S413M-ZMDFJD (2020)
Toyota Lite/Townace
Production
Jul 2020
-
Sep 9999
Engine
2NRVE
Transmission
Displacement
2500cc
Power
168 HP (125 kW)
(2007- )
Click highlighted areas on diagram
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 67001 - PANEL SUB-ASSY, FRONT DOOR, RH | ||||
| 67001-BZ211 |
S403,413 |
1 | ||
| 67001A - CUSHION, FRONT DOOR PANEL | ||||
| 90541-09069 |
S403,413 |
4 | ||
| 67001A - CUSHION, FRONT DOOR PANEL | ||||
| 90541-09069 |
S403,413 |
4 | ||
| 67002 - PANEL SUB-ASSY, FRONT DOOR, LH | ||||
| 67002-BZ201 |
S403,413 |
1 | ||
| 67355 - REINFORCEMENT, FRONT DOOR REAR FRAME, RH | ||||
| 67305-BZ010 |
S403,413 |
1 | ||
| 67401F - FRAME SUB-ASSY, FRONT DOOR, FRONT LOWER RH | ||||
| 67401-BZ030 |
S403,413 |
1 | ||
| 67402F - FRAME SUB-ASSY, FRONT DOOR, FRONT LOWER LH | ||||
| 67402-BZ030 |
S403,413 |
1 | ||
| 67433 - FRAME, FRONT DOOR WINDOW, REAR LOWER RH | ||||
| 67403-BZ060 |
S403,413 |
1 | ||
| 67434 - FRAME, FRONT DOOR WINDOW, REAR LOWER LH | ||||
| 67404-BZ060 |
S403,413 |
1 | ||
| 67601 - BOARD SUB-ASSY, FRONT DOOR TRIM, RH | ||||
| 67610-BZ270B1 |
S403,413..DXED,GL -,TRIM1# |
1 | ||
| 67601B - CLIP(FOR FRONT DOOR TRIM BOARD) | ||||
| 67771-BZ070 |
S403,413 |
36 | ||
| 67602 - BOARD SUB-ASSY, FRONT DOOR TRIM, LH | ||||
| 67620-BZ280B1 |
S403,413..DXED,GL -,TRIM1# |
1 | ||
| 67631 - SEAL, DOOR TRIM PANEL(FOR FRONT DOOR) | ||||
| 75975-BZ010 |
S403,413 |
2 | ||
| 67663D - GARNISH, DOOR FRAME, RH | ||||
| 67663-BZ010 |
S403,413 |
1 | ||
| 67664C - GARNISH, DOOR FRAME, LH | ||||
| 67664-BZ010 |
S403,413 |
1 | ||
| 67772A - CAP, FRONT DOOR TRIM RETAINER | ||||
| 67772-87Z02 |
S403,413 |
2 | ||
| 67831 - COVER, FRONT DOOR SERVICE HOLE, RH | ||||
| 67831-BZ160 |
S403,413..DXED,GL |
1 | ||
| 67832 - COVER, FRONT DOOR SERVICE HOLE, LH | ||||
| 67831-BZ160 |
S403,413..DXED,GL |
1 | ||
| 67861 - WEATHERSTRIP, FRONT DOOR, RH | ||||
| 67861-BZ080 |
S403,413..VAN |
1 | ||
| 67862 - WEATHERSTRIP, FRONT DOOR, LH | ||||
| 67862-BZ060 |
S403,413..VAN |
1 | ||
| 67867 - CLIP, DOOR WEATHERSTRIP | ||||
| 90467-06084 |
S403,413 |
1 | ||
| 67867C - RETAINER, FRONT DOOR WEATHERSTRIP, RH | ||||
| 67867-BZ010 |
S403,413 |
35 | ||
| 67868L - RETAINER, DOOR WEATHERSTRIP, LH | ||||
| 67868-BZ010 |
S403,413 |
36 | ||
| 67869J - CLIP, FRONT DOOR WEATHERSTRIP | ||||
| 90467-06084 |
S403,413 |
1 | ||
| 67923 - CUSHION, FRONT DOOR STIFFENER, NO.1 | ||||
| 67923-BZ020 |
S403,413 |
1 | ||
| 67924 - CUSHION, FRONT DOOR STIFFENER, NO.2 | ||||
| 67924-BZ010 |
S403,413 |
1 | ||
| 68101 - GLASS SUB-ASSY, FRONT DOOR, RH | ||||
| 68101-BZ160 |
S403,413 |
1 | ||
| 68102 - GLASS SUB-ASSY, FRONT DOOR, LH | ||||
| 68102-BZ150 |
S403,413 |
1 | ||
| 68141 - RUN, FRONT DOOR GLASS | ||||
| 68141-BZ060 |
S403,413 右側 |
1 | ||
| 68151-BZ060 |
S403,413 左側 |
1 | ||
| 68141E - RUN, FRONT DOOR GLASS, RH | ||||
| 68143-BZ030 |
S403,413 |
1 | ||
| 68151D - RUN, FRONT DOOR GLASS, LH | ||||
| 68143-BZ030 |
S403,413 |
1 | ||
| 68160C - WEATHERSTRIP ASSY, FRONT DOOR GLASS, OUTER RH | ||||
| 68161-BZ070 |
S403,413 |
1 | ||
| 68171B - WEATHERSTRIP, FRONT DOOR GLASS, INNER RH | ||||
| 68171-BZ110 |
S403,413 |
1 | ||
| 68172A - WEATHERSTRIP, FRONT DOOR GLASS, INNER LH | ||||
| 68172-BZ100 |
S403,413 |
1 | ||
| 68210C - WEATHERSTRIP ASSY, FRONT DOOR GLASS, OUTER LH | ||||
| 68162-BZ060 |
S403,413 |
1 | ||
| 68610B - CHECK ASSY, FRONT DOOR, RH | ||||
| 68610-BZ090 |
S403,413 |
1 | ||
| 68620 - CHECK ASSY, FRONT DOOR, LH | ||||
| 68610-BZ090 |
S403,413 |
1 | ||
| Common parts | ||||
| 67713-BZ010 | ||||
| 9004A-10168 | ||||
| 9004A-10260 | ||||
| 9004A-11216 | ||||
| 9004A-11244 | ||||
| 9004A-11294 | ||||
| 90541-09143 | ||||
| 91621-40610 | ||||
