RZH112V-SMMDE (1993)
Toyota Hiace/Regiusace
(9608- )KZH10#,11#,12#,13#,RZH101,111,133
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53111 - GRILLE, RADIATOR | ||||
| 53100-95J17 |
LH102,109,110,113,115,119,123,125,129,140,RZH102,112,12#..(03S,06S,09S,15S)..(CD,DX,SW) 塗装不要 |
1 | ||
| 53100-26040 |
KZH10#,11#,RZH100..CTM,DX 塗装不要,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26110 |
KZH11#,12#,13#,RZH111,133 塗装不要,ﾄｿ-ｱﾘ |
1 | ||
| 53100-26100 |
KZH11#..4FC;KZH10#,12#,13#,RZH101 ﾒｯｷ,ﾒﾂｷ |
1 | ||
| 53100-26060 |
LH10#,11#,12#,RZH102,112,124..CD,DX,GL 塗装不要,TYPE B:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26030E1 |
KZH10#,12#,13#,LH123,129,RZH101..03S,06S,08S,10S BEIGE M,21T,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26130 |
LH16#,17#,18#,RZH102,112,12#..CD,DX,GL 塗装不要 |
1 | ||
| 53118B - RETAINER, RADIATOR GRILLE, NO.2 RH | ||||
| 53118-26030 |
KZH10#,11#,12#,13#,RZH101,111,133 |
1 | ||
| 53128B - RETAINER, RADIATOR GRILLE, NO.2 LH | ||||
| 53128-26010 |
KZH10#,11#,12#,13#,RZH101,111,133 |
1 | ||
| 81819A - COVER, TURN SIGNAL INDICATOR LAMP | ||||
| 81819-26010B1 |
KZH10#,12#,13#,RZH101 WARM GRAY PEARL ME.,2BY |
1 | ||
| 81819-26010A2 |
KZH11#,12#,13#,RZH111,133 WHITE,045 |
1 | ||
| 81819-26010B1 |
KZH11#..4FC;KZH10#,12#,13#,RZH101 WARM GRAY PEARL ME.,2BY |
1 | ||
| 81819-26010A6 |
KZH11#,12#,13#,RZH111,133 WHITE,058 |
1 | ||
| 81819B - COVER, TURN SIGNAL INDICATOR LAMP | ||||
| 81819-26020B1 |
KZH10#,12#,13#,RZH101 WARM GRAY PEARL ME.,2BY |
1 | ||
| 81819-26020A2 |
KZH11#,12#,13#,RZH111,133 WHITE,045 |
1 | ||
| 81819-26020B1 |
KZH11#..4FC;KZH10#,12#,13#,RZH101 WARM GRAY PEARL ME.,2BY |
1 | ||
| 81819-26020A6 |
KZH11#,12#,13#,RZH111,133 WHITE,058 |
1 | ||
| Common parts | ||||
| 67921-32010 | ||||
| 67921-50030 | ||||
| 71196-26020 | ||||
| 93540-54010 | ||||
| Linked diagrams | ||||
| 7551 | ||||
(9808- )LH16#,17#,18#,RZH102,112,12#,18#,TRH102,112,12#
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53111 - GRILLE, RADIATOR | ||||
| 53100-95J17 |
LH102,109,110,113,115,119,123,125,129,140,RZH102,112,12#..(03S,06S,09S,15S)..(CD,DX,SW) 塗装不要 |
1 | ||
| 53100-26040 |
KZH10#,11#,RZH100..CTM,DX 塗装不要,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26110 |
KZH11#,12#,13#,RZH111,133 塗装不要,ﾄｿ-ｱﾘ |
1 | ||
| 53100-26100 |
KZH11#..4FC;KZH10#,12#,13#,RZH101 ﾒｯｷ,ﾒﾂｷ |
1 | ||
| 53100-26060 |
LH10#,11#,12#,RZH102,112,124..CD,DX,GL 塗装不要,TYPE B:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26030E1 |
KZH10#,12#,13#,LH123,129,RZH101..03S,06S,08S,10S BEIGE M,21T,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26130 |
LH16#,17#,18#,RZH102,112,12#..CD,DX,GL 塗装不要 |
1 | ||
| 53145B - CLIP, RADIATOR GRILLE GARNISH | ||||
| 53145-95J01 |
LH10#,11#,12#,RZH102,112,124 |
2 | ||
| 53145-95J01 |
LH100,102,109,11#,123,125,129,140,RZH100,102,11#,12#..HRF,SRF |
2 | ||
| 53145-26010 |
RZH102,112,12#,18# |
2 | ||
| 53145-26010 |
LH10#,11#,12#,16#,17#,18#,RZH102,112,12# |
2 | ||
| 53145-26010 |
LH119..05S;LH123..06S;LH113..V1..SRF..4D..06S..DX;KZH10#,11#,12#,LH129,RZH100,101 ｷﾔﾝﾋﾟﾝｸﾞ ｶ- |
3 | ||
| 53145-26010 |
LH123..06S;KZH10#,11#,12#,13#,LH129,RZH101,111,133 ｷﾔﾝﾋﾟﾝｸﾞ ｶ- |
3 | ||
| 53145-95J01 |
KZH10#,11#,12#,RZH100,101 |
3 | ||
| Common parts | ||||
| 90168-40128 | ||||
| 90467-09201 | ||||
| 90467-10162 | ||||
| Linked diagrams | ||||
| 7551 | ||||
(9308-9608)KZH10#,11#,12#,13#,RZH101,111,133 ; (9308-9808)LH10#,11#,12#,RZH102,112,
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 53111 - GRILLE, RADIATOR | ||||
| 53100-95J17 |
LH102,109,110,113,115,119,123,125,129,140,RZH102,112,12#..(03S,06S,09S,15S)..(CD,DX,SW) 塗装不要 |
1 | ||
| 53100-26040 |
KZH10#,11#,RZH100..CTM,DX 塗装不要,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26110 |
KZH11#,12#,13#,RZH111,133 塗装不要,ﾄｿ-ｱﾘ |
1 | ||
| 53100-26100 |
KZH11#..4FC;KZH10#,12#,13#,RZH101 ﾒｯｷ,ﾒﾂｷ |
1 | ||
| 53100-26060 |
LH10#,11#,12#,RZH102,112,124..CD,DX,GL 塗装不要,TYPE B:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26030E1 |
KZH10#,12#,13#,LH123,129,RZH101..03S,06S,08S,10S BEIGE M,21T,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26130 |
LH16#,17#,18#,RZH102,112,12#..CD,DX,GL 塗装不要 |
1 | ||
| 53111 - GRILLE, RADIATOR | ||||
| 53100-95J17 |
LH102,109,110,113,115,119,123,125,129,140,RZH102,112,12#..(03S,06S,09S,15S)..(CD,DX,SW) 塗装不要 |
1 | ||
| 53100-26040 |
KZH10#,11#,RZH100..CTM,DX 塗装不要,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26110 |
KZH11#,12#,13#,RZH111,133 塗装不要,ﾄｿ-ｱﾘ |
1 | ||
| 53100-26100 |
KZH11#..4FC;KZH10#,12#,13#,RZH101 ﾒｯｷ,ﾒﾂｷ |
1 | ||
| 53100-26060 |
LH10#,11#,12#,RZH102,112,124..CD,DX,GL 塗装不要,TYPE B:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26030E1 |
KZH10#,12#,13#,LH123,129,RZH101..03S,06S,08S,10S BEIGE M,21T,TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 53100-26130 |
LH16#,17#,18#,RZH102,112,12#..CD,DX,GL 塗装不要 |
1 | ||
| 53145B - CLIP, RADIATOR GRILLE GARNISH | ||||
| 53145-95J01 |
LH10#,11#,12#,RZH102,112,124 |
2 | ||
| 53145-95J01 |
LH100,102,109,11#,123,125,129,140,RZH100,102,11#,12#..HRF,SRF |
2 | ||
| 53145-26010 |
RZH102,112,12#,18# |
2 | ||
| 53145-26010 |
LH10#,11#,12#,16#,17#,18#,RZH102,112,12# |
2 | ||
| 53145-26010 |
LH119..05S;LH123..06S;LH113..V1..SRF..4D..06S..DX;KZH10#,11#,12#,LH129,RZH100,101 ｷﾔﾝﾋﾟﾝｸﾞ ｶ- |
3 | ||
| 53145-26010 |
LH123..06S;KZH10#,11#,12#,13#,LH129,RZH101,111,133 ｷﾔﾝﾋﾟﾝｸﾞ ｶ- |
3 | ||
| 53145-95J01 |
KZH10#,11#,12#,RZH100,101 |
3 | ||
| 53145B - CLIP, RADIATOR GRILLE GARNISH | ||||
| 53145-95J01 |
LH10#,11#,12#,RZH102,112,124 |
2 | ||
| 53145-95J01 |
LH100,102,109,11#,123,125,129,140,RZH100,102,11#,12#..HRF,SRF |
2 | ||
| 53145-26010 |
RZH102,112,12#,18# |
2 | ||
| 53145-26010 |
LH10#,11#,12#,16#,17#,18#,RZH102,112,12# |
2 | ||
| 53145-26010 |
LH119..05S;LH123..06S;LH113..V1..SRF..4D..06S..DX;KZH10#,11#,12#,LH129,RZH100,101 ｷﾔﾝﾋﾟﾝｸﾞ ｶ- |
3 | ||
| 53145-26010 |
LH123..06S;KZH10#,11#,12#,13#,LH129,RZH101,111,133 ｷﾔﾝﾋﾟﾝｸﾞ ｶ- |
3 | ||
| 53145-95J01 |
KZH10#,11#,12#,RZH100,101 |
3 | ||
| Common parts | ||||
| 67771-22040 | ||||
| 67921-32010 | ||||
| 90167-40035 | ||||
| Linked diagrams | ||||
| 7551 | ||||
