UVF46-AEXQH (2007)
Toyota Lexus Ls600h/600hl
(0704-0809)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 81080D - LAMP ASSY, FRONT DOOR INSIDE HANDLE ILLUMINATION, RH | ||||
| 81080-50040 |
UVF4# |
1 | ||
| 81080E - LAMP ASSY, FRONT DOOR INSIDE HANDLE ILLUMINATION, LH | ||||
| 81080-50050 |
UVF4# |
1 | ||
| 81080F - LAMP ASSY, REAR DOOR INSIDE HANDLE ILLUMINATION, RH | ||||
| 81080-50040 |
UVF4# |
1 | ||
| 81080G - LAMP ASSY, REAR DOOR INSIDE HANDLE ILLUMINATION, LH | ||||
| 81080-50050 |
UVF4# |
1 | ||
| 81080H - LAMP ASSY, INTERIOR ILLUMINATION, NO.1 RH | ||||
| 81080-50030 |
UVF4# |
1 | ||
| 81080J - LAMP ASSY, INTERIOR ILLUMINATION, NO.1 | ||||
| 81080-30010 |
UVF46 有り(ｵｯﾄﾏﾝ)&有り(DVDﾌﾟﾚｲﾔ&ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ) |
1 | ||
| 81080L - LAMP ASSY, INTERIOR ILLUMINATION, NO.1 LH | ||||
| 81080-50030 |
UVF4# |
1 | ||
| 81080P - LAMP ASSY, INTERIOR ILLUMINATION, NO.1 RH | ||||
| 81081-50020 |
UVF4# |
1 | ||
| 81080S - LAMP ASSY, INTERIOR ILLUMINATION, NO.1 LH | ||||
| 81081-50030 |
UVF4# |
1 | ||
| 81090 - LAMP ASSY, INTERIOR ILLUMINATION, NO.2 | ||||
| 81080-22040 |
UVF4# |
1 | ||
| 81205C - BULB, ASH RECEPTACLE LAMP, REAR RH | ||||
| 90981-1104179 |
UVF4# |
1 | ||
| 81205D - BULB, ASH RECEPTACLE LAMP, REAR LH | ||||
| 90981-1104179 |
UVF4# |
1 | ||
| 81206A - LAMP SUB-ASSY, CONSOLE BOX | ||||
| 81206-50050A1 |
UVF46 有り(ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),MELLOW WHITE,TRIM01,05,07,08 |
1 | ||
| 81206-50050A1 |
UVF46 有り(ｵｯﾄﾏﾝ)&有り(DVDﾌﾟﾚｲﾔ&ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),MELLOW WHITE,TRIM01,05,07,08 |
1 | ||
| 81206-50050B0 |
UVF46 有り(ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),LT.GRAY,TRIM10,11,20,21 |
1 | ||
| 81206-50050A0 |
UVF46 有り(ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),IVORY,TRIM00,06 |
1 | ||
| 81206-50050B0 |
UVF46 有り(ｵｯﾄﾏﾝ)&有り(DVDﾌﾟﾚｲﾔ&ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),LT.GRAY,TRIM10,11,20,21 |
1 | ||
| 81206-50050A0 |
UVF46 有り(ｵｯﾄﾏﾝ)&有り(DVDﾌﾟﾚｲﾔ&ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),IVORY,TRIM00,06 |
1 | ||
| 81230 - LAMP ASSY, COURTESY | ||||
| 81230-47010 |
UVF4# |
4 | ||
| 81230A - LAMP ASSY, COURTESY, NO.2 | ||||
| 81230-30140 |
UVF4# |
1 | ||
| 81230B - BULB(FOR COURTESY LAMP) | ||||
| 90981-1201079 |
UVF4# 12V 5W |
4 | ||
| 81230C - BULB(FOR COURTESY LAMP NO.2) | ||||
| 90981-1102079 |
UVF4# 12V 3.8W |
1 | ||
| 81231A - LENS, COURTESY LAMP, NO.2 | ||||
| 81231-50010 |
UVF4# |
1 | ||
| 81240 - LAMP ASSY, ROOM, NO.1 | ||||
| 81024-50010 |
UVF4# 読書灯−有り |
1 | ||
| 81250C - BULB, SPOT LAMP | ||||
| 90981-14004 |
UVF4# 12V 8W |
1 | ||
| 81250C - BULB, SPOT LAMP | ||||
| 90981-14004 |
UVF4# 12V 8W |
1 | ||
| 81251A - LENS, SPOT LAMP | ||||
| 81361-50020A1 |
UVF46 有り(ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),MELLOW WHITE,TRIM01,05,07,08 |
1 | ||
| 81361-50020A0 |
UVF46 有り(ｵｯﾄﾏﾝ)&有り(DVDﾌﾟﾚｲﾔ&ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),IVORY,TRIM00,06 |
1 | ||
| 81361-50020A1 |
UVF46 有り(ｵｯﾄﾏﾝ)&有り(DVDﾌﾟﾚｲﾔ&ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),MELLOW WHITE,TRIM01,05,07,08 |
1 | ||
| 81361-50020A0 |
UVF46 有り(ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),IVORY,TRIM00,06 |
1 | ||
| 81361-50020B0 |
UVF46 有り(ｵｯﾄﾏﾝ)&有り(DVDﾌﾟﾚｲﾔ&ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),LT.GRAY,TRIM10,11,20,21 |
1 | ||
| 81361-50020B0 |
UVF46 有り(ﾃﾞｼﾞﾀﾙﾃﾚﾋﾞ&後席ﾃﾞｨｽﾌﾟﾚｲ),LT.GRAY,TRIM10,11,20,21 |
1 | ||
| 81260A - LAMP ASSY, MAP | ||||
| 81260-50721A6 |
UVF46 MELLOW WHITE,TRIM08 |
1 | ||
| 81260-50721B1 |
UVF46 BLACK,TRIM11,20 |
1 | ||
| 81260-50721A2 |
UVF46 IVORY,TRIM00 |
1 | ||
| 81260-50721A3 |
UVF46 MELLOW WHITE,TRIM01,05 |
1 | ||
| 81260-50692A4 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),IVORY,TRIM06 |
1 | ||
| 81260-50692A2 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),IVORY,TRIM00 |
1 | ||
| 81260-50721B2 |
UVF46 LT.GRAY,TRIM10,21 |
1 | ||
| 81260-50692B2 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),LT.GRAY,TRIM10,21 |
1 | ||
| 81260-50692B1 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),BLACK,TRIM11,20 |
1 | ||
| 81260-50692A3 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),MELLOW WHITE,TRIM01,05 |
1 | ||
| 81260-50721A5 |
UVF46 MELLOW WHITE,TRIM07 |
1 | ||
| 81260-50692A5 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),MELLOW WHITE,TRIM07 |
1 | ||
| 81260-50722A3 |
UVF46 MELLOW WHITE,TRIM01,05 |
1 | ||
| 81260-50722A4 |
UVF46 IVORY,TRIM06 |
1 | ||
| 81260-50722A6 |
UVF46 MELLOW WHITE,TRIM08 |
1 | ||
| 81260-50722B1 |
UVF46 BLACK,TRIM11,20 |
1 | ||
| 81260-50722A5 |
UVF46 MELLOW WHITE,TRIM07 |
1 | ||
| 81260-50722A2 |
UVF46 IVORY,TRIM00 |
1 | ||
| 81260-50722B2 |
UVF46 LT.GRAY,TRIM10,21 |
1 | ||
| 81260-50692A6 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),MELLOW WHITE,TRIM08 |
1 | ||
| 81260-50691A2 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),IVORY,TRIM00 |
1 | ||
| 81260-50691A4 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),IVORY,TRIM06 |
1 | ||
| 81260-50691A6 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),MELLOW WHITE,TRIM08 |
1 | ||
| 81260-50691A3 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),MELLOW WHITE,TRIM01,05 |
1 | ||
| 81260-50691A5 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),MELLOW WHITE,TRIM07 |
1 | ||
| 81260-50691B1 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),BLACK,TRIM11,20 |
1 | ||
| 81260-50691B2 |
UVF46 盗難防止ｼｽﾃﾑ−有り(侵入ｾﾝｻ+ﾘﾓｰﾄｾｷｭﾘﾃｨ),LT.GRAY,TRIM10,21 |
1 | ||
| 81260-50721A4 |
UVF46 IVORY,TRIM06 |
1 | ||
| 81260C - BULB(FOR MAP LAMP) | ||||
| 90981-1106279 |
UVF46 12V 8W |
2 | ||
| 90981-1106279 |
UVF46 12V 8W |
2 | ||
| 81260C - BULB(FOR MAP LAMP) | ||||
| 90981-1106279 |
UVF46 12V 8W |
2 | ||
| 90981-1106279 |
UVF46 12V 8W |
2 | ||
| 81330 - LAMP ASSY, LUGGAGE COMPARTMENT, NO.1 | ||||
| 81330-50021 |
UVF4# |
1 | ||
| 81330B - BULB, LUGGAGE COMPARTMENT LAMP | ||||
| 90981-1102079 |
UVF4# 12V 3.8W |
1 | ||
| 81331 - LENS, LUGGAGE COMPARTMENT LAMP | ||||
| 81331-50010 |
UVF4# |
1 | ||
| 81340 - LAMP ASSY, VANITY | ||||
| 81340-30100A0 |
UVF4# IVORY,TRIM00,06 |
2 | ||
| 81340-30100B0 |
UVF4# LT.GRAY,TRIM10,11,20,21 |
2 | ||
| 81340-30100A2 |
UVF4# MELLOW WHITE,TRIM01,05,07,08 |
2 | ||
| 81340A - LAMP ASSY, REAR VANITY | ||||
| 81340-50170B0 |
UVF4# LT.GRAY,TRIM10,11,20,21 |
2 | ||
| 81340-50170A0 |
UVF4# MELLOW WHITE,TRIM01,05,07,08 |
2 | ||
| 81340-50170A2 |
UVF4# IVORY,TRIM00,06 |
2 | ||
| 81340B - BULB (FOR VANITY LAMP) | ||||
| 90981-1106279 |
UVF4# 12V 8W |
2 | ||
| 81340C - BULB (FOR REAR VANITY LAMP) | ||||
| 90981-14007 |
UVF4# |
6 | ||
| 81340C - BULB (FOR REAR VANITY LAMP) | ||||
| 90981-14007 |
UVF4# |
6 | ||
| 81340C - BULB (FOR REAR VANITY LAMP) | ||||
| 90981-14007 |
UVF4# |
6 | ||
| 81360T - LAMP ASSY, SPOT | ||||
| 81360-50030A0 |
UVF4# IVORY,TRIM00,06 |
1 | ||
| 81360-50030A1 |
UVF4# MELLOW WHITE,TRIM01,05,07,08 |
1 | ||
| 81360-50030B0 |
UVF4# LT.GRAY,TRIM10,11,20,21 |
1 | ||
| Common parts | ||||
| 90159-40206 | ||||
| 90168-40048 | ||||
| 90168-40116 | ||||
| 90189-04102 | ||||
| 90189-04217 | ||||
| Linked diagrams | ||||
| 5501 | ||||
| 6402 | ||||
| 8202 | ||||
| 8424 | ||||
| 8603 | ||||
