VXFA55-AEUQT (2017)
Toyota Lexus Ls500/500h
(1710-2010)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 63395E - CLIP(FOR MAP LAMP) | ||||
| 90467-09240 |
VXFA5# |
4 | ||
| 81080J - LAMP ASSY, INTERIOR ILLUMINATION, NO.1 | ||||
| 81080-50110 |
VXFA5# |
1 | ||
| 81080K - LAMP ASSY, CONSOLE BOX ILLUMINATION | ||||
| 81080-50110 |
VXFA5# |
1 | ||
| 81080V - LAMP ASSY, INTERIOR ILLUMINATION, NO.2 | ||||
| 81080-50110 |
VXFA5# |
1 | ||
| 81080W - LAMP ASSY, INTERIOR ILLUMINATION, NO.3 | ||||
| 81080-50110 |
VXFA5# |
2 | ||
| 81080X - LAMP ASSY, METER HOOD ILLUMINATION | ||||
| 81080-50200 |
VXFA5# “EXECUTIVE”*(E)&ｽﾃｱﾘﾝｸﾞﾎｲｰﾙ−本杢&革巻,有り(ｽﾃｱﾘﾝｸﾞﾋｰﾀ) |
1 | ||
| 81080-50200 |
GVF5#,VXFA5# “EXECUTIVE”*(E) |
1 | ||
| 81080-50200 |
VXFA5# “version L”*(L)&ｽﾃｱﾘﾝｸﾞﾎｲｰﾙ−本杢&革巻,有り(ｽﾃｱﾘﾝｸﾞﾋｰﾀ) |
1 | ||
| 81080-50200 |
GVF5#,VXFA5# “version L”*(L) |
1 | ||
| 81080Y - LAMP ASSY, COIN BOX | ||||
| 81080-50210 |
VXFA5# |
1 | ||
| 81230 - LAMP ASSY, COURTESY | ||||
| 81230-11030 |
VXFA5# |
2 | ||
| 81230A - LAMP ASSY, COURTESY, NO.2 | ||||
| 81230-11030 |
VXFA5# |
2 | ||
| 81240 - LAMP ASSY, ROOM, NO.1 | ||||
| 81024-50020 |
GVF5#,VXFA5# 読書灯−有り |
1 | ||
| 81260 - LAMP ASSY, GLOVE BOX | ||||
| 81080-50110 |
VXFA5# |
1 | ||
| 81260A - LAMP ASSY, MAP | ||||
| 81208-50060A0 |
VXFA5# “EXECUTIVE”*(E)&ﾑｰﾝﾙｰﾌ−有り,WHITE,TRIM0#,41,45,54,59 |
1 | ||
| 81208-50060E0 |
VXFA5# “EXECUTIVE”*(E)&ﾑｰﾝﾙｰﾌ−有り,NOBLE BROWN,TRIM48,49,52,53,9# |
1 | ||
| 81208-50230E0 |
VXFA5# “version L”*(L),NOBLE BROWN,TRIM48,49,52,53,9# |
1 | ||
| 81208-50050C0 |
VXFA5# ﾑｰﾝﾙｰﾌ−有り,BLACK,TRIM0#,2#,3# |
1 | ||
| 81208-50050A0 |
VXFA5# ﾑｰﾝﾙｰﾌ−有り,WHITE,TRIM1#,4#,5# |
1 | ||
| 81208-50060A0 |
VXFA5# “version L”*(L)&ﾑｰﾝﾙｰﾌ−有り,WHITE,TRIM0#,41,45,54,59 |
1 | ||
| 81208-50060E0 |
VXFA5# “version L”*(L)&ﾑｰﾝﾙｰﾌ−有り,NOBLE BROWN,TRIM48,49,52,53,9# |
1 | ||
| 81208-50230E0 |
VXFA5# “EXECUTIVE”*(E),NOBLE BROWN,TRIM48,49,52,53,9# |
1 | ||
| 81208-50060C0 |
VXFA5# “EXECUTIVE”*(E)&ﾑｰﾝﾙｰﾌ−有り,BLACK,TRIM2#,3# |
1 | ||
| 81208-50230C0 |
VXFA5# “version L”*(L),BLACK,TRIM2#,3# |
1 | ||
| 81208-50230A0 |
VXFA5# “EXECUTIVE”*(E),WHITE,TRIM0#,41,45,54,59 |
1 | ||
| 81208-50060E0 |
VXFA5# “version L”*(L)&ﾑｰﾝﾙｰﾌ−有り,NOBLE BROWN,TRIM46,48,49,52,53,9# |
1 | ||
| 81208-50230E0 |
VXFA5# “version L”*(L),NOBLE BROWN,TRIM46,48,49,52,53,9# |
1 | ||
| 81208-50220C0 |
VXFA5# BLACK,TRIM0#,2#,3# |
1 | ||
| 81208-50230C0 |
VXFA5# “EXECUTIVE”*(E),BLACK,TRIM2#,3# |
1 | ||
| 81208-50230A0 |
VXFA5# “version L”*(L),WHITE,TRIM0#,41,45,54,59 |
1 | ||
| 81208-50230E0 |
VXFA5# “EXECUTIVE”*(E),NOBLE BROWN,TRIM46,48,49,52,53,9# |
1 | ||
| 81208-50220A0 |
VXFA5# WHITE,TRIM1#,4#,5# |
1 | ||
| 81208-50060E0 |
VXFA5# “EXECUTIVE”*(E)&ﾑｰﾝﾙｰﾌ−有り,NOBLE BROWN,TRIM46,48,49,52,53,9# |
1 | ||
| 81208-50060C0 |
VXFA5# “version L”*(L)&ﾑｰﾝﾙｰﾌ−有り,BLACK,TRIM2#,3# |
1 | ||
| 81330 - LAMP ASSY, LUGGAGE COMPARTMENT, NO.1 | ||||
| 81330-11010 |
VXFA5# |
1 | ||
| 81330A - LAMP ASSY, LUGGAGE COMPARTMENT, NO.2 | ||||
| 81330-11010 |
VXFA5# |
1 | ||
| 81340 - LAMP ASSY, VANITY | ||||
| 81340-50260 |
VXFA5# |
2 | ||
| 81360T - LAMP ASSY, SPOT | ||||
| 81360-50190E0 |
VXFA5# NOBLE BROWN,TRIM46,48,49,52,53,9# |
1 | ||
| 81360-50190A1 |
VXFA5# L WHITE,TRIM00,04,05,1#,4#,51,54,57,59 |
1 | ||
| 81360-50190C0 |
VXFA5# BLACK,TRIM06,2#,3# |
1 | ||
| Linked diagrams | ||||
| 6402 | ||||
| 8424 | ||||
