LH80-MDL (1985)
Toyota Hiace Truck
ILLUST NO. 1 OF 2(8508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 51100 - FRAME ASSY | ||||
| 51001-26380 |
LH80..T2..ST |
1 | ||
| 51202 - CROSSMEMBER SUB-ASSY, FRAME, NO.1 | ||||
| 51201-26060 |
LH80,YH80 |
1 | ||
| 51203 - CROSSMEMBER SUB-ASSY, FRAME, NO.2 | ||||
| 51203-26110 |
LH80 |
1 | ||
| 51204 - CROSSMEMBER SUB-ASSY, FRAME, NO.3 | ||||
| 51203-26120 |
LH80,YH80 |
1 | ||
| 51205 - CROSSMEMBER SUB-ASSY, FRAME, NO.4 | ||||
| 51204-26030 |
LH80,YH80..T2..ST |
1 | ||
| 51209C - CROSSMEMBER SUB-ASSY, FRAME, REAR | ||||
| 51209-26030 |
LH80,YH80..ST |
1 | ||
ILLUST NO. 2 OF 2(8508- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 51203 - CROSSMEMBER SUB-ASSY, FRAME, NO.2 | ||||
| 51203-26110 |
LH80 |
1 | ||
| 51225B - BRACKET, FRONT SUSPENSION MEMBER, RH | ||||
| 51225-26010 |
LH80,YH80 |
2 | ||
| 51225B - BRACKET, FRONT SUSPENSION MEMBER, RH | ||||
| 51225-26010 |
LH80,YH80 |
2 | ||
| 51225B - BRACKET, FRONT SUSPENSION MEMBER, RH | ||||
| 51225-26010 |
LH80,YH80 |
2 | ||
| 51341 - GUSSET, FRAME NO.4 CROSSMEMBER, RH | ||||
| 51342-26010 |
LH80,YH80..ST |
1 | ||
| 51341 - GUSSET, FRAME NO.4 CROSSMEMBER, RH | ||||
| 51342-26010 |
LH80,YH80..ST |
1 | ||
| 51342 - GUSSET, FRAME NO.4 CROSSMEMBER, LH | ||||
| 51342-26010 |
LH80,YH80..ST |
1 | ||
| 51342 - GUSSET, FRAME NO.4 CROSSMEMBER, LH | ||||
| 51342-26010 |
LH80,YH80..ST |
1 | ||
| 51345 - BRACKET, REAR SPRING, FRONT | ||||
| 51345-26040 |
LH80,YH80..T2..ST |
2 | ||
| 51345 - BRACKET, REAR SPRING, FRONT | ||||
| 51345-26040 |
LH80,YH80..T2..ST |
2 | ||
| 51345 - BRACKET, REAR SPRING, FRONT | ||||
| 51345-26040 |
LH80,YH80..T2..ST |
2 | ||
| 51345 - BRACKET, REAR SPRING, FRONT | ||||
| 51345-26040 |
LH80,YH80..T2..ST |
2 | ||
| 51355 - BRACKET, REAR SPRING, REAR RH | ||||
| 51355-26010 |
LH80,YH80..T1,T2,T3 |
1 | ||
| 51356 - BRACKET, REAR SPRING, REAR LH | ||||
| 51356-26010 |
LH80,YH80..T1,T2,T3 |
1 | ||
| 51391 - GUSSET, FRAME REAR CROSSMEMBER, RH | ||||
| 51393-26010 |
LH80,YH80 |
1 | ||
| 51391 - GUSSET, FRAME REAR CROSSMEMBER, RH | ||||
| 51393-26010 |
LH80,YH80 |
1 | ||
| 51392 - GUSSET, FRAME REAR CROSSMEMBER, LH | ||||
| 51393-26010 |
LH80,YH80 |
1 | ||
| 51392 - GUSSET, FRAME REAR CROSSMEMBER, LH | ||||
| 51393-26010 |
LH80,YH80 |
1 | ||
| 51401 - BRACKET SUB-ASSY, ENGINE FRONT MOUNTING, RH | ||||
| 51401-26010 |
LH80,YH80 |
2 | ||
| 51401 - BRACKET SUB-ASSY, ENGINE FRONT MOUNTING, RH | ||||
| 51401-26010 |
LH80,YH80 |
2 | ||
| 51401 - BRACKET SUB-ASSY, ENGINE FRONT MOUNTING, RH | ||||
| 51401-26010 |
LH80,YH80 |
2 | ||
| 51401 - BRACKET SUB-ASSY, ENGINE FRONT MOUNTING, RH | ||||
| 51401-26010 |
LH80,YH80 |
2 | ||
| 51505A - SUPPORT SUB-ASSY, UPPER CONTROL ARM | ||||
| 51505-26900 |
LH80,YH80 RH |
1 | ||
| 51506-26900 |
LH80,YH80 LH |
1 | ||
| 51505A - SUPPORT SUB-ASSY, UPPER CONTROL ARM | ||||
| 51505-26900 |
LH80,YH80 RH |
1 | ||
| 51506-26900 |
LH80,YH80 LH |
1 | ||
| 51703 - BRACKET SUB-ASSY, CAB MOUNTING, NO.2, RH | ||||
| 51703-26010 |
LH80,YH80 |
1 | ||
| 51703 - BRACKET SUB-ASSY, CAB MOUNTING, NO.2, RH | ||||
| 51703-26010 |
LH80,YH80 |
1 | ||
| 51704 - BRACKET SUB-ASSY, CAB MOUNTING, NO.2 LH | ||||
| 51703-26010 |
LH80,YH80 |
1 | ||
| 51704 - BRACKET SUB-ASSY, CAB MOUNTING, NO.2 LH | ||||
| 51703-26010 |
LH80,YH80 |
1 | ||
| 51741 - BRACKET, REAR BODY MOUNTING, NO.1 | ||||
| 51742-26020 |
LH80,YH80..T1,T2,T3 LH |
1 | ||
| 51741-26050 |
LH80,YH80..T1,T2,T3 RH |
1 | ||
| 51741 - BRACKET, REAR BODY MOUNTING, NO.1 | ||||
| 51742-26020 |
LH80,YH80..T1,T2,T3 LH |
1 | ||
| 51741-26050 |
LH80,YH80..T1,T2,T3 RH |
1 | ||
| 51741 - BRACKET, REAR BODY MOUNTING, NO.1 | ||||
| 51742-26020 |
LH80,YH80..T1,T2,T3 LH |
1 | ||
| 51741-26050 |
LH80,YH80..T1,T2,T3 RH |
1 | ||
| 51741 - BRACKET, REAR BODY MOUNTING, NO.1 | ||||
| 51742-26020 |
LH80,YH80..T1,T2,T3 LH |
1 | ||
| 51741-26050 |
LH80,YH80..T1,T2,T3 RH |
1 | ||
| 51742 - BRACKET, BODY MOUNTING, NO.2 | ||||
| 51743-26010 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51742 - BRACKET, BODY MOUNTING, NO.2 | ||||
| 51743-26010 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51742 - BRACKET, BODY MOUNTING, NO.2 | ||||
| 51743-26010 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51742 - BRACKET, BODY MOUNTING, NO.2 | ||||
| 51743-26010 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51743 - BRACKET, BODY MOUNTING, NO.3 | ||||
| 51711-26080 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51743 - BRACKET, BODY MOUNTING, NO.3 | ||||
| 51711-26080 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51743 - BRACKET, BODY MOUNTING, NO.3 | ||||
| 51711-26080 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51743 - BRACKET, BODY MOUNTING, NO.3 | ||||
| 51711-26080 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51744 - BRACKET, BODY MOUNTING, NO.4 | ||||
| 51743-26010 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 51744 - BRACKET, BODY MOUNTING, NO.4 | ||||
| 51743-26010 |
LH80,YH80..T1,T2,T3 |
2 | ||
| 57107 - BRACKET SUB-ASSY, STRUT BAR, RH | ||||
| 57107-26010 |
LH80,YH80 |
1 | ||
| 57107 - BRACKET SUB-ASSY, STRUT BAR, RH | ||||
| 57107-26010 |
LH80,YH80 |
1 | ||
| 57108 - BRACKET SUB-ASSY, STRUT BAR, LH | ||||
| 57108-26010 |
LH80,YH80 |
1 | ||
| 57108 - BRACKET SUB-ASSY, STRUT BAR, LH | ||||
| 57108-26010 |
LH80,YH80 |
1 | ||
| Common parts | ||||
| 90105-10101 | ||||
| 90105-10107 | ||||
| 90179-10054 | ||||
| 90950-01395 | ||||
| 90950-01420 | ||||
