NCP110-AHXEK (2007)
Toyota Ist
(0707- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 85031B - VALVE SUB-ASSY, WASHER | ||||
| 85321-28020 |
NCP11#,ZSP110..CBU |
1 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-12320 |
NCP11#,ZSP110..CBU 角度 +2 |
2 | ||
| 85381-12300 |
NCP11#,ZSP110..CBU 角度 0 |
2 | ||
| 85381-12310 |
NCP11#,ZSP110..CBU 角度 −2 |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-12320 |
NCP11#,ZSP110..CBU 角度 +2 |
2 | ||
| 85381-12300 |
NCP11#,ZSP110..CBU 角度 0 |
2 | ||
| 85381-12310 |
NCP11#,ZSP110..CBU 角度 −2 |
2 | ||
| 85035 - NOZZLE SUB-ASSY, WASHER | ||||
| 85381-12320 |
NCP11#,ZSP110..CBU 角度 +2 |
2 | ||
| 85381-12300 |
NCP11#,ZSP110..CBU 角度 0 |
2 | ||
| 85381-12310 |
NCP11#,ZSP110..CBU 角度 −2 |
2 | ||
| 85310 - MOTOR AND PUMP ASSY, WINDSHIELD WASHER | ||||
| 85330-21010 |
NCP11#,ZSP110..CBU |
1 | ||
| 85330 - JAR ASSY, WINDSHIELD WASHER | ||||
| 85315-52170 |
NCP11#,ZSP110..CBU |
1 | ||
| 85332 - CAP, WINDSHIELD WASHER JAR | ||||
| 85316-26030 |
NCP11#,ZSP110..CBU |
1 | ||
| 85336J - PROTECTOR, WASHER JAR | ||||
| 85336-60300 |
NCP11#,ZSP110..CBU |
1 | ||
| 85348 - JOINT, WINDSHIELD WASHER HOSE, NO.1 | ||||
| 85349-89122 |
NCP11#,ZSP110..CBU |
1 | ||
| 85348D - JOINT, WINDSHIELD WASHER ELBOW, NO.1 | ||||
| 85377-50110 |
NCP11#,ZSP110..CBU |
1 | ||
| 85371 - HOSE, WINDSHIELD WASHER (FROM MOTOR TO JOINT) | ||||
| 90099-33080 |
NCP11#,ZSP110..CBU *H,L=720 |
1 | ||
| 85372B - HOSE, WINDSHIELD WASHER (FROM JOINT TO JOINT), NO.2 | ||||
| 90446-07001 |
NCP11#,ZSP110..CBU *H,L=1100 |
1 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90446-07001 |
NCP11#,ZSP110..CBU *H,L=140 |
1 | ||
| 90099-33080 |
NCP11#,ZSP110..CBU *H,L=325 |
6 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90446-07001 |
NCP11#,ZSP110..CBU *H,L=140 |
1 | ||
| 90099-33080 |
NCP11#,ZSP110..CBU *H,L=325 |
6 | ||
| 85373 - HOSE, WINDSHIELD WASHER (FROM JOINT TO NOZZLE) | ||||
| 90446-07001 |
NCP11#,ZSP110..CBU *H,L=140 |
1 | ||
| 90099-33080 |
NCP11#,ZSP110..CBU *H,L=325 |
6 | ||
| 85387 - CLAMP NO.1 (FOR WINDSEIELD WASHER) | ||||
| 85387-22410 |
NCP11#,ZSP110..CBU |
1 | ||
| 85389B - PROTECTOR, WINDSHIELD WASHER | ||||
| 85389-22660 |
NCP11#,ZSP110..CBU |
1 | ||
| Common parts | ||||
| 82711-1E150 | ||||
| 85371-52060 | ||||
| 85387-52410 | ||||
| 85388-52410 | ||||
| 90119-06767 | ||||
| 90469-07011 | ||||
| Linked diagrams | ||||
| 8504 | ||||
