KR41V-FEMDS (1996)
Toyota Lite/Townace Noah,V
ILLUST NO. 1 OF 7(9610-9812)CR4#,5#
ｴﾝｼﾞﾝ ｽｲﾂﾁ, ﾐﾂｼﾖﾝ ｽｲﾂﾁ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83420 - GAGE ASSY, WATER TEMPERATURE SENDER | ||||
| 83420-16040 |
CR40,50,KR4# |
1 | ||
| 83530 - SWITCH ASSY, OIL PRESSURE (FOR ENGINE) | ||||
| 83530-30100 |
CR4#,5# YAZAKI |
1 | ||
| 83530-28010 |
CR4#,5# DENSO |
1 | ||
| 83530-60010 |
CR4#,5# YAZAKI |
1 | ||
| 83530-28020 |
KR4#,SR40,50 DENSO |
1 | ||
| 83530-30090 |
KR4#,SR40,50 |
1 | ||
| 83530-14070 |
CR4#,5# DENSO |
1 | ||
| 83530-60020 |
KR4#,SR40,50 YAZAKI |
1 | ||
| 84210 - SWITCH ASSY, BACK-UP LAMP | ||||
| 84210-12040 |
CR4#,5#,KR4#,SR40..MTM |
1 | ||
| 88620C - THERMO SWITCH ASSY | ||||
| 88620-28020 |
CR4#,5# |
1 | ||
| 88620-28040 |
CR4#,5# |
1 | ||
| Common parts | ||||
| 90430-12221 | ||||
| 90430-18008 | ||||
| 93385-16025 | ||||
ILLUST NO. 3 OF 7(9610-9812)
ｶｳﾙ, ｲﾝﾊﾟﾈ ﾘﾚ-
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81980 - FLASHER ASSY, TURN SIGNAL | ||||
| 81980-12070 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 82600F - FUSE, FUSE BLOCK | ||||
| 90982-09007 |
CR4#,5#,KR4#,SR40,50 5A,ﾐﾆ ﾋｭｰｽﾞ,黄褐色 |
1 | ||
| 90982-09010 |
CR4#,5#,KR4#,SR40,50 15A,ﾐﾆ ﾋｭｰｽﾞ,青 |
1 | ||
| 90982-09009 |
CR4#,5#,KR4#,SR40,50 10A,ﾐﾆ ﾋｭｰｽﾞ,赤 |
1 | ||
| 90982-09011 |
CR4#,5#,KR4#,SR40,50 20A,ﾐﾆ ﾋｭｰｽﾞ,黄 |
1 | ||
| 82600F - FUSE, FUSE BLOCK | ||||
| 90982-09007 |
CR4#,5#,KR4#,SR40,50 5A,ﾐﾆ ﾋｭｰｽﾞ,黄褐色 |
1 | ||
| 90982-09010 |
CR4#,5#,KR4#,SR40,50 15A,ﾐﾆ ﾋｭｰｽﾞ,青 |
1 | ||
| 90982-09009 |
CR4#,5#,KR4#,SR40,50 10A,ﾐﾆ ﾋｭｰｽﾞ,赤 |
1 | ||
| 90982-09011 |
CR4#,5#,KR4#,SR40,50 20A,ﾐﾆ ﾋｭｰｽﾞ,黄 |
1 | ||
| 82600G - PLATE, CAUTION(FOR FUSE) | ||||
| 82683-28430 |
CR4#,5#,SR40,50..B,D,N |
1 | ||
| 82661A - COVER, RELAY BLOCK, NO.2 | ||||
| 82661-28170 |
CR4#,5#,SR40,50 |
1 | ||
| 82730 - BLOCK ASSY, INSTRUMENT PANEL JUNCTION | ||||
| 82730-28030 |
CR4#,5#,KR4#,SR40,50..B,D,N |
1 | ||
| 82730-28030 |
CR4#,51,KR4#,SR40,50..B,D,N |
1 | ||
| 83650 - FUSEE | ||||
| 90986-01005 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 84340 - SWITCH ASSY, STOP LAMP | ||||
| 84340-32050 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 85925D - RELAY, PTC HEATER | ||||
| 85925-17010 |
CR4#,5# |
1 | ||
| 89550 - COMPUTER ASSY, EMISSION CONTROL | ||||
| 89550-28310 |
KR4#..MTM |
1 | ||
| Common parts | ||||
| 90179-06036 | ||||
| 91635-60616 | ||||
| 91651-40616 | ||||
| 93319-15010 | ||||
| Linked diagrams | ||||
| 8202 | ||||
| 8404 | ||||
| 8417 | ||||
ILLUST NO. 6 OF 7(9610-0207)
ﾄﾞｱ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 84233 - SWITCH ASSY, COURTESY LAMP (FOR FRONT DOOR) | ||||
| 84231-33071 |
CR4#,5#,KR4#,SR40,50 左側 |
1 | ||
| 84231-28090 |
CR4#,5#,KR4#,SR40,50 右側 |
1 | ||
| 84231-32050 |
CR4#,5#,KR4#,SR40,50 右側 |
1 | ||
| 84233 - SWITCH ASSY, COURTESY LAMP (FOR FRONT DOOR) | ||||
| 84231-33071 |
CR4#,5#,KR4#,SR40,50 左側 |
1 | ||
| 84231-28090 |
CR4#,5#,KR4#,SR40,50 右側 |
1 | ||
| 84231-32050 |
CR4#,5#,KR4#,SR40,50 右側 |
1 | ||
| 84234E - SWITCH, COURTESY LAMP (FOR SLIDE DOOR) | ||||
| 84231-28070 |
CR41,51,KR4#,SR40,50..5D |
2 | ||
| 84231-28080 |
CR41,51,KR4#,SR40,50..5D |
2 | ||
| 84231-28071 |
CR41,51,KR4#,SR40,50..5D |
2 | ||
| 84234E - SWITCH, COURTESY LAMP (FOR SLIDE DOOR) | ||||
| 84231-28070 |
CR41,51,KR4#,SR40,50..5D |
2 | ||
| 84231-28080 |
CR41,51,KR4#,SR40,50..5D |
2 | ||
| 84231-28071 |
CR41,51,KR4#,SR40,50..5D |
2 | ||
| 84261B - JUNCTION, SLIDE DOOR CONTROL,MALE | ||||
| 84261-28090 |
CR41,51,KR4#,SR40,50..5D 右側 |
1 | ||
| 84261-28080 |
CR41,51,KR4#,SR40,50..03S,05S,06S 左側 |
1 | ||
| 84261B - JUNCTION, SLIDE DOOR CONTROL,MALE | ||||
| 84261-28090 |
CR41,51,KR4#,SR40,50..5D 右側 |
1 | ||
| 84261-28080 |
CR41,51,KR4#,SR40,50..03S,05S,06S 左側 |
1 | ||
| 84262B - JUNCTION, SLIDE DOOR CONTROL, FEMALE | ||||
| 84262-28060 |
CR41,51,KR4#,SR40,50..03S,05S,06S 左側 |
1 | ||
| 84262-28070 |
CR41,51,KR4#,SR40,50..5D 右側 |
1 | ||
| 84262B - JUNCTION, SLIDE DOOR CONTROL, FEMALE | ||||
| 84262-28060 |
CR41,51,KR4#,SR40,50..03S,05S,06S 左側 |
1 | ||
| 84262-28070 |
CR41,51,KR4#,SR40,50..5D 右側 |
1 | ||
| Common parts | ||||
| 90109-06296 | ||||
| 90119-06709 | ||||
| 90153-60012 | ||||
| 90159-60303 | ||||
| 90164-40103 | ||||
| 90189-06034 | ||||
ILLUST NO. 5 OF 7(9610-9812)
ﾀ-ﾝｼｸﾞﾅﾙ ｽｲﾂﾁ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 84052 - SWITCH ASSY, UN-LOCK WARNING | ||||
| 84052-12070 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 84140 - SWITCH ASSY, HEADLAMP DIMMER | ||||
| 84140-20570 |
CR40,50,KR41,SR40,50;CR41,51,KR42..D..CBU ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ) |
1 | ||
| 84140-12380 |
CR4#,5#,KR4#,SR40,50..B,D |
1 | ||
| 84310 - SWITCH ASSY, TURN SIGNAL | ||||
| 84310-28850 |
CR41,51,KR4#..D ｱﾘ(*80) |
1 | ||
| 84310-1E050 |
CR41,51,KR4#..D |
1 | ||
| 84310-1E490 |
CR41,51,KR4#..D..CBU ｱﾘ(*80 & ﾘﾔﾜｲﾊﾟ) |
1 | ||
| 84310-1A830 |
CR41,51,KR4#..D..CBU ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ) |
1 | ||
| 84310-28860 |
CR41,51,KR4#..D..CBU ｱﾘ(*80 & ﾘﾔﾜｲﾊﾟ) |
1 | ||
| 84310-1E480 |
CR41,51,KR4#..D ｱﾘ(*80) |
1 | ||
| 84312 - PLATE, HORN CONTACT | ||||
| 84312-26010 |
CR41,51,KR4#..D..CBU ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ) |
1 | ||
| 84312-12050 |
CR41,51,KR4#..D |
1 | ||
| 84450 - SWITCH ASSY, IGNITION OR STARTER | ||||
| 84450-12200 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 84650 - SWITCH ASSY, WINDSHIELD WIPER | ||||
| 84652-1A560 |
CR4#,5#,KR4#,SR40,50..B,D |
1 | ||
| 84652-1A510 |
CR4#,5#,KR4#,SR40,50..(B,D)..CBU ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ) |
1 | ||
| Common parts | ||||
| 93319-14012 | ||||
| 93319-15012 | ||||
ILLUST NO. 5 OF 7(9610-9812)
ﾀ-ﾝｼｸﾞﾅﾙ ｽｲﾂﾁ---ｴｱﾊﾞﾂｸ ﾂｷ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 84052 - SWITCH ASSY, UN-LOCK WARNING | ||||
| 84052-12070 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 84140 - SWITCH ASSY, HEADLAMP DIMMER | ||||
| 84140-20570 |
CR40,50,KR41,SR40,50;CR41,51,KR42..D..CBU ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ) |
1 | ||
| 84140-12380 |
CR4#,5#,KR4#,SR40,50..B,D |
1 | ||
| 84306 - CABLE SUB-ASSY, SPIRAL | ||||
| 84306-12080 |
CR4#,5#,KR4#,SR40,50..B,D |
1 | ||
| 84306-35010 |
CR40,50,KR41,SR40,50;CR41,51,KR42..D..CBU ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ) |
1 | ||
| 84306-20080 |
CR4#,5#,KR4#,SR40,50..B,D |
1 | ||
| 84306-35011 |
CR41,51,KR42..CBU;CR40,50,KR41,SR40,50 ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ),ﾀｲﾌﾟ A |
1 | ||
| 84306-12070 |
CR41,51,KR42..CBU;CR40,50,KR41,SR40,50 ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ),ﾀｲﾌﾟ B |
1 | ||
| 84310 - SWITCH ASSY, TURN SIGNAL | ||||
| 84310-28850 |
CR41,51,KR4#..D ｱﾘ(*80) |
1 | ||
| 84310-1E050 |
CR41,51,KR4#..D |
1 | ||
| 84310-1E490 |
CR41,51,KR4#..D..CBU ｱﾘ(*80 & ﾘﾔﾜｲﾊﾟ) |
1 | ||
| 84310-1A830 |
CR41,51,KR4#..D..CBU ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ) |
1 | ||
| 84310-28860 |
CR41,51,KR4#..D..CBU ｱﾘ(*80 & ﾘﾔﾜｲﾊﾟ) |
1 | ||
| 84310-1E480 |
CR41,51,KR4#..D ｱﾘ(*80) |
1 | ||
| 84450 - SWITCH ASSY, IGNITION OR STARTER | ||||
| 84450-12200 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 84650 - SWITCH ASSY, WINDSHIELD WIPER | ||||
| 84652-1A560 |
CR4#,5#,KR4#,SR40,50..B,D |
1 | ||
| 84652-1A510 |
CR4#,5#,KR4#,SR40,50..(B,D)..CBU ｱﾘ(ﾘﾔﾜｲﾊﾟ---INTﾂｷ) |
1 | ||
| Common parts | ||||
| 93319-14012 | ||||
| 93319-15012 | ||||
ILLUST NO. 1 OF 7(9611-9812)KR4#
ｴﾝｼﾞﾝ ｽｲﾂﾁ, ﾐﾂｼﾖﾝ ｽｲﾂﾁ
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 83420 - GAGE ASSY, WATER TEMPERATURE SENDER | ||||
| 83420-16040 |
CR40,50,KR4# |
1 | ||
| 83530 - SWITCH ASSY, OIL PRESSURE (FOR ENGINE) | ||||
| 83530-30100 |
CR4#,5# YAZAKI |
1 | ||
| 83530-28010 |
CR4#,5# DENSO |
1 | ||
| 83530-60010 |
CR4#,5# YAZAKI |
1 | ||
| 83530-28020 |
KR4#,SR40,50 DENSO |
1 | ||
| 83530-30090 |
KR4#,SR40,50 |
1 | ||
| 83530-14070 |
CR4#,5# DENSO |
1 | ||
| 83530-60020 |
KR4#,SR40,50 YAZAKI |
1 | ||
| 84210 - SWITCH ASSY, BACK-UP LAMP | ||||
| 84210-12040 |
CR4#,5#,KR4#,SR40..MTM |
1 | ||
| 89465 - SENSOR, OXYGEN | ||||
| 89465-28200 |
KR4# |
1 | ||
| Common parts | ||||
| 90430-18008 | ||||
| 90464-00429 | ||||
| 93385-16025 | ||||
ILLUST NO. 4 OF 7(9610-9812)
ｲﾝｽﾄﾙﾒﾝﾄﾊﾟﾈﾙSW.
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 84330 - SWITCH ASSY, HAZARD WARNING SIGNAL | ||||
| 84332-28130 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 84330B - BULB, HAZARD WARNING SIGNAL SWITCH | ||||
| 84999-10320 |
CR4#,5#,KR4#,SR40,50 14V 0.84W |
1 | ||
| 84660C - SWITCH, COOLER | ||||
| 84660-10110 |
CR4#,5#,KR4#,SR40,50..B,D,N |
1 | ||
| 84660-10110 |
CR4#,5#,KR4#,SR40,50..03S,05S,06S,08S |
1 | ||
| 84660D - BULB(FOR COOLER SWITCH) | ||||
| 88607-10020 |
CR4#,5#,KR4#,SR40,50..B,D,N 14V 0.08A |
1 | ||
| 88607-10020 |
CR4#,5#,KR4#,SR40,50..03S,05S,06S,08S 14V 0.08A |
1 | ||
| 84790 - SWITCH ASSY, REAR WINDOW DEFOGGER | ||||
| 84790-28050 |
CR41,51,KR42..CBU;CR40,50,KR41,SR40,50 |
1 | ||
| 84790B - BULB(FOR REAR WINDOW DEFOGGER SWITCH) | ||||
| 84999-10320 |
CR41,51,KR42..CBU;CR40,50,KR41,SR40,50 14V 0.84W |
1 | ||
| 84930 - SWITCH ASSY, DOOR CONTROL | ||||
| 84930-87003 |
CR4#,5#,KR4#,SR40,50..B,D,N |
1 | ||
| 85500 - LIGHTER ASSY, CIGARETTE | ||||
| 85500-28050 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 85500 - LIGHTER ASSY, CIGARETTE | ||||
| 85500-28050 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 85513 - COVER, CIGARETTE LIGHTER | ||||
| 85513-12020 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 85513 - COVER, CIGARETTE LIGHTER | ||||
| 85513-12020 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 85520 - KNOB AND ELEMENT ASSY, CIGARETTE LIGHTER | ||||
| 85520-28010 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 85520 - KNOB AND ELEMENT ASSY, CIGARETTE LIGHTER | ||||
| 85520-28010 |
CR4#,5#,KR4#,SR40,50 |
1 | ||
| 85533 - LENS, CIGARETTE LIGHTER INDICATOR | ||||
| 85533-26010 |
CR4#,5#,KR4#,SR40,50..B,D,N |
1 | ||
