LN56-PF (1983)

Toyota Hilux

Production Nov 1983 - Aug 1988
Engine 2L
Transmission 4FC ATM
Displacement 2500cc
Power 168 HP (125 kW)

(8311- )

Click highlighted areas on diagram

diagram 11283 11283 11284 11289 11291 11293 11294 11296 11297 11297A 11299 11299A 17700C 17792
Part # Description Qty Price
11293 - PLATE, ENGINE CAUTION & ENGINE NAME
11293-54030

2L..LN51,56,6#

 1
11294 - PLATE, ENGINE CAUTION, NO.2
11294-54040

L,2L#..LN5#,6#

 1
11294-56010

L,2L..LN5#,6#

COLD SPEC

 1
11296 - PLATE, TIMING BELT CAUTION
11296-54010

L,2L..LN5#,6#

 1
17700C - PLATE, AIR CLEANER CAUTION (FOR ENGINE MODEL)
90917-07095

L,2L,2YJ,3YJ..LN5#,6#,YN5#,6#

 1
