LN106-PRMSS (1988)
Toyota Hilux
(8809- )3L
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 16261 - HOSE, WATER BY-PASS | ||||
| 16261-54080 |
2LT#,2L,3L..LN10#,13#,8# |
1 | ||
| 16261-54080 |
2L,3L..LN100,106,107,109,131,8# |
1 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 90467-15004 |
2L#,3L..LN10#,13#,8# |
2 | ||
| 90467-15022 |
2LT#,2L,3L..LN100,106,107,109,13#,8# |
2 | ||
| 16261A - CLAMP OR CLIP, HOSE(FOR WATER BY-PASS HOSE) | ||||
| 90467-15004 |
2L#,3L..LN10#,13#,8# |
2 | ||
| 90467-15022 |
2LT#,2L,3L..LN100,106,107,109,13#,8# |
2 | ||
| 16261B - UNION(FOR WATER BY-PASS HOSE) | ||||
| 90404-54037 |
2LT#,2L,3L..LN10#,13#,8# |
1 | ||
| 16264 - HOSE, WATER BY-PASS, NO.2 | ||||
| 16264-54070 |
2LT#,2L,3L..LN10#,13#,8# |
1 | ||
| 16264A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) | ||||
| 90467-15022 |
2LT#,2L,3L..LN100,106,107,109,13#,8# |
2 | ||
| 90467-15004 |
2L#,3L..LN10#,13#,8# |
2 | ||
| 16264A - CLAMP OR CLIP(FOR WATER BY-PASS HOSE NO.2) | ||||
| 90467-15022 |
2LT#,2L,3L..LN100,106,107,109,13#,8# |
2 | ||
| 90467-15004 |
2L#,3L..LN10#,13#,8# |
2 | ||
| 16331 - OUTLET, WATER | ||||
| 16331-54090 |
2L,3L..LN100,106,107,109,131,8# |
1 | ||
| 16331A - THERMOSTAT | ||||
| 90916-03099 |
2LT#,2L,3L..LN10#,13#,8# *WAX 88−100 |
1 | ||
| 16333 - HOUSING, WATER OUTLET | ||||
| 16303-54030 |
2L,3L..LN10#,131,8# |
1 | ||
| 16333-54111 |
2L,3L..LN10#,131,8# |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-54030 |
2L,3L..LN10#,131,8# |
1 | ||
| 16341 - GASKET, WATER OUTLET | ||||
| 16341-54030 |
2L,3L..LN10#,131,8# |
1 | ||
| 16343 - GASKET, WATER OUTLET HOUSING | ||||
| 16343-54030 |
2LT#,2L,3L..LN10#,13#,8# |
1 | ||
| 16361 - FAN | ||||
| 16361-54040 |
3L..LN100,106,107,109,81,86 |
1 | ||
| 16361-54040 |
2L,3L..LN10#,85..4FC,5F |
1 | ||
| 16381 - BAR, FAN BELT ADJUSTING | ||||
| 16381-54060 |
2L#,3L..LN10#,13#,8# |
1 | ||
| 16381-54060 |
2L,3L..LN100,106,107,109,8# |
1 | ||
| 16400 - RADIATOR ASSY | ||||
| 16400-54640 |
3L..LN100,106,107,109,131 |
1 | ||
| 16400B - PLUG, RADIATOR DRAIN COCK | ||||
| 90910-09054 |
2L,3L..LN10#,131,8# |
1 | ||
| 90910-09054 |
2L#,3L..LN10#,13#,8# |
1 | ||
| 16400F - PACKING(FOR RADIATOR DRAIN COCK) | ||||
| 96711-19007 |
2L#,3L..LN10#,13#,8# |
1 | ||
| 96711-19007 |
2LT#,2L,3L..LN10#,112,13#,8# |
1 | ||
| 96711-19007 |
2L,3L..LN10#,131,8# |
1 | ||
| 16401 - CAP SUB-ASSY, RADIATOR | ||||
| 16401-63010 |
2L,3L..LN10#,131,8# |
1 | ||
| 16401-63010 |
2L#,3L..LN10#,13#,8# |
1 | ||
| 16401-63010 |
2LT#,2L,3L..LN10#,112,13#,8# |
1 | ||
| 16470 - TANK ASSY, RADIATOR RESERVE | ||||
| 16470-54120 |
2L,3L..LN10#,131,8# |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12078 |
2LT#,2L,3L..LN10#,13#,8# *H,L=220,NO.2 |
1 | ||
| 90445-12078 |
2L,3L..LN10#,131,8# *H,L=260,NO.1 |
1 | ||
| 16470A - HOSE OR PIPE(FOR RADIATOR RESERVE TANK) | ||||
| 90445-12078 |
2LT#,2L,3L..LN10#,13#,8# *H,L=220,NO.2 |
1 | ||
| 90445-12078 |
2L,3L..LN10#,131,8# *H,L=260,NO.1 |
1 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
2LT#,2L,3L..LN10#,112,13#,8# |
2 | ||
| 16470B - CLAMP OR CLIP(FOR RADIATOR RESERVE TANK HOSE) | ||||
| 90467-11085 |
2LT#,2L,3L..LN10#,112,13#,8# |
2 | ||
| 16471 - CAP SUB-ASSY, RESERVE TANK | ||||
| 16405-54180 |
2L,3L..LN100,106,107,109,131,8# |
1 | ||
| 16472 - HOSE, BREATHER | ||||
| 85338-71030 |
2LT#,2L,3L..LN10#,112,13#,8# |
1 | ||
| 16571 - HOSE, RADIATOR, INLET | ||||
| 16571-54270 |
2L,3L..LN100,106,107,109,131,8# |
1 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37003 |
2LT#,2L,3L..LN10#,112,13#,8# |
2 | ||
| 16571A - CLAMP OR CLIP, HOSE(FOR RADIATOR INLET) | ||||
| 90467-37003 |
2LT#,2L,3L..LN10#,112,13#,8# |
2 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16573-54080 |
3L..LN10# NO.2 |
1 | ||
| 16572-54270 |
2LT#,3L..LN10#,112,13# NO.1 |
1 | ||
| 16573-54081 |
2LT#,3L..LN10#,112,13# NO.2 |
1 | ||
| 16572 - HOSE, RADIATOR, OUTLET | ||||
| 16573-54080 |
3L..LN10# NO.2 |
1 | ||
| 16572-54270 |
2LT#,3L..LN10#,112,13# NO.1 |
1 | ||
| 16573-54081 |
2LT#,3L..LN10#,112,13# NO.2 |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 90467-41001 |
2LT#,2L,3L..LN10#,112,13#,8# ｴﾝｼﾞﾝ側 |
1 | ||
| 90467-37002 |
2LT#,2L,3L..LN10#,112,13#,8# ﾗｼﾞｴｰﾀ側 |
1 | ||
| 16572A - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.1) | ||||
| 90467-41001 |
2LT#,2L,3L..LN10#,112,13#,8# ｴﾝｼﾞﾝ側 |
1 | ||
| 90467-37002 |
2LT#,2L,3L..LN10#,112,13#,8# ﾗｼﾞｴｰﾀ側 |
1 | ||
| 16572C - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.2) | ||||
| 90467-37002 |
2LT,3L..LN10#,13# |
2 | ||
| 16572C - CLAMP OR CLIP, HOSE(FOR RADIATOR OUTLET NO.2) | ||||
| 90467-37002 |
2LT,3L..LN10#,13# |
2 | ||
| 16577 - PIPE, RADIATOR, NO.7 | ||||
| 16577-54120 |
3L..LN10# |
1 | ||
| 16577-54121 |
2LT#,3L..LN100,106,107,109,13# |
1 | ||
| 16701 - SHROUD SUB-ASSY, FAN | ||||
| 16711-54290 |
2LT#,3L..LN100,106,107,109,13# |
1 | ||
| 16712 - SHROUD, FAN, NO.2 | ||||
| 16712-54200 |
2LT#,3L..LN100,106,107,109,13# |
1 | ||
| Common parts | ||||
| 90099-04428 | ||||
| 90116-08366 | ||||
| 90119-08127 | ||||
| 90119-08689 | ||||
| 90119-08694 | ||||
| 90119-12224 | ||||
| 90179-06293 | ||||
| 90179-08150 | ||||
| 90480-25025 | ||||
| 90929-01219 | ||||
| 91626-60616 | ||||
| 91626-60618 | ||||
| 91626-60818 | ||||
| 91666-60618 | ||||
| 94185-60600 | ||||
