LH66V-MEG (1987)

Toyota Hiace Van,Wagon

Production Aug 1987 - Aug 1989
Engine 2L
Transmission 5F MTM
Displacement 2500cc
Power 168 HP (125 kW)

(8708- )

Click highlighted areas on diagram

LPG PACKAGE

diagram 51902A 51910E 51911 51913A 51934C 51998 9011906042 9095001056 9165140620 9418040800 9461311001
Part # Description Qty Price
Common parts
90119-06042
90950-01056
91651-40620
94180-40800
94613-11001

(8708- )

Click highlighted areas on diagram

diagram 51900 51900 51908 51937B 51938 51943 51944 51955B 51956B 9010912015 9011908190 9011908190 9011908216 9020112581 9044017005 9165140820 9165140820
Part # Description Qty Price
51900 - CARRIER ASSY, SPARE WHEEL
51903-26280

LH66..05S;LH66..(DX,SGL)..08S

 1
51900 - CARRIER ASSY, SPARE WHEEL
51903-26280

LH66..05S;LH66..(DX,SGL)..08S

 1
51937B - PLATE, SPARE WHEEL CARRIER LOCK
51937-26010

LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71

 1
51938 - LOCK, SPARE WHEEL CARRIER
51938-28030

LH66..05S;LH66..(DX,SGL)..08S;LH5#,61,71,YH5#,6#,71

 1
51943 - BRACKET, SPARE WHEEL CARRIER, NO.1
51943-26070

LH66..(DX,SGL)..08S;LH6#,71,YH6#,71..(03S,05S,06S,09S,10S,15S)..ST

 1
51944 - BRACKET, SPARE WHEEL CARRIER, NO.2
51944-26090

LH66..(DX,SGL)..08S;LH6#,71,YH6#,71..(03S,05S,06S,09S,10S,15S)..ST

 1
51955B - HINGE, SPARE WHEEL CARRIER, NO.1
51955-26010

LH61,71,YH61..ST;LH66..(DX,SGL)..08S;LH5#,66,YH50,51,52,62,71..(COM,V)..(03S,05S,06S,09S,15S)

 1
51956B - HINGE, SPARE WHEEL CARRIER, NO.2
51956-26020

LH61,71,YH61..ST;LH66..(DX,SGL)..08S;LH5#,66,YH50,51,52,62,71..(COM,V)..(03S,05S,06S,09S,15S)

 1
Common parts
90109-12015
90119-08190
90119-08216
90201-12581
90440-17005
91651-40820
