RZN147-TRMDE (1997)
Toyota Hilux
(0208- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 87116A - SPRING, HOLDING (FOR COOLER UNIT CASE) | ||||
| 87116-14010 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 87116-14010 |
RZN147,152 |
1 | ||
| 87138C - RESISTOR, BLOWER | ||||
| 87138-35080 |
RZN147,152,169,174 |
1 | ||
| 87138-35080 |
RZN147,152 |
1 | ||
| 88501 - EVAPORATOR SUB-ASSY, COOLER, NO.1 | ||||
| 88501-35060 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88501-35060 |
LN147,167,172,RZN147,152,169,174..T1,TW1 |
1 | ||
| 88502 - CASE SUB-ASSY, COOLING UNIT | ||||
| 88502-35080 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88502-35080 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88502A - CASE SUB-ASSY, COOLING UNIT | ||||
| 88502-35100 |
RZN147 |
1 | ||
| 88502-35100 |
RZN147,152 |
1 | ||
| 88521-35260 |
RZN147,152 |
1 | ||
| 88510 - UNIT ASSY, COOLER | ||||
| 88510-35690 |
RZN147,152 |
1 | ||
| 88510-35630 |
RZN147,167 |
1 | ||
| 88510-3D040 |
RZN147,152 |
1 | ||
| 88510-3D020 |
RZN147,152 |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90480-24008 |
LN147,16#,17#,RZN147,152,16#,174 |
1 | ||
| 88515 - VALVE, COOLER EXPANSION | ||||
| 88515-35010 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88539 - HOSE, COOLER UNIT DRAIN, NO.1 | ||||
| 88539-35020 |
LN147,16#,17#,RZN147,152,16#,174 ｱﾘ(ｴｱ ｺﾝﾃﾞｲｼﾖﾅ (ﾃﾞｲ-ﾗ- ｵﾌﾟｼﾖﾝ)) |
1 | ||
| 88539G - GROMMET (FOR COOLER UNIT DRAIN HOSE) | ||||
| 90480-26022 |
LN147,16#,17#,RZN147,152,16#,174 ｱﾘ(ｴｱ ｺﾝﾃﾞｲｼﾖﾅ (ﾃﾞ-ﾗ- ｵﾌﾟｼﾖﾝ)) |
1 | ||
| 88578B - PACKING, COOLING UNIT, NO.1 | ||||
| 88578-35040 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88578C - PACKING, COOLING UNIT, NO.2 | ||||
| 88578-35050 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88605 - HARNESS SUB-ASSY, COOLER WIRING, NO.1 | ||||
| 88605-35360 |
RZN147,152,167 |
1 | ||
| 88605-35360 |
RZN147,152 |
1 | ||
| 88625 - THERMISTOR, COOLER, NO.1 | ||||
| 88625-35040 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88625-35040 |
RZN147,152 |
1 | ||
| 88625-16210 |
LN147,16#,17#,RZN147,167 |
1 | ||
| 88650 - AMPLIFIER ASSY, COOLER STABILIZER | ||||
| 88650-35080 |
RZN147,152 |
1 | ||
| 88650-35080 |
RZN147,152 |
1 | ||
| 88716F - PIPE, COOLER REFRIGERANT LIQUID, F | ||||
| 88726-35050 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88726-35050 |
LN147,167,172,RZN147,152,169,174..T1,TW1 |
1 | ||
| 88891S - COVER, COOLER, NO.1 | ||||
| 88891-35010 |
RZN147,152,169,174 |
1 | ||
| 88891-35010 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| Common parts | ||||
| 88519-87301 | ||||
| 88578-30360 | ||||
| 88714-35040 | ||||
| 88899-35040 | ||||
| 90099-00968 | ||||
| 90099-14119 | ||||
| 90099-14120 | ||||
| 90159-60195 | ||||
| 90183-05094 | ||||
| 93568-55016 | ||||
(9708-0208)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 87116A - SPRING, HOLDING (FOR COOLER UNIT CASE) | ||||
| 87116-14010 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 87116-14010 |
RZN147,152 |
1 | ||
| 87138C - RESISTOR, BLOWER | ||||
| 87138-35080 |
RZN147,152,169,174 |
1 | ||
| 87138-35080 |
RZN147,152 |
1 | ||
| 88501 - EVAPORATOR SUB-ASSY, COOLER, NO.1 | ||||
| 88501-35060 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88501-35060 |
LN147,167,172,RZN147,152,169,174..T1,TW1 |
1 | ||
| 88502 - CASE SUB-ASSY, COOLING UNIT | ||||
| 88502-35080 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88502-35080 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88502A - CASE SUB-ASSY, COOLING UNIT | ||||
| 88502-35100 |
RZN147 |
1 | ||
| 88502-35100 |
RZN147,152 |
1 | ||
| 88521-35260 |
RZN147,152 |
1 | ||
| 88510 - UNIT ASSY, COOLER | ||||
| 88510-35690 |
RZN147,152 |
1 | ||
| 88510-35630 |
RZN147,167 |
1 | ||
| 88510-3D040 |
RZN147,152 |
1 | ||
| 88510-3D020 |
RZN147,152 |
1 | ||
| 88510R - GROMMET (FOR COOLER UNIT) | ||||
| 90480-24008 |
LN147,16#,17#,RZN147,152,16#,174 |
1 | ||
| 88515 - VALVE, COOLER EXPANSION | ||||
| 88515-35010 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88539 - HOSE, COOLER UNIT DRAIN, NO.1 | ||||
| 88539-35020 |
LN147,16#,17#,RZN147,152,16#,174 ｱﾘ(ｴｱ ｺﾝﾃﾞｲｼﾖﾅ (ﾃﾞｲ-ﾗ- ｵﾌﾟｼﾖﾝ)) |
1 | ||
| 88539G - GROMMET (FOR COOLER UNIT DRAIN HOSE) | ||||
| 90480-26022 |
LN147,16#,17#,RZN147,152,16#,174 ｱﾘ(ｴｱ ｺﾝﾃﾞｲｼﾖﾅ (ﾃﾞ-ﾗ- ｵﾌﾟｼﾖﾝ)) |
1 | ||
| 88578B - PACKING, COOLING UNIT, NO.1 | ||||
| 88578-35040 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88578C - PACKING, COOLING UNIT, NO.2 | ||||
| 88578-35050 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88605 - HARNESS SUB-ASSY, COOLER WIRING, NO.1 | ||||
| 88605-35360 |
RZN147,152,167 |
1 | ||
| 88605-35360 |
RZN147,152 |
1 | ||
| 88625 - THERMISTOR, COOLER, NO.1 | ||||
| 88625-35040 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88625-35040 |
RZN147,152 |
1 | ||
| 88625-16210 |
LN147,16#,17#,RZN147,167 |
1 | ||
| 88650 - AMPLIFIER ASSY, COOLER STABILIZER | ||||
| 88650-35080 |
RZN147,152 |
1 | ||
| 88650-35080 |
RZN147,152 |
1 | ||
| 88716F - PIPE, COOLER REFRIGERANT LIQUID, F | ||||
| 88726-35050 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| 88726-35050 |
LN147,167,172,RZN147,152,169,174..T1,TW1 |
1 | ||
| 88891S - COVER, COOLER, NO.1 | ||||
| 88891-35010 |
RZN147,152,169,174 |
1 | ||
| 88891-35010 |
LN147,167,172,RZN147,152,169,174 |
1 | ||
| Common parts | ||||
| 88519-87301 | ||||
| 88569-87207 | ||||
| 88578-30360 | ||||
| 88714-28010 | ||||
| 88714-35040 | ||||
| 88714-87524 | ||||
| 88714-89105 | ||||
| 88714-95J03 | ||||
| 90099-00968 | ||||
| 90099-14119 | ||||
| 90099-14120 | ||||
| 90159-60195 | ||||
| 90183-05094 | ||||
| 93568-55016 | ||||
