KDH222B-LEPDY (2005)
Toyota Hiace/Regiusace
(0408- )KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 43211 - KNUCKLE, STEERING, RH | ||||
| 43211-29026 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 43212 - KNUCKLE, STEERING, LH | ||||
| 43212-29026 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 43310B - RING, SET (FOR DUST COVER) | ||||
| 90580-10001 |
KDH200,220,222,TRH200,214,221,223,224 NO.1 |
2 | ||
| 90522-50001 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
2 | ||
| 43310B - RING, SET (FOR DUST COVER) | ||||
| 90580-10001 |
KDH200,220,222,TRH200,214,221,223,224 NO.1 |
2 | ||
| 90522-50001 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
2 | ||
| 43324B - COVER, FRONT UPPER BALL JOINT DUST, RH | ||||
| 43324-26050 |
KDH20#,211,22#,TRH200,21#,22# |
1 | ||
| 43324C - COVER, FRONT UPPER BALL JOINT DUST, LH | ||||
| 43324-26050 |
KDH20#,211,22#,TRH200,21#,22# |
1 | ||
| 43330K - JOINT ASSY, LOWER BALL, FRONT RH | ||||
| 43330-29565 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 43330L - NUT, CASTLE (FOR FRONT LOWER BALL JOINT RH) | ||||
| 90171-16008 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 43340A - JOINT ASSY, LOWER BALL, FRONT LH | ||||
| 43330-29565 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 43340B - NUT, CASTLE (FOR FRONT LOWER BALL JOINT LH) | ||||
| 90171-16008 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48066 - ARM SUB-ASSY, FRONT SUSPENSION, UPPER RH | ||||
| 48066-29215 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48067 - ARM SUB-ASSY, FRONT SUSPENSION, UPPER LH | ||||
| 48067-29215 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48068 - ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 RH | ||||
| 48068-26160 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48069 - ARM SUB-ASSY, FRONT SUSPENSION, LOWER NO.1 LH | ||||
| 48069-26160 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48167C - ARM, FRONT SUSPENSION TORQUE, RH | ||||
| 48106-26040 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48167D - ARM, FRONT SUSPENSION TORQUE, LH | ||||
| 48106-26040 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48194C - CAM, FRONT SUSPENSION CAMBER ADJUST, NO.1 RH | ||||
| 48190-25010 |
KDH20#,211,22#,TRH200,21#,22# |
1 | ||
| 48194D - CAM, FRONT SUSPENSION CAMBER ADJUST, NO.2 RH | ||||
| 48198-25010 |
KDH20#,211,22#,TRH200,21#,22# |
1 | ||
| 48198C - CAM, FRONT SUSPENSION CAMBER ADJUST, NO.1 LH | ||||
| 48190-25010 |
KDH20#,211,22#,TRH200,21#,22# |
1 | ||
| 48198D - CAM, FRONT SUSPENSION CAMBER ADJUST, NO.2 LH | ||||
| 48198-25010 |
KDH20#,211,22#,TRH200,21#,22# |
1 | ||
| 48331D - BUMPER, FRONT SPRING, NO.1 RH | ||||
| 48331-26140 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48331E - BUMPER, FRONT SPRING, NO.1 LH | ||||
| 48331-26140 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48332B - BUMPER, FRONT SPRING, NO.2 RH | ||||
| 48332-35020 |
KDH20#,211,22#,TRH200,21#,22# |
1 | ||
| 48332C - BUMPER, FRONT SPRING, NO.2 LH | ||||
| 48332-35020 |
KDH20#,211,22#,TRH200,21#,22# |
1 | ||
| 48631 - SHAFT, FRONT SUSPENSION UPPER ARM | ||||
| 48631-26040 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
2 | ||
| 48631A - RETAINER, CUSHION(FOR FRONT SUSPENSION UPPER ARM RH) | ||||
| 90948-02143 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
1 | ||
| 90948-02142 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.1 |
1 | ||
| 48631A - RETAINER, CUSHION(FOR FRONT SUSPENSION UPPER ARM RH) | ||||
| 90948-02143 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
1 | ||
| 90948-02142 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.1 |
1 | ||
| 48631C - RETAINER, CUSHION(FOR FRONT SUSPENSION UPPER ARM LH) | ||||
| 90948-02143 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
1 | ||
| 90948-02142 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.1 |
1 | ||
| 48631C - RETAINER, CUSHION(FOR FRONT SUSPENSION UPPER ARM LH) | ||||
| 90948-02143 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
1 | ||
| 90948-02142 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.1 |
1 | ||
| 48632A - BUSH, FRONT SUSPENSION UPPER ARM, RH | ||||
| 48635-26080 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
1 | ||
| 48632-26090 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.1 |
1 | ||
| 48632A - BUSH, FRONT SUSPENSION UPPER ARM, RH | ||||
| 48635-26080 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
1 | ||
| 48632-26090 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.1 |
1 | ||
| 48632B - BUSH, FRONT SUSPENSION UPPER ARM, LH | ||||
| 48632-26090 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.1 |
1 | ||
| 48635-26080 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
1 | ||
| 48632B - BUSH, FRONT SUSPENSION UPPER ARM, LH | ||||
| 48632-26090 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.1 |
1 | ||
| 48635-26080 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 NO.2 |
1 | ||
| 48654E - BUSH, FRONT LOWER ARM, NO.1 RH | ||||
| 48061-26050 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| 48654F - BUSH, FRONT LOWER ARM, NO.1 LH | ||||
| 48061-26050 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224 |
1 | ||
| Common parts | ||||
| 90105-12285 | ||||
| 90119-14112 | ||||
| 90170-16023 | ||||
| 90171-16008 | ||||
| 90179-18004 | ||||
| 90201-10031 | ||||
| 90201-11006 | ||||
| 90252-04003 | ||||
| 90252-04005 | ||||
| 94151-21041 | ||||
| 94622-11600 | ||||
| Linked diagrams | ||||
| 5851 | ||||
(1312- )GDH201,211,221,223,KDH201,211,22#,TRH200,211,214,221,223,224
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90105-12285 | ||||
| 90119-14112 | ||||
| 90170-16023 | ||||
| 90171-16008 | ||||
| 90179-18004 | ||||
| 90201-10031 | ||||
| 90201-11006 | ||||
| 90252-04003 | ||||
| 90252-04005 | ||||
| 94151-21041 | ||||
| 94622-11600 | ||||
