GWL10-BEXQB (2012)
Toyota Lexus Gs Series
(1203- )2GRFXE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11363A - COVER, FLYWHEEL HOUSING SIDE | ||||
| 11363-31010 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
1 | ||
| 11363-31030 |
2GR#,4GRFSE..GRL1#,GWL10 |
1 | ||
| 11401 - BLOCK SUB-ASSY, CYLINDER | ||||
| 11401-39777 |
2GR#..GRL10,15,GWL10 |
1 | ||
| 11401-39775 |
2GR#..GRL15,GWL10;2GRFSE..GRL10..8FC |
1 | ||
| 11401-39776 |
2GR#..GRL10,15,GWL10 |
1 | ||
| 11401G - SENSOR, CRANK POSITION | ||||
| 90919-05057 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
1 | ||
| 11415 - COCK SUB-ASSY, WATER DRAIN(FOR CYLINDER BLOCK) | ||||
| 90910-09129 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
2 | ||
| 90345-52001 |
2GR#,4GRFSE..GRL1#,GWL10 左側,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 90910-09129 |
2GR#,4GRFSE..GRL1#,GWL10 右側 |
1 | ||
| 11415 - COCK SUB-ASSY, WATER DRAIN(FOR CYLINDER BLOCK) | ||||
| 90910-09129 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
2 | ||
| 90345-52001 |
2GR#,4GRFSE..GRL1#,GWL10 左側,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 90910-09129 |
2GR#,4GRFSE..GRL1#,GWL10 右側 |
1 | ||
| 11415A - PLUG, WATER DRAIN COCK(FOR CYLINDER BLOCK) | ||||
| 90910-09087 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
2 | ||
| 11415A - PLUG, WATER DRAIN COCK(FOR CYLINDER BLOCK) | ||||
| 90910-09087 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
2 | ||
| 11416 - BOLT(FOR CRANKSHAFT BEARING CAP SET) | ||||
| 90910-02153 |
2GR#,4GRFSE..GRL1#,GWL10 |
7 | ||
| 11421 - BOLT, STUD(FOR OIL PAN) | ||||
| 90126-08052 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
2 | ||
| 11434A - PIN, STRAIGHT(FOR TIMING GEAR COVER SET) | ||||
| 90250-04097 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 長さ=12,外径=4.0 |
2 | ||
| 11434C - PIN, STRAIGHT (FOR CYLINDER HEAD SET) | ||||
| 90250-08120 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 長さ=18,外径=8 |
4 | ||
| 11434C - PIN, STRAIGHT (FOR CYLINDER HEAD SET) | ||||
| 90250-08120 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 長さ=18,外径=8 |
4 | ||
| 11434D - PIN, STRAIGHT(FOR ENGINE REAR OIL SEAL) | ||||
| 90250-04097 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 長さ=12,外径=4.0 |
2 | ||
| 11434G - PIN, STRAIGHT(FOR END PLATE) | ||||
| 90250-10113 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
2 | ||
| 11434T - PIN, RING(FOR TIMING BELT IDLER BRACKET SET) | ||||
| 90250-10030 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
1 | ||
| 11434Y - PIN, STRAIGHT(FOR OIL PAN) | ||||
| 90250-04097 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
2 | ||
| 11452 - GUIDE, OIL LEVEL GAGE | ||||
| 11452-31040 |
2GRFSE..GRL10..8FC;2GRFXE,4GRFSE..GRL11,GWL10 |
1 | ||
| 11452B - RING, O(FOR OIL LEVEL GAGE GUIDE) | ||||
| 90301-12018 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
1 | ||
| 12101 - PAN SUB-ASSY, OIL | ||||
| 12101-31101 |
2GRFSE..GRL10..8FC;2GRFXE,4GRFSE..GRL11,GWL10 |
1 | ||
| 12101A - PLUG(FOR OIL PAN DRAIN) | ||||
| 90341-12012 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
1 | ||
| 12101B - GASKET(FOR OIL PAN DRAIN PLUG) | ||||
| 90430-12031 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
1 | ||
| 12101C - RING, O(FOR OIL PAN) | ||||
| 12151-31010 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
2 | ||
| 12102A - PAN SUB-ASSY, OIL, NO.2 | ||||
| 12102-31030 |
2GRFSE..GRL10..8FC;2GRFXE,4GRFSE..GRL11,GWL10 |
1 | ||
| 12121 - PLATE, OIL PAN BAFFLE, NO.1 | ||||
| 12121-31080 |
2GR#..GRL15,GWL10;2GRFSE..GRL10..8FC |
1 | ||
| 12142 - GUIDE, OIL LEVEL GAGE, NO.2 | ||||
| 12142-31050 |
2GRFXE..GWL10 |
1 | ||
| 12142A - RING, O(FOR OIL LEVEL GAGE GUIDE, NO.2) | ||||
| 96721-19010 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
1 | ||
| 15301 - GAGE SUB-ASSY, OIL LEVEL | ||||
| 15301-31120 |
2GRFXE..GWL10 |
1 | ||
| 15301A - RING, O(FOR OIL LEVEL GAGE) | ||||
| 96741-19005 |
2GRFSE..GRL10..8FC;2GR#,4GRFSE..GRL11,15,GWL10 |
1 | ||
| 15708 - NOZZLE SUB-ASSY, OIL, NO.1 | ||||
| 15708-31050 |
2GR#..GRL10,15,GWL10 |
3 | ||
| 15708-31030 |
2GR#..GRL15,GWL10;2GRFSE..GRL10..8FC |
3 | ||
| 28193 - INSULATOR, STARTER HOLE | ||||
| 28193-31010 |
2GRFXE..GWL10 |
1 | ||
| Common parts | ||||
| 90110-06018 | ||||
| 90110-06040 | ||||
| 90119-06938 | ||||
| 90126-06028 | ||||
| 90126-08047 | ||||
| 90179-06326 | ||||
| 90210-07006 | ||||
| 90910-02154 | ||||
| 91551-80616 | ||||
| 91551-F0825 | ||||
| 91551-F0845 | ||||
| 91551-G0845 | ||||
| 91551-L0830 | ||||
| 91551-L0845 | ||||
| 91671-80610 | ||||
| 91671-80612 | ||||
| 91671-80816 | ||||
| 94151-80600 | ||||
| 94151-80800 | ||||
