CM61-TBQDS (1991)
Toyota Lite/Townace Truck
(8610-9310)1C,2C..5H ; (9310- )2C
12V 1.4KW
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 28011 - CLUTCH SUB-ASSY, STARTER | ||||
| 28011-64020 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
1 | ||
| 28011-64130 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28011-64020 |
2C..CM65..TS;2C..CM5#,60,61..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28011-64020 |
2C..CM55..IV;2C..CM55..5H..CBU;2C..CM51,52,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28011-64130 |
2C..CM5#,6# |
1 | ||
| 28100 - STARTER ASSY | ||||
| 28100-64020 |
1C,2C..CM50,55,6#..5H 12V 2.0KW,ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 28100-64100 |
1C,2C..CM5#,6#..5H 12V 1.4KW |
1 | ||
| 28100-64290 |
2C..CM65..TS;2C..CM5#,60,61 12V 2.2KW,ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28100-64170 |
2C..CM65..TS;2C..CM5#,60,61 12V 1.4KW |
1 | ||
| 28100-64290 |
2C..CM5#,6# 12V 2.2KW,ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28100-64170 |
2C..CM5#,6# 12V 1.4KW |
1 | ||
| 28110 - HOUSING ASSY, STARTER DRIVE | ||||
| 28115-64020 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
1 | ||
| 28110-64170 |
2C..CM5#,6# |
1 | ||
| 28115-64290 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28110-64170 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28115-64290 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28119 - COVER, STARTER END FRAME | ||||
| 28119-54070 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 28199-74110 |
2C..CM5#,6# |
1 | ||
| 28199-77090 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28199-72020 |
2C..CM55..SJL..5H;1C,2C..CM50,6#..(JL,SJL,T1)..(GUT,TS) 12V 1.4KW |
1 | ||
| 28199-77090 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28199-74110 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28120 - YOKE ASSY, STARTER | ||||
| 28120-64020 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
1 | ||
| 28120-55050 |
2C..CM5#,6# |
1 | ||
| 28120-64130 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28120-64040 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28120-64130 |
2C..CM5#,6# |
1 | ||
| 28120-64040 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28130 - FRAME ASSY, STARTER COMMUTATOR END | ||||
| 28130-64100 |
2C..CM55..SJL..5H;1C,2C..CM50,6#..(JL,SJL,T1)..(GUT,TS) 12V 1.4KW |
1 | ||
| 28130-64170 |
2C..CM5#,6# 12V 1.4KW |
1 | ||
| 28130-64170 |
2C..CM65..TS;2C..CM5#,60,61 12V 1.4KW |
1 | ||
| 28139 - WIRE, LEAD, NO.1(FOR STARTER) | ||||
| 28139-64111 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28139-64010 |
2C..CM55..SJL..5H;1C,2C..CM50,6#..(JL,SJL,T1)..(GUT,TS) 12V 1.4KW;ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
1 | ||
| 28139-64111 |
2C..CM5#,6# |
1 | ||
| 28140 - HOLDER ASSY, STARTER BRUSH | ||||
| 28140-54070 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
1 | ||
| 28140-64040 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28140-64130 |
2C..CM5#,6# |
1 | ||
| 28140-64130 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28140-64040 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28143 - SPRING, STARTER BRUSH | ||||
| 90099-17115 |
2C..CM55..IV;2C..CM55..5H..CBU;2C..CM51,52,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
4 | ||
| 90099-17115 |
2C..CM65..TS;2C..CM5#,60,61..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
4 | ||
| 90099-17112 |
2C..CM65..TS;5K..KM51..3HC,5F;2C,2Y..CM5#,60,61,YM55,6# 12V 1.0KW |
4 | ||
| 90099-17115 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
4 | ||
| 90099-17112 |
5K..KM51..3HC,5F;2C,2Y..CM5#,6#,YM55,6# 12V 1.0KW |
4 | ||
| 28150 - SWITCH ASSY, MAGNET STARTER | ||||
| 28150-64020 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
1 | ||
| 28150-64130 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28150-64190 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28150-64190 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28150-64070 |
2C..CM55..SJL..5H;1C,2C..CM50,6#..(JL,SJL,T1)..(GUT,TS) 12V 1.4KW |
1 | ||
| 28150-64170 |
2C..CM5#,6# |
1 | ||
| 28150-64290 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28150-64130 |
2C..CM5#,6# |
1 | ||
| 28159B - COVER, MAGNET SWITCH | ||||
| 28159-10040 |
1C,2C,5K..CM50,55,6#,KM51..3HC,4H,5F,5H |
1 | ||
| 28159-10040 |
2C,5K,2Y..CM5#,6#,KM51,YM55,6# |
1 | ||
| 28159-64180 |
2C..CM5#,6# ｶﾝﾚｲﾁｼﾖｳ |
1 | ||
| 28159-64180 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁｼﾖｳ |
1 | ||
| 28160 - ARMATURE ASSY, STARTER | ||||
| 28160-54070 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
1 | ||
| 28160-15090 |
2C..CM6#..GUT,TS;1C,2C..CM50,55..5H 12V 1.4KW |
1 | ||
| 28160-64041 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28160-64041 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28160-74070 |
2C..CM5#,6# |
1 | ||
| 28160-74070 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28160A - BEARING, STARTER ARMATURE | ||||
| 28253-54070 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW,NO.1 |
1 | ||
| 90099-10131 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW,NO.2 |
1 | ||
| 90099-10197 |
2C..CM65..TS;2C..CM5#,60,61 NO.2 |
1 | ||
| 90099-10196 |
2C..CM65..TS;2C..CM5#,60,61 NO.1 |
1 | ||
| 28253-54070 |
2C..CM65..TS;2C..CM5#,60,61..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ,NO.1 |
1 | ||
| 90099-10197 |
2C..CM5#,6# NO.2 |
1 | ||
| 90099-10143 |
2C..CM60..TB;2C..CM55..SJLC;2C..CM51,52,61..5H ｶﾝﾚｲﾁ OR ﾕｷｸﾞﾆ ｼﾖｳ,NO.2 |
1 | ||
| 28253-54070 |
2C..CM55..IV;2C..CM55..5H..CBU;2C..CM51,52,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ,NO.1 |
1 | ||
| 90099-10196 |
2C..CM5#,6# NO.1 |
1 | ||
| 28160A - BEARING, STARTER ARMATURE | ||||
| 28253-54070 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW,NO.1 |
1 | ||
| 90099-10131 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW,NO.2 |
1 | ||
| 90099-10197 |
2C..CM65..TS;2C..CM5#,60,61 NO.2 |
1 | ||
| 90099-10196 |
2C..CM65..TS;2C..CM5#,60,61 NO.1 |
1 | ||
| 28253-54070 |
2C..CM65..TS;2C..CM5#,60,61..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ,NO.1 |
1 | ||
| 90099-10197 |
2C..CM5#,6# NO.2 |
1 | ||
| 90099-10143 |
2C..CM60..TB;2C..CM55..SJLC;2C..CM51,52,61..5H ｶﾝﾚｲﾁ OR ﾕｷｸﾞﾆ ｼﾖｳ,NO.2 |
1 | ||
| 28253-54070 |
2C..CM55..IV;2C..CM55..5H..CBU;2C..CM51,52,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ,NO.1 |
1 | ||
| 90099-10196 |
2C..CM5#,6# NO.1 |
1 | ||
| 28165 - SPRING, STARTER MAGNET SWITCH RETURN | ||||
| 28165-26040 |
1C,2C,5K,2Y..CM5#,6#,KM51,YM55,60 12V 1.0KW,1.4KW,2.0KW,2.2KW |
1 | ||
| 28165-26040 |
2C..CM60..TB;2C..CM55..SJLC;2C..CM55..4HC..CBU;2C,2Y..CM51,52,61,YM55,6# ｶﾝﾚｲﾁ OR ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28165-76070 |
2C..CM5#,6# |
1 | ||
| 28165-76070 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28169 - CLAMP, STARTER MOTOR LEAD WIRE | ||||
| 28169-10040 |
1C,2C,5K..CM50,55,6#,KM51..3HC,4H,5F,5H |
1 | ||
| 28175A - GASKET, MAGNET SWITCH COVER | ||||
| 28175-10040 |
2C..CM65..TS;2C,5K,2Y..CM5#,60,61,KM51,YM55,6# |
1 | ||
| 28175-10040 |
2C,5K,2Y..CM5#,6#,KM51,YM55,6# |
1 | ||
| 28175-10040 |
1C,2C,5K..CM50,55,6#,KM51..3HC,4H,5F,5H |
1 | ||
| 28226 - STARTER KIT, BATTERY TERMINAL | ||||
| 28226-54350 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 28226-64110 |
1C,2C..CM5#,6#..5H |
1 | ||
| 28226-54350 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 28226-54330 |
2C..CM5#,6# ｶﾝﾚｲﾁ OR ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28226-76100 |
2C..CM5#,6# ｶﾝﾚｲﾁ OR ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28226-16130 |
2C..CM5#,6# |
1 | ||
| 28226-16130 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28226A - STARTER KIT, MOTOR TERMINAL | ||||
| 28226-72010 |
2C,5K,2Y..CM5#,6#,KM51,YM55,6# ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 28226-74070 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28226-72010 |
1C,2C,5K,2Y..CM5#,6#,KM51,YM55,6#..3FC,3HC,4H,5F,5H |
1 | ||
| 28226-74070 |
2C..CM5#,6# |
1 | ||
| 28226-72010 |
2C..CM65..TS;2C,5K,2Y..CM5#,60,61,KM51,YM55,6# ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 28228 - ROLLER, STARTER IDLE GEAR CLUTCH | ||||
| 28228-26040 |
1C,2C,5K,2Y..CM5#,6#,KM51,YM55,60 12V 1.0KW,1.4KW,2.0KW,2.2KW |
5 | ||
| 28228-26040 |
2C,2Y..CM5#,6#,YM55,6# |
5 | ||
| 28228-26040 |
2C..CM65..TS;2C,2Y..CM5#,60,61,YM55,6# |
5 | ||
| 28229 - RETAINER, STARTER IDLE GEAR | ||||
| 28229-74070 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28229-26040 |
1C,2C,5K,2Y..CM5#,6#,KM51,YM55,60 12V 1.0KW,1.4KW,2.0KW |
1 | ||
| 28229-26040 |
2C..CM60..TB;2C..CM55..SJLC;2C..CM55..4HC..CBU;2C,2Y..CM51,52,61,YM55,6# ｶﾝﾚｲﾁ OR ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28229-74070 |
2C..CM5#,6# |
1 | ||
| 28235 - PLUNGER, MAGNET SWITCH | ||||
| 28235-35080 |
1C,2C,5K..CM5#,6#,KM51 |
1 | ||
| 28235-35080 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 28235-55050 |
2C..CM5#,6# |
1 | ||
| 28235-55050 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28235-35080 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28235-35080 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28251 - PINION, STARTER DRIVE | ||||
| 28251-54070 |
2C..CM55..IV;2C..CM55..5H..CBU;2C..CM51,52,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28251-54070 |
2C..CM65..TS;2C..CM5#,60,61..5H ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28251-54070 |
1C,2C..CM50,55,6#..5H ｶﾝﾚｲﾁ ｼﾖｳ;12V 2.0KW |
1 | ||
| 28252 - GEAR, STARTER IDLE | ||||
| 28254-64040 |
2C..CM65..TS;2C..CM5#,60,61 ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28254-64040 |
2C..CM5#,6# ｶﾝﾚｲﾁ ｼﾖｳ & ﾕｷｸﾞﾆ ｼﾖｳ |
1 | ||
| 28254-64130 |
2C..CM65..TS;2C..CM5#,60,61 |
1 | ||
| 28254-64130 |
2C..CM5#,6# |
1 | ||
| Common parts | ||||
| 28176-15090 | ||||
| 90099-00270 | ||||
| 90099-00907 | ||||
| 90099-04448 | ||||
| 90099-04449 | ||||
| 90099-04474 | ||||
| 90099-04974 | ||||
| 90099-05129 | ||||
| 90099-12009 | ||||
| 90099-14064 | ||||
| 90179-08146 | ||||
| 91611-61055 | ||||
| 94110-40800 | ||||
| 94511-00600 | ||||
| 94511-00800 | ||||
