TRH124B-ZRPNK (2003)
Toyota Hiace/Regiusace
(0308- )TRH102,112,12#..4FC
A45DE
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 35601B - RING, O (FOR FRONT CLUTCH DRUM) | ||||
| 90301-57188 |
LH100,102,103,107,113,119,123,129,RZH10#,111,112,124,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35602 - PISTON SUB-ASSY, FRONT CLUTCH | ||||
| 35602-22030 |
TRH12#..4FC |
1 | ||
| 35602F - PISTON SUB-ASSY, REAR CLUTCH, NO.2 | ||||
| 35602-30041 |
TRH12#..4FC |
1 | ||
| 35603A - SPRING SUB-ASSY, FORWARD CLUTCH RETURN | ||||
| 35603-22030 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) ﾌﾛﾝﾄ |
1 | ||
| 35603-22010 |
TRH12#..4FC ﾘﾔ |
1 | ||
| 35603-22040 |
TRH12#..4FC ﾌﾛﾝﾄ |
1 | ||
| 35603A - SPRING SUB-ASSY, FORWARD CLUTCH RETURN | ||||
| 35603-22030 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) ﾌﾛﾝﾄ |
1 | ||
| 35603-22010 |
TRH12#..4FC ﾘﾔ |
1 | ||
| 35603-22040 |
TRH12#..4FC ﾌﾛﾝﾄ |
1 | ||
| 35605 - DRUM SUB-ASSY, REAR CLUTCH W/2ND SUN GEAR | ||||
| 35605-22011 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35606 - PISTON SUB-ASSY, REAR CLUTCH | ||||
| 35606-22010 |
TRH12#..4FC |
1 | ||
| 35606B - RING (FOR REAR CLUTCH PISTON INNER) | ||||
| 90301-57188 |
LH100,102,103,107,113,119,123,129,RZH10#,111,112,124,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35610C - RING, SHAFT SNAP (FOR FRONT CLUTCH PISTON RETURN SPRING | ||||
| 90520-39261 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35613 - RING, CLUTCH PISTON OIL SEAL, OUTER | ||||
| 90301-99016 |
LH100,102,103,107,113,119,123,129,RZH10#,111,112,124,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35631B - BEARING, THRUST(FOR FRONT CLUTCH HUB) | ||||
| 90374-28014 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35631C - RACE, THRUST BEARING(FOR FRONT CLUTCH HUB FRONT) | ||||
| 35789-22050 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-22080 |
TRH12#..4FC |
4 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-22080 |
TRH12#..4FC |
4 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-22080 |
TRH12#..4FC |
4 | ||
| 35633 - DISC, CLUTCH (FOR FRONT CLUTCH) | ||||
| 35677-22080 |
TRH12#..4FC |
4 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=1.8 |
3 | ||
| 35634-30070 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=2.0 |
1 | ||
| 35634-22040 |
TRH12#..4FC 厚さ=1.8 |
1 | ||
| 35634-30070 |
TRH12#..4FC 厚さ=2.0 |
1 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=1.8 |
3 | ||
| 35634-30070 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=2.0 |
1 | ||
| 35634-22040 |
TRH12#..4FC 厚さ=1.8 |
1 | ||
| 35634-30070 |
TRH12#..4FC 厚さ=2.0 |
1 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=1.8 |
3 | ||
| 35634-30070 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=2.0 |
1 | ||
| 35634-22040 |
TRH12#..4FC 厚さ=1.8 |
1 | ||
| 35634-30070 |
TRH12#..4FC 厚さ=2.0 |
1 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=1.8 |
3 | ||
| 35634-30070 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=2.0 |
1 | ||
| 35634-22040 |
TRH12#..4FC 厚さ=1.8 |
1 | ||
| 35634-30070 |
TRH12#..4FC 厚さ=2.0 |
1 | ||
| 35634 - PLATE, FRONT CLUTCH | ||||
| 35634-22040 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=1.8 |
3 | ||
| 35634-30070 |
LH102,103,113,119,123,129,162,17#,18#,RZH102,112,124..4FC 厚さ=2.0 |
1 | ||
| 35634-22040 |
TRH12#..4FC 厚さ=1.8 |
1 | ||
| 35634-30070 |
TRH12#..4FC 厚さ=2.0 |
1 | ||
| 35650A - RING, SHAFT SNAP (FOR REAR CLUTCH PISTON RETURN SPRING) | ||||
| 90520-39261 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35650F - RING, SHAFT SNAP | ||||
| 90521-99139 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35652A - RING (FOR REAR CLUTCH OUTER) | ||||
| 90301-99016 |
LH100,102,103,107,113,119,123,129,RZH10#,111,112,124,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35652B - RING (FOR REAR CLUTCH PISTON INNER) | ||||
| 90301-57188 |
LH100,102,103,107,113,119,123,129,RZH10#,111,112,124,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35653 - RING, REAR CLUTCH OIL SEAL, OUTER | ||||
| 90301-84184 |
LH100,102,103,107,113,119,123,129,RZH10#,111,112,124,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35654 - HUB, REAR CLUTCH | ||||
| 35654-30010 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35701B - BEARING, THRUST NEEDLE ROLLER (FOR INPUT SHAFT REAR) | ||||
| 90374-23012 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 90374-23012 |
TRH12#..4FC |
1 | ||
| 35701C - RACE, THRUST BEARING (FOR INPUT SHAFT REAR) | ||||
| 35789-22010 |
LH100,102,103,107,113,119,123,129,162,17#,18#,RZH10#,111,112,124,125,133..4FC..(CBR,DSL,EFI,TD) |
1 | ||
| 35789-22010 |
TRH12#..4FC |
1 | ||
