YN105-PRMSS (1988)
Toyota Hilux
(8809- )TW1
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 63102A - PANEL SUB-ASSY, WINDSHIELD HEADER | ||||
| 63102-89108 |
LN106,107,108,109,112,85,86,YN105,107,85,86..TW1 |
1 | ||
| 63103A - REINFORCEMENT SUB-ASSY, ROOF PANEL | ||||
| 63103-89107 |
LN106,107,108,109,112,85,86,YN105,107,85,86..TW1 |
2 | ||
| 63103A - REINFORCEMENT SUB-ASSY, ROOF PANEL | ||||
| 63103-89107 |
LN106,107,108,109,112,85,86,YN105,107,85,86..TW1 |
2 | ||
| 63105D - FRAME SUB-ASSY, BACK WINDOW, UPPER | ||||
| 63105-89110 |
LN106,107,108,109,112,85,86,YN105,107,85,86..TW1 |
1 | ||
| 63111 - PANEL, ROOF | ||||
| 63111-89122 |
LN106,107,108,109,112,85,86,YN105,107,85,86..TW1 |
1 | ||
| 64111A - PANEL, BACK | ||||
| 64101-89149 |
LN106,107,108,109,112,85,86,YN105,107,85,86..TW1 |
1 | ||
| 64101-89138 |
LN106,85,YN105,85..TW1 |
1 | ||
| 64122A - BAFFLE, DUST REAR BODY | ||||
| 64122-89102 |
LN106,85,86,YN85,86..TW1;LN100,107,108,109,112,80,81,YN10#,80,81 |
1 | ||
| 64807A - GLASS SUB-ASSY, BACK WINDOW SLIDE, RH | ||||
| 64807-89137 |
LN100,106,107,108,85,86,YN10#,80,85,86..SDX,SR,SSR *TT,厚さ=3.5,ﾌﾞﾙｰ |
1 | ||
| 64808 - CHANNEL SUB-ASSY, BACK WINDOW SLIDE GLASS | ||||
| 64808-89105 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 64809 - GLASS SUB-ASSY, BACK WINDOW SLIDE, LH | ||||
| 64809-89103 |
LN100,106,107,108,85,86,YN10#,80,85,86..SDX,SR,SSR *TT,厚さ=3.5,ﾌﾞﾙｰ |
1 | ||
| 64810 - WINDOW ASSY, BACK | ||||
| 64810-89110 |
LN100,106,107,108,85,86,YN10#,80,85,86..SDX,SR,SSR *TT,厚さ=3.5,ﾌﾞﾙｰ |
1 | ||
| 64812C - WEATHERSTRIP, BACK WINDOW GLASS | ||||
| 64812-89109 |
LN10#,YN10#..SR,SSR |
1 | ||
| 64812C - WEATHERSTRIP, BACK WINDOW GLASS | ||||
| 64812-89109 |
LN10#,YN10#..SR,SSR |
1 | ||
| 64813 - GLASS, BACK WINDOW CORNER, RH | ||||
| 64813-89102 |
LN100,106,107,108,85,86,YN10#,80,85,86..SDX,SR,SSR *TT,厚さ=3.5 |
1 | ||
| 64814 - GLASS, BACK WINDOW CORNER, LH | ||||
| 64814-89102 |
LN100,106,107,108,85,86,YN10#,80,85,86..SDX,SR,SSR *TT,厚さ=3.5 |
1 | ||
| 64818 - SPACER, BACK WINDOW GLASS | ||||
| 64818-89101 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64825 - RUN, BACK WINDOW CHANNEL, UPPER | ||||
| 64825-89101 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 64826 - RUN, BACK WINDOW CHANNEL, LOWER | ||||
| 64826-89101 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 64831 - WEATHERSTRIP, BACK WINDOW GLASS | ||||
| 64831-89110 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64831 - WEATHERSTRIP, BACK WINDOW GLASS | ||||
| 64831-89110 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64833A - WEATHERSTRIP, BACK WINDOW CENTER CHANNEL | ||||
| 64833-89114 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 64834D - WEATHERSTRIP, BACK WINDOW SLIDE GLASS | ||||
| 64834-89101 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64834D - WEATHERSTRIP, BACK WINDOW SLIDE GLASS | ||||
| 64834-89101 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64835A - WEATHERSTRIP, BACK WINDOW GLASS, CENTER | ||||
| 64835-89101 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 64837C - WEATHERSTRIP, BACK WINDOW CORNER GLASS | ||||
| 64837-89101 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64837C - WEATHERSTRIP, BACK WINDOW CORNER GLASS | ||||
| 64837-89101 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64839A - PACKING, BACK WINDOW | ||||
| 64839-89105 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 64851 - STOP, BACK WINDOW SLIDE GLASS | ||||
| 64851-89103 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 64883 - FRAME, BACK WINDOW | ||||
| 64881-89104 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64883 - FRAME, BACK WINDOW | ||||
| 64881-89104 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 64885A - CHANNEL, BACK WINDOW GLASS, RH | ||||
| 64885-89102 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 64886 - CHANNEL, BACK WINDOW GLASS, LH | ||||
| 64886-89102 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 69370A - LOCK ASSY, BACK WINDOW | ||||
| 69370-89103 |
LN10#,85,YN10#,8#..SDX,SR,SSR |
1 | ||
| 69374 - CATCH, BACK WINDOW LOCK | ||||
| 69374-89103 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
1 | ||
| 69375A - RETAINER, BACK WINDOW LOCK | ||||
| 69375-89103 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| 69376B - PACKING, BACK WINDOW LOCK | ||||
| 69376-89103 |
LN10#,112,85,86,YN10#,80,85,86..SDX,SR,SSR,SSRX |
2 | ||
| Common parts | ||||
| 90161-40013 | ||||
| 90333-35002 | ||||
| 90467-07050 | ||||
| 90950-01506 | ||||
| 93520-24012 | ||||
| 93540-64012 | ||||
