YH51G-SG (1982)
Toyota Hiace Van,Wagon
(8212- )2Y,3Y
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-71011 |
3YU..YH51,61 |
1 | ||
| 17303-71010 |
3YU..YH51,61 |
1 | ||
| 17303-71051 |
2Y,3Y..YH5#,61,71 |
1 | ||
| 17303E - HOSE, NO.1(FOR AIR PIPE) | ||||
| 90445-14104 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 17630 - VALVE ASSY, AIR CONTROL | ||||
| 17630-28020 |
2Y,3Y#..YH5#,6#,71 W/PS |
1 | ||
| 17650 - VALVE ASSY, VACUUM SWITCHING | ||||
| 89570-28050 |
2Y,3Y..YH50,51,61,71 |
1 | ||
| 17810A - FILTER ASSY, AIR | ||||
| 90925-06007 |
2Y,3Y#..YH5#,6#,71 W/PS |
1 | ||
| 21381 - BIMETAL, THERMOSTATIC | ||||
| 21381-71010 |
2Y,3Y#..YH5#,61,71 |
1 | ||
| 21381-71040 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 21908 - ACTUATOR SUB-ASSY, IDLE-UP | ||||
| 21908-71010 |
2Y,3Y#..YH5#,6#,71 W/PS |
1 | ||
| 21908-71010 |
2Y,3Y,3YJ..YH5#,6#,71 W/PS |
1 | ||
| 23262 - VALVE, BIMETAL VACUUM SWITCHING, NO.1 | ||||
| 90925-05041 |
2Y,3Y..YH50,51,61,71 |
1 | ||
| 23265 - FILTER, GAS, NO.1 | ||||
| 90917-11024 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01027 |
3YU..YH51,61 |
1 | ||
| 23288 - JET, NO.1 | ||||
| 90925-04006 |
2Y,3Y..YH5#,61,71 |
1 | ||
| 23289 - JET, NO.2 | ||||
| 90925-04004 |
2Y,3Y..YH50,51,61,71 |
1 | ||
| Common parts | ||||
| 90339-03002 | ||||
| 90464-00074 | ||||
| 90464-00081 | ||||
| 90464-00082 | ||||
| 90464-00301 | ||||
| 91615-40816 | ||||
| 91651-40814 | ||||
| 93381-16014 | ||||
| 95411-10030 | ||||
| 95411-10060 | ||||
| 95411-10130 | ||||
| 95411-10160 | ||||
| 95411-10230 | ||||
| 95411-10430 | ||||
| 95411-10530 | ||||
| 95411-10630 | ||||
| 95411-10730 | ||||
| 95411-10830 | ||||
| 95411-10930 | ||||
| 95411-11230 | ||||
| 95411-19930 | ||||
| 95411-19960 | ||||
| 96132-30800 | ||||
(8212-8508)3YU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-71011 |
3YU..YH51,61 |
1 | ||
| 17303-71010 |
3YU..YH51,61 |
1 | ||
| 17303-71051 |
2Y,3Y..YH5#,61,71 |
1 | ||
| 17303E - HOSE, NO.1(FOR AIR PIPE) | ||||
| 90445-14104 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 17341B - HOSE, NO.1(FOR AIR INJECTION SYSTEM) | ||||
| 17341-73010 |
3YU..YH51,61 |
1 | ||
| 17630 - VALVE ASSY, AIR CONTROL | ||||
| 17630-28020 |
2Y,3Y#..YH5#,6#,71 W/PS |
1 | ||
| 17810A - FILTER ASSY, AIR | ||||
| 90925-06007 |
2Y,3Y#..YH5#,6#,71 W/PS |
1 | ||
| 21381 - BIMETAL, THERMOSTATIC | ||||
| 21381-71010 |
2Y,3Y#..YH5#,61,71 |
1 | ||
| 21381-71040 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 21908 - ACTUATOR SUB-ASSY, IDLE-UP | ||||
| 21908-71010 |
2Y,3Y#..YH5#,6#,71 W/PS |
1 | ||
| 21908-71010 |
2Y,3Y,3YJ..YH5#,6#,71 W/PS |
1 | ||
| 23265 - FILTER, GAS, NO.1 | ||||
| 90917-11024 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01027 |
3YU..YH51,61 |
1 | ||
| 23283 - VALVE, VACUUM TRANSMITTING, NO.3 | ||||
| 90925-01027 |
3YU..YH51,61 |
1 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10049 |
3YU..YH51,61 |
1 | ||
| 25730 - VALVE ASSY, ELECTRIC BLEED AIR CONTROL | ||||
| 25730-73010 |
3YU..YH51,61 |
1 | ||
| 25810 - VALVE ASSY, BIMETAL | ||||
| 25810-27010 |
3YU..YH51,61 NO.1 |
1 | ||
| 25820-37010 |
3YU..YH51,61 NO.2 |
1 | ||
| 25810 - VALVE ASSY, BIMETAL | ||||
| 25810-27010 |
3YU..YH51,61 NO.1 |
1 | ||
| 25820-37010 |
3YU..YH51,61 NO.2 |
1 | ||
| Common parts | ||||
| 90119-08103 | ||||
| 90339-03002 | ||||
| 90413-04005 | ||||
| 90464-00074 | ||||
| 90464-00079 | ||||
| 90464-00081 | ||||
| 90464-00082 | ||||
| 90464-00301 | ||||
| 91651-40814 | ||||
| 93381-16014 | ||||
| 95411-10030 | ||||
| 95411-10060 | ||||
| 95411-10130 | ||||
| 95411-10160 | ||||
| 95411-10230 | ||||
| 95411-10330 | ||||
| 95411-10430 | ||||
| 95411-10530 | ||||
| 95411-10730 | ||||
| 95411-10830 | ||||
| 95411-11030 | ||||
| 95411-11130 | ||||
| 95411-11230 | ||||
| 96132-30800 | ||||
| 96132-31000 | ||||
(8508- )3YU
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 17303B - PIPE SUB-ASSY, AIR, NO.1 | ||||
| 17303-71011 |
3YU..YH51,61 |
1 | ||
| 17303-71010 |
3YU..YH51,61 |
1 | ||
| 17303-71051 |
2Y,3Y..YH5#,61,71 |
1 | ||
| 17303E - HOSE, NO.1(FOR AIR PIPE) | ||||
| 90445-14104 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 17341B - HOSE, NO.1(FOR AIR INJECTION SYSTEM) | ||||
| 17341-73010 |
3YU..YH51,61 |
1 | ||
| 17630 - VALVE ASSY, AIR CONTROL | ||||
| 17630-28020 |
2Y,3Y#..YH5#,6#,71 W/PS |
1 | ||
| 17810A - FILTER ASSY, AIR | ||||
| 90925-06007 |
2Y,3Y#..YH5#,6#,71 W/PS |
1 | ||
| 21381 - BIMETAL, THERMOSTATIC | ||||
| 21381-71010 |
2Y,3Y#..YH5#,61,71 |
1 | ||
| 21381-71040 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 23265 - FILTER, GAS, NO.1 | ||||
| 90917-11024 |
2Y,3Y#..YH5#,6#,71 |
1 | ||
| 23281 - VALVE, VACUUM TRANSMITTING, NO.1 | ||||
| 90925-01027 |
3YU..YH51,61 |
1 | ||
| 23283 - VALVE, VACUUM TRANSMITTING, NO.3 | ||||
| 90925-01027 |
3YU..YH51,61 |
1 | ||
| 23285A - VALVE, CHECK, NO.1 | ||||
| 90917-10049 |
3YU..YH51,61 |
1 | ||
| 23289B - JET, NO.3 | ||||
| 90925-04006 |
3YU..YH51,61 |
1 | ||
| 90925-04004 |
3YU..YH51,61 |
1 | ||
| 25730 - VALVE ASSY, ELECTRIC BLEED AIR CONTROL | ||||
| 25730-73010 |
3YU..YH51,61 |
1 | ||
| 25810 - VALVE ASSY, BIMETAL | ||||
| 25810-27010 |
3YU..YH51,61 NO.1 |
1 | ||
| 25820-37010 |
3YU..YH51,61 NO.2 |
1 | ||
| 25810 - VALVE ASSY, BIMETAL | ||||
| 25810-27010 |
3YU..YH51,61 NO.1 |
1 | ||
| 25820-37010 |
3YU..YH51,61 NO.2 |
1 | ||
| Common parts | ||||
| 90119-08103 | ||||
| 90413-04004 | ||||
| 90413-04005 | ||||
| 90464-00081 | ||||
| 90464-00082 | ||||
| 90464-00301 | ||||
| 91651-40814 | ||||
| 95411-10060 | ||||
| 95411-10130 | ||||
| 95411-10230 | ||||
| 95411-10330 | ||||
| 95411-10730 | ||||
| 95411-10830 | ||||
| 95411-19930 | ||||
| 95411-19960 | ||||
| 96132-30800 | ||||
| 96132-31000 | ||||
| Linked diagrams | ||||
| 2103 | ||||
(8212- )2Y,3Y#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 95411-10030 | ||||
| 95411-10160 | ||||
| 95411-19995 | ||||
(8708-8808)2Y,3Y
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90339-03002 | ||||
| 90464-00074 | ||||
| 90464-00081 | ||||
| 90464-00082 | ||||
| 90464-00301 | ||||
| 90999-92002 | ||||
| 90999-92003 | ||||
| 91615-40816 | ||||
| 91651-40814 | ||||
| 93381-16014 | ||||
| 96132-30800 | ||||
(8708-8808)2Y,3Y
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90339-03002 | ||||
| 90339-03005 | ||||
| 90413-04005 | ||||
| 90464-00074 | ||||
| 90464-00082 | ||||
| 90999-92002 | ||||
| 90999-92003 | ||||
| 91615-40816 | ||||
| 91651-40814 | ||||
| 93381-16014 | ||||
