RN30-JDSJ (1978)

Toyota Hilux

Production Aug 1978 - Dec 1979
Engine 12RJ
Transmission 4H MTM
Displacement 2500cc
Power 168 HP (125 kW)

(7808- )

Click highlighted areas on diagram

diagram 37199 74518 74519 74519 74533 74541 74562 74565 74571 74574 74579
Part # Description Qty Price
74518 - PLATE, MAINTENANCE CAUTION
74518-22021

LN30,40,RN3#,4#

 1
74519 - PLATE, FUEL CAUTION
74559-14010

RN3#,4#

 1
74519 - PLATE, FUEL CAUTION
74559-14010

RN3#,4#

 1
74541 - PLATE, TIRE PRESSURE CAUTION
74552-35060

RN30,40

 1
74562 - PLATE, EMISSION CONTROL SYSTEM INFORMATION
74562-26041

RN30,40

 1
74565 - PLATE, TIRE CARRIER CAUTION
74544-35050

LN3#,4#,RN3#,4#

 1
74571 - PLATE, BRAKE FLUID CAUTION
74571-22011

LN3#,4#,RN3#,4#

 1
74574 - PLATE, NOISE IDENTIFICATION
74563-26020

RN30,40

 1
