LH71B-QD (1987)
Toyota Hiace Van,Wagon
(8708- )LH51,61,71,YH50,51,52,6#,71
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04371 - SPIDER KIT, UNIVERSAL JOINT(FOR PROPELLER SHAFT) | ||||
| 04371-25010 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL |
2 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01148 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 4G,厚さ=2.0,ﾘﾔ |
1 | ||
| 90937-01150 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 8G,長さ=16.6,ﾘﾔ |
1 | ||
| 90937-01151 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 12G,長さ=24.9,ﾘﾔ |
1 | ||
| 90937-01147 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 2G,厚さ=2.0,ﾘﾔ |
1 | ||
| 90937-01149 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 6G,長さ=12.4,ﾘﾔ |
1 | ||
| 90937-01132 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 10G,長さ=20.7,ﾘﾔ |
1 | ||
| 90937-01152 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 14G,長さ=29.0,ﾘﾔ |
1 | ||
| 37101A - PIECE, BALANCE, NO.1 (FOR PROPELLER SHAFT) | ||||
| 90937-01148 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 4G,厚さ=2.0,ﾘﾔ |
1 | ||
| 90937-01150 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 8G,長さ=16.6,ﾘﾔ |
1 | ||
| 90937-01151 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 12G,長さ=24.9,ﾘﾔ |
1 | ||
| 90937-01147 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 2G,厚さ=2.0,ﾘﾔ |
1 | ||
| 90937-01149 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 6G,長さ=12.4,ﾘﾔ |
1 | ||
| 90937-01132 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 10G,長さ=20.7,ﾘﾔ |
1 | ||
| 90937-01152 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 14G,長さ=29.0,ﾘﾔ |
1 | ||
| 37110 - SHAFT ASSY, PROPELLER | ||||
| 37110-26141 |
LH71,YH71 |
1 | ||
| 37110A - BOLT (FOR PROPELLER SHAFT) | ||||
| 90105-10085 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 *10−1.00PX27−13 |
4 | ||
| 37110D - NUT (FOR PROPELLER SHAFT) | ||||
| 90179-10059 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 |
4 | ||
| 37110E - WASHER (FOR PROPELLER SHAFT) | ||||
| 90204-10002 |
LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71 |
4 | ||
| 37302 - YOKE SUB-ASSY, UNIVERSAL JOINT SLEEVE | ||||
| 37302-35010 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL |
1 | ||
| 37315 - YOKE, UNIVERSAL JOINT FLANGE | ||||
| 37315-35050 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL |
1 | ||
| 37331 - COVER, SLIDING SHAFT DUST | ||||
| 37331-30010 |
LH51,61,71,YH50,51,52,6#,71 |
1 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29070 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL 厚さ=2.375−2.425 |
8 | ||
| 90521-29072 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL 厚さ=2.475−2.525 |
8 | ||
| 90521-29071 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL 厚さ=2.425−2.475 |
8 | ||
| 37401A - RING, HOLE SNAP (FOR SPIDER BEARING) | ||||
| 90521-29070 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL 厚さ=2.375−2.425 |
8 | ||
| 90521-29072 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL 厚さ=2.475−2.525 |
8 | ||
| 90521-29071 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL 厚さ=2.425−2.475 |
8 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25020 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL |
8 | ||
| 37402 - BEARING SUB-ASSY, UNIVERSAL JOINT SPIDER | ||||
| 37402-25020 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL |
8 | ||
| 37434 - SEAL, UNIVERSAL JOINT SPIDER BEARING | ||||
| 37434-25010 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL |
8 | ||
| 37434 - SEAL, UNIVERSAL JOINT SPIDER BEARING | ||||
| 37434-25010 |
LH51,61,71,YH50,51,52,6#,71..CBR,DSL |
8 | ||
