LH125B-ZRMNS (1989)
Toyota Hiace/Regiusace
ILLUST NO. 1 OF 2(8908- )HRF
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 63071 - FRAME SUB-ASSY, BACK DOOR OPENING, UPPER | ||||
| 63071-95J05 |
LH113,123,125,129,RZH112,12#..HRF |
1 | ||
| 63071-95J05 |
LH113,12#,RZH112,12#,133..HRF..(DX,GL) |
1 | ||
| 63071 - FRAME SUB-ASSY, BACK DOOR OPENING, UPPER | ||||
| 63071-95J05 |
LH113,123,125,129,RZH112,12#..HRF |
1 | ||
| 63071-95J05 |
LH113,12#,RZH112,12#,133..HRF..(DX,GL) |
1 | ||
| 63102A - PANEL SUB-ASSY, WINDSHIELD HEADER | ||||
| 63102-95J07 |
LH120,125,RZH124;LH100,102,107,113,119,RZH100,101..CTM,SCL,SCM,SCMM,SGL |
1 | ||
| 63102-95J07 |
LH102,103,113,119..SGL;KZH10#,12#,13#,LH100,107,125,RZH100,101,124,133..HRF,MRF,SMRF |
1 | ||
| 63102A - PANEL SUB-ASSY, WINDSHIELD HEADER | ||||
| 63102-95J07 |
LH120,125,RZH124;LH100,102,107,113,119,RZH100,101..CTM,SCL,SCM,SCMM,SGL |
1 | ||
| 63102-95J07 |
LH102,103,113,119..SGL;KZH10#,12#,13#,LH100,107,125,RZH100,101,124,133..HRF,MRF,SMRF |
1 | ||
| 63103A - REINFORCEMENT SUB-ASSY, ROOF PANEL | ||||
| 63103-95J15 |
LH125,RZH124 ﾘﾔ |
1 | ||
| 63103-95J09 |
LH125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103-95J09 |
LH120,125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103-26070 |
KZH12#,LH125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103A - REINFORCEMENT SUB-ASSY, ROOF PANEL | ||||
| 63103-95J15 |
LH125,RZH124 ﾘﾔ |
1 | ||
| 63103-95J09 |
LH125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103-95J09 |
LH120,125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103-26070 |
KZH12#,LH125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103A - REINFORCEMENT SUB-ASSY, ROOF PANEL | ||||
| 63103-95J15 |
LH125,RZH124 ﾘﾔ |
1 | ||
| 63103-95J09 |
LH125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103-95J09 |
LH120,125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103-26070 |
KZH12#,LH125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103A - REINFORCEMENT SUB-ASSY, ROOF PANEL | ||||
| 63103-95J15 |
LH125,RZH124 ﾘﾔ |
1 | ||
| 63103-95J09 |
LH125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103-95J09 |
LH120,125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63103-26070 |
KZH12#,LH125,RZH124 ﾌﾛﾝﾄ |
1 | ||
| 63104D - REINFORCEMENT SUB-ASSY, ROOF PANEL, NO.2 | ||||
| 63104-95J02 |
LH125,RZH124,133 |
1 | ||
| 63104-95J02 |
KZH13#,LH125,RZH124,133 |
1 | ||
| 63104D - REINFORCEMENT SUB-ASSY, ROOF PANEL, NO.2 | ||||
| 63104-95J02 |
LH125,RZH124,133 |
1 | ||
| 63104-95J02 |
KZH13#,LH125,RZH124,133 |
1 | ||
| 63105E - REINFORCEMENT SUB-ASSY, ROOF PANEL, NO.3 | ||||
| 63105-95J12 |
LH125,RZH124,133 |
1 | ||
| 63105-95J12 |
KZH13#,LH125,RZH124,133 |
1 | ||
| 63105E - REINFORCEMENT SUB-ASSY, ROOF PANEL, NO.3 | ||||
| 63105-95J12 |
LH125,RZH124,133 |
1 | ||
| 63105-95J12 |
KZH13#,LH125,RZH124,133 |
1 | ||
| 63105F - REINFORCEMENT SUB-ASSY, ROOF PANEL, NO.3 | ||||
| 63105-95J09 |
KZH12#,13#,LH113,12#,172,18#,RZH112,12#,133..HRF |
1 | ||
| 63105F - REINFORCEMENT SUB-ASSY, ROOF PANEL, NO.3 | ||||
| 63105-95J09 |
KZH12#,13#,LH113,12#,172,18#,RZH112,12#,133..HRF |
1 | ||
| 63111 - PANEL, ROOF | ||||
| 63111-95J20 |
KZH12#,13#,LH12#,18#,RZH12#,133 |
1 | ||
| 63111 - PANEL, ROOF | ||||
| 63111-95J20 |
KZH12#,13#,LH12#,18#,RZH12#,133 |
1 | ||
| 63146A - BRACKET, ROOF PANEL REINFORCEMENT, NO.1 | ||||
| 63146-95J00 |
LH120,125,RZH124..CBR,DSL,TD |
8 | ||
| 63146A - BRACKET, ROOF PANEL REINFORCEMENT, NO.1 | ||||
| 63146-95J00 |
LH120,125,RZH124..CBR,DSL,TD |
8 | ||
| 63146A - BRACKET, ROOF PANEL REINFORCEMENT, NO.1 | ||||
| 63146-95J00 |
LH120,125,RZH124..CBR,DSL,TD |
8 | ||
| 63146A - BRACKET, ROOF PANEL REINFORCEMENT, NO.1 | ||||
| 63146-95J00 |
LH120,125,RZH124..CBR,DSL,TD |
8 | ||
| 63146A - BRACKET, ROOF PANEL REINFORCEMENT, NO.1 | ||||
| 63146-95J00 |
LH120,125,RZH124..CBR,DSL,TD |
8 | ||
| 63146A - BRACKET, ROOF PANEL REINFORCEMENT, NO.1 | ||||
| 63146-95J00 |
LH120,125,RZH124..CBR,DSL,TD |
8 | ||
| 63146A - BRACKET, ROOF PANEL REINFORCEMENT, NO.1 | ||||
| 63146-95J00 |
LH120,125,RZH124..CBR,DSL,TD |
8 | ||
| 63146A - BRACKET, ROOF PANEL REINFORCEMENT, NO.1 | ||||
| 63146-95J00 |
LH120,125,RZH124..CBR,DSL,TD |
8 | ||
| 63713 - BRACKET, ROOF PANEL REINFORCEMENT, NO.3 | ||||
| 63713-95J00 |
LH113..HRF..5D;LH12#,RZH112,12#..HRF..(CBR,DSL,TD) |
1 | ||
| 63714 - BRACKET, ROOF PANEL REINFORCEMENT, NO.4 | ||||
| 63714-95J00 |
LH113,12#,RZH112,12#..HRF..(CBR,DSL,TD) |
1 | ||
| Common parts | ||||
| 90119-06572 | ||||
| 90179-06274 | ||||
| Linked diagrams | ||||
| 6151 | ||||
ILLUST NO. 2 OF 2(8908-9508)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90044-30071 | ||||
| 90116-06092 | ||||
| 90119-06182 | ||||
| 90154-50019 | ||||
| 90159-50301 | ||||
| 90159-60009 | ||||
| 90159-60162 | ||||
| 90162-40025 | ||||
| 90164-50008 | ||||
| 90176-06036 | ||||
| 90179-06171 | ||||
| 90179-06194 | ||||
| 90179-06220 | ||||
| 90189-05058 | ||||
| 90385-11005 | ||||
| 90467-17126 | ||||
| 90480-30015 | ||||
| 90561-14001 | ||||
| 90950-01530 | ||||
| 91631-40612 | ||||
| 93210-16012 | ||||
| 93229-54012 | ||||
