
| 04497-28041 |
CM60,65,YM6# ﾘﾋﾞﾙﾄ |
1 | ||
| 04497-28040 |
CM6#,YM60 ﾘﾋﾞﾙﾄ |
1 | ||
| 04495-28041 |
CM6#,YM60 |
1 | ||
| 04495-28040 |
CM6#,YM60 |
1 | ||
| 04906 - CUP KIT, REAR WHEEL CYLINDER | ||||
| 04906-30080 |
CM52,6#,YM6# |
1 | ||
| 47043 - PLATE SUB-ASSY, BRAKE BACKING, REAR RH | ||||
| 47043-28050 |
CM60,65,YM6# |
1 | ||
| 47043D - BOLT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 42184-30021 |
CM60,65,YM6# |
8 | ||
| 47043F - NUT(FOR BACKING PLATE TO REAR AXLE HOUSING SETTING) | ||||
| 90179-10030 |
CM60,65,YM6# |
8 | ||
| 47044 - PLATE SUB-ASSY, BRAKE BACKING, REAR LH | ||||
| 47044-28050 |
CM60,65,YM6# |
1 | ||
| 47430C - SPRING(FOR REAR BRAKE SHOE HOLD DOWN) | ||||
| 90501-20756 |
CM60,65,YM6# |
4 | ||
| 47430D - SPRING, TENSION(FOR REAR BRAKE SHOE RETURN) | ||||
| 90506-23003 |
CM60,65,YM6# |
2 | ||
| 47430E - SPRING, TENSION(FOR REAR BRAKE SHOE RETURN) | ||||
| 90506-23030 |
CM60,65,YM6# |
2 | ||
| 47430G - SPRING, TENSION(FOR REAR BRAKE AUTOMATIC ADJUST LEVER) | ||||
| 90506-12480 |
CM60,65,YM6# |
2 | ||
| 47457 - PIN, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47447-30020 |
CM60,65,YM6# |
4 | ||
| 47459 - CUP, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47449-30020 |
CM5#,6#,KM5#,YM55,6# |
8 | ||
| 47459 - CUP, SHOE HOLD DOWN SPRING(FOR REAR BRAKE) | ||||
| 47449-30020 |
CM5#,6#,KM5#,YM55,6# |
8 | ||
| 47460 - ADJUSTER ASSY, SHOE, RH(FOR REAR BRAKE) | ||||
| 47062-30040 |
CM60,65,YM6# |
1 | ||
| 47062-30020 |
CM6#,YM60 |
1 | ||
| 47470 - ADJUSTER ASSY, SHOE, LH(FOR REAR BRAKE) | ||||
| 47061-30020 |
CM6#,YM60 |
1 | ||
| 47061-30040 |
CM60,65,YM6# |
1 | ||
| 47496 - PLUG, HOLE(FOR REAR BRAKE) | ||||
| 47491-20011 |
CM5#,6#,KM5#,YM55,6# |
2 | ||
| 47497 - PLUG, HOLE NO.2(FOR REAR BRAKE) | ||||
| 47492-28010 |
CM5#,6#,KM5#,YM55,6# |
2 | ||
| 47536 - PISTON, WHEEL BRAKE CYLINDER(FOR REAR BRAKE) | ||||
| 47051-22040 |
CM52,6#,YM6# |
4 | ||
| 47536 - PISTON, WHEEL BRAKE CYLINDER(FOR REAR BRAKE) | ||||
| 47051-22040 |
CM52,6#,YM6# |
4 | ||
| 47547R - PLUG, BLEEDER(FOR DRUM BRAKE, REAR) | ||||
| 47547-20030 |
CM60,65,YM6# |
2 | ||
| 47548R - CAP, BLEEDER PLUG(FOR DRUM BRAKE, REAR) | ||||
| 31478-30010 |
CM5#,6#,KM5#,YM55,6# |
2 | ||
| 47550 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR RH, FRONT OR UPPER) | ||||
| 47550-30120 |
CM60,65,YM6# |
1 | ||
| 47550C - SPRING, COMPRESSION(FOR REAR WHEEL BRAKE CYLINDER) | ||||
| 47509-22010 |
CM52,6#,YM6# |
2 | ||
| 47570 - CYLINDER ASSY, REAR WHEEL BRAKE(FOR LH, FRONT OR UPPER) | ||||
| 47550-30120 |
CM60,65,YM6# |
1 | ||
| 47601 - LEVER SUB-ASSY, PARKING BRAKE SHOE, RH(FOR REAR BRAKE) | ||||
| 47601-28010 |
CM60,65,YM6# |
1 | ||
| 47601B - SHIM, REAR PARKING BRAKE SHOE LEVER | ||||
| 90564-09003 |
CM60,65,YM6# 厚さ=0.5 |
1 | ||
| 90564-09185 |
CM60,65,YM6# 厚さ=0.6 |
1 | ||
| 90564-09001 |
CM60,65,YM6# 厚さ=0.2 |
1 | ||
| 90564-09184 |
CM60,65,YM6# 厚さ=0.3 |
1 | ||
| 90564-09002 |
CM60,65,YM6# 厚さ=0.4 |
1 | ||
| 90564-09186 |
CM60,65,YM6# 厚さ=0.9 |
1 | ||
| 47601C - WASHER, C(FOR REAR BRAKE) | ||||
| 90213-06013 |
CM60,65,YM6# 厚さ=1.2 |
1 | ||
| 90213-07010 |
CM52,6#,YM6# 厚さ=1.6 |
1 | ||
| 47601C - WASHER, C(FOR REAR BRAKE) | ||||
| 90213-06013 |
CM60,65,YM6# 厚さ=1.2 |
1 | ||
| 90213-07010 |
CM52,6#,YM6# 厚さ=1.6 |
1 | ||
| 47602 - LEVER SUB-ASSY, PARKING BRAKE SHOE, LH (FOR REAR BRAKE) | ||||
| 47602-28010 |
CM60,65,YM6# |
1 | ||
| 47663 - LEVER, AUTOMATIC ADJUST, RH(FOR REAR BRAKE) | ||||
| 47644-30010 |
CM60,65,YM6# |
1 | ||
| 47664 - LEVER, AUTOMATIC ADJUST, LH(FOR REAR BRAKE) | ||||
| 47643-30010 |
CM60,65,YM6# |
1 | ||
| Common parts | ||||
| 90119-06084 | ||||
