CM50-TBQDS (1986)
Toyota Lite/Townace Truck
(8610- )CM50,51,55,KM5#,YM55
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04485 - SHAFT KIT, UPPER SUSPENSION ARM | ||||
| 04485-28020 |
CM50,51,55,KM5#,YM55 |
2 | ||
| 43211 - KNUCKLE, STEERING, RH | ||||
| 43211-28021 |
CM50,51,55,KM5#,YM55 |
1 | ||
| 43212 - KNUCKLE, STEERING, LH | ||||
| 43211-28021 |
YM55..MTM;CM55..CBU;CM50,51,KM5#;CM55..5H..IV |
1 | ||
| 43310 - JOINT ASSY, UPPER BALL | ||||
| 43350-29036 |
CM5#,KM5#,YM55 RH |
1 | ||
| 43360-29056 |
CM5#,KM5#,YM55 LH |
1 | ||
| 43310A - PLUG (FOR BALL JOINT) | ||||
| 90345-06014 |
CM5#,6#,KM5#,YM55,60 |
6 | ||
| 43330 - JOINT ASSY, LOWER BALL, FRONT | ||||
| 43330-29175 |
CM50,51,55,KM5#,YM55 |
2 | ||
| 43346 - PROTECTOR, LOWER BALL JOINT DUST COVER | ||||
| 43346-28011 |
CM5#,KM5#,YM55 COLD SPEC |
2 | ||
| 43355C - DEFLECTOR, LOWER ARM ICE, RH NO.1 | ||||
| 43355-27031 |
CM50,51,KM5#..JL,T1 |
1 | ||
| 43355-27031 |
CM50,51,KM5#..JL,T1 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 43356A - DEFLECTOR, LOWER ARM ICE, LH NO.1 | ||||
| 43356-27021 |
CM50,51,KM5#..JL,T1 |
1 | ||
| 43356-27021 |
CM50,51,KM5#..JL,T1 ｶﾝﾚｲﾁ ｼﾖｳ |
1 | ||
| 48066 - ARM SUB-ASSY, FRONT SUSPENSION, UPPER RH | ||||
| 48610-28012 |
CM5#,KM5#,YM55 |
1 | ||
| 48067 - ARM SUB-ASSY, FRONT SUSPENSION, UPPER LH | ||||
| 48630-28012 |
CM5#,KM5#,YM55 |
1 | ||
| 48068 - ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 RH | ||||
| 48068-27050 |
CM5#,KM5#,YM55 |
1 | ||
| 48069 - ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 LH | ||||
| 48069-27050 |
CM5#,KM5#,YM55 |
1 | ||
| 48167 - ARM, TORQUE | ||||
| 48106-28010 |
CM5#,KM5#,YM55 |
2 | ||
| 48106-27040 |
CM50,51,55,KM5#,YM55 |
2 | ||
| 48167A - BOLT(FOR TORQUE ARM SETTING) | ||||
| 91121-71085 |
CM5#,KM5#,YM55 |
4 | ||
| 48167B - TUBE(FOR TORQUE ARM SETTING BOLT) | ||||
| 90440-17029 |
CM50,51,55,KM5#,YM55 |
2 | ||
| 48190 - CAM ASSY, CAMBER ADJUST | ||||
| 48190-27010 |
CM5#,KM5#,YM55 |
2 | ||
| 48190-27010 |
CM5#,6#,KM5#,YM55,60 |
4 | ||
| 48198 - CAM, CAMBER ADJUST, NO.2 | ||||
| 48198-27010 |
CM5#,6#,KM5#,YM55,60 |
4 | ||
| 48198-27010 |
CM50,51,55,KM5#,YM55 |
2 | ||
| 48331A - BUMPER, FRONT SPRING, NO.1 | ||||
| 48331-27060 |
CM50,51,55,KM5#,YM55 |
2 | ||
| 48332 - BUMPER, FRONT SPRING, NO.2 | ||||
| 48305-30030 |
CM5#,6#,KM5#,YM55,6# |
2 | ||
| 48631B - RETAINER, CUSHION(FOR FRONT SUSPENSION UPPER ARM) | ||||
| 90948-02048 |
CM50,51,55,KM5#,YM55 REAR |
2 | ||
| 90948-02049 |
CM50,51,55,KM5#,YM55 FRONT |
2 | ||
| 48631B - RETAINER, CUSHION(FOR FRONT SUSPENSION UPPER ARM) | ||||
| 90948-02048 |
CM50,51,55,KM5#,YM55 REAR |
2 | ||
| 90948-02049 |
CM50,51,55,KM5#,YM55 FRONT |
2 | ||
| 48632 - BUSH, UPPER ARM | ||||
| 48632-27010 |
CM50,51,55,KM5#,YM55 FRONT |
2 | ||
| 48635-28010 |
CM50,51,55,KM5#,YM55 REAR |
2 | ||
| 48632 - BUSH, UPPER ARM | ||||
| 48632-27010 |
CM50,51,55,KM5#,YM55 FRONT |
2 | ||
| 48635-28010 |
CM50,51,55,KM5#,YM55 REAR |
2 | ||
| 48654 - BUSH, LOWER ARM | ||||
| 48061-27011 |
CM50,51,55,KM5#,YM55 |
2 | ||
| 48061-27010 |
CM5#,KM5#,YM55 |
2 | ||
| Common parts | ||||
| 90101-12161 | ||||
| 90101-14040 | ||||
| 90119-08835 | ||||
| 90170-08036 | ||||
| 90171-14042 | ||||
| 90171-16006 | ||||
| 90171-16050 | ||||
| 90179-08038 | ||||
| 90179-10041 | ||||
| 90179-14046 | ||||
| 90201-08016 | ||||
| 90201-12056 | ||||
| 90201-14005 | ||||
| 90252-03006 | ||||
| 91615-60825 | ||||
| 91651-60820 | ||||
| 94531-01400 | ||||
| 94531-01600 | ||||
| 94621-11400 | ||||
| 95381-03025 | ||||
| 95381-03030 | ||||
| 95381-03035 | ||||
