KDH222B-LEPDY (2005)
Toyota Hiace/Regiusace
(0408-0709)KDH20#,22#..COM,V1..4D ; (0408- )TRH200,214,219,22#..COM,V1,WG..4D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 58076 - COVER SUB-ASSY, JACK BOX HOLE | ||||
| 58076-26010B0 |
KDH200,205,TRH200..IV5;KDH20#,211,222,227,TRH200,21#,22#..02S,05S,10S,15S MD.GRAY,TRIM1#,左側 |
1 | ||
| 58511E - CLIP(FOR FRONT FLOOR MAT) | ||||
| 64726-26010B0 |
KDH20#,211,22#,TRH200,21#,22# MD.GRAY,TRIM1# |
10 | ||
| 58520H - CLIP(FOR ENGINE COVER MAT) | ||||
| 64726-26010B0 |
KDH20#,211,22#,TRH200,21#,22# MD.GRAY,TRIM1# |
2 | ||
| 58530F - MAT ASSY, HEADER | ||||
| 58530-26E60B0 |
KDH22#..DX MEDIUM GRAY,TRIM1# |
1 | ||
| 58530H - CLIP(FOR HEADER MAT & HEADER CARPET) | ||||
| 64726-26010B0 |
KDH20#,211,22#,TRH200,21#,22# MD.GRAY,TRIM1# |
9 | ||
| 58560B - CLIP(FOR FLOOR CARPET, REAR) | ||||
| 63399-26050B0 |
KDH222,227,TRH223,224,228,229..CBU LT.GRAY,TRIM1# |
6 | ||
| 58569 - STOPPER, REAR FLOOR MAT | ||||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ｴﾝｼﾞﾝｶﾊﾞｰ ﾏｯﾄ用 |
1 | ||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ﾌﾛﾝﾄ ﾌﾛｱﾏｯﾄ用 |
10 | ||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ﾍｯﾀﾞﾊﾟﾈﾙ ﾏｯﾄ用 |
6 | ||
| 58569 - STOPPER, REAR FLOOR MAT | ||||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ｴﾝｼﾞﾝｶﾊﾞｰ ﾏｯﾄ用 |
1 | ||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ﾌﾛﾝﾄ ﾌﾛｱﾏｯﾄ用 |
10 | ||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ﾍｯﾀﾞﾊﾟﾈﾙ ﾏｯﾄ用 |
6 | ||
| 58569 - STOPPER, REAR FLOOR MAT | ||||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ｴﾝｼﾞﾝｶﾊﾞｰ ﾏｯﾄ用 |
1 | ||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ﾌﾛﾝﾄ ﾌﾛｱﾏｯﾄ用 |
10 | ||
| 64779-26010 |
KDH20#,211,22#,TRH200,21#,22# ﾍｯﾀﾞﾊﾟﾈﾙ ﾏｯﾄ用 |
6 | ||
| 58570B - MAT ASSY, REAR FLOOR | ||||
| 58517-26B60B0 |
KDH222,227,TRH223,228..DX MEDIUM GRAY,TRIM1# |
1 | ||
| 58572C - CLIP, REAR FLOOR MAT SET | ||||
| 64726-26010B0 |
TRH224,229;KDH20#,211,22#,TRH200,21#,221,223,226,228..SG..(03S,05S,06S,09S,10S,15S)..CBU MD.GRAY,TRIM1# |
2 | ||
| 58579C - CLIP, REAR FLOOR CARPET SET | ||||
| 90467-10034C0 |
KDH222,223,227,TRH214,219,223,228..DX BLACK |
2 | ||
| 58579C - CLIP, REAR FLOOR CARPET SET | ||||
| 90467-10034C0 |
KDH222,223,227,TRH214,219,223,228..DX BLACK |
2 | ||
| 58579C - CLIP, REAR FLOOR CARPET SET | ||||
| 90467-10034C0 |
KDH222,223,227,TRH214,219,223,228..DX BLACK |
2 | ||
| 67913 - PLATE, FRONT DOOR SCUFF, RH | ||||
| 67913-26080B0 |
KDH20#,22#,TRH200,21#,22# MD.GRAY,TRIM1# |
1 | ||
| 67914 - PLATE, FRONT DOOR SCUFF, LH | ||||
| 67914-26060B0 |
KDH20#,22#,TRH200,21#,22# MD.GRAY,TRIM1# |
1 | ||
| 67918A - PLATE, REAR DOOR SCUFF, LH | ||||
| 67918-26120B0 |
KDH222,223,227,TRH214,219,223,224,228,229..CBU *POSD(左側)&*ECS(左側),MD.GRAY,TRIM1# |
1 | ||
| 67918-26110B0 |
KDH20#,TRH200..IV5;KDH20#,211,222,223,227,TRH200,21#,22#..02S,05S,10S,15S MD.GRAY,TRIM1# |
1 | ||
| 67918A - PLATE, REAR DOOR SCUFF, LH | ||||
| 67918-26120B0 |
KDH222,223,227,TRH214,219,223,224,228,229..CBU *POSD(左側)&*ECS(左側),MD.GRAY,TRIM1# |
1 | ||
| 67918-26110B0 |
KDH20#,TRH200..IV5;KDH20#,211,222,223,227,TRH200,21#,22#..02S,05S,10S,15S MD.GRAY,TRIM1# |
1 | ||
| 67921 - RETAINER, FRONT DOOR SCUFF PLATE | ||||
| 67771-26240 |
KDH20#,211,22#,TRH200,21#,22# |
4 | ||
| 67921 - RETAINER, FRONT DOOR SCUFF PLATE | ||||
| 67771-26240 |
KDH20#,211,22#,TRH200,21#,22# |
4 | ||
| 67935 - PLATE, BACK DOOR SCUFF | ||||
| 67935-26130 |
KDH22#,TRH21#,221,223,226,228..DX |
1 | ||
| 67935 - PLATE, BACK DOOR SCUFF | ||||
| 67935-26130 |
KDH22#,TRH21#,221,223,226,228..DX |
1 | ||
| 67935G - SCREW, BACK DOOR SCUFF PLATE | ||||
| 93560-56014 |
KDH22#,TRH214,219,221,223,226,228..DX |
7 | ||
| 67935H - GROMMET, BACK DOOR SCUFF PLATE | ||||
| 90189-06057 |
KDH22#,TRH214,219,221,223,226,228..DX |
7 | ||
| 67936B - COVER, BACK DOOR SCUFF SIDE, RH | ||||
| 67936-26020B1 |
KDH20#,22#,TRH200,21#,221,223,226,228..(COM,V1,WG)..DX..CBU MD.GRAY,TRIM1# |
1 | ||
| 67937F - COVER, BACK DOOR SCUFF SIDE, LH | ||||
| 67937-26020B1 |
KDH20#,22#,TRH200,21#,221,223,226,228..(COM,V1,WG)..DX..CBU MD.GRAY,TRIM1# |
1 | ||
| Common parts | ||||
| 64779-26020 | ||||
| 90189-06057 | ||||
| 90467-09206 | ||||
| 90467-10161 | ||||
| 90467-10167 | ||||
| 90467-10178 | ||||
| 93560-56014 | ||||
| Linked diagrams | ||||
| 5851 | ||||
(1312- )GDH20#,22#,TRH200,214,219,22#..4D
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 64779-26020 | ||||
| 90189-06057 | ||||
| 90467-09206 | ||||
| 90467-10161 | ||||
| 90467-10167 | ||||
| 90467-10178 | ||||
| 93560-56012 | ||||
| Linked diagrams | ||||
| 5851 | ||||
