KDH222B-LEPDY (2005)
Toyota Hiace/Regiusace
(0408- )TRH21#,22#
A343E,A343F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 32907 - TUBE SUB-ASSY, OIL COOLER OUTLET, NO.2 | ||||
| 32907-26050 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224..4FC |
1 | ||
| 32907 - TUBE SUB-ASSY, OIL COOLER OUTLET, NO.2 | ||||
| 32907-26050 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224..4FC |
1 | ||
| 32921 - TUBE, OIL COOLER INLET, NO.1 | ||||
| 32921-26380 |
KDH20#,22#..4FC |
1 | ||
| 32921-26370 |
TRH21#,22# |
1 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90407-14024 |
KDH20#,22#..4FC ｲﾝﾚｯﾄ |
1 | ||
| 90407-16009 |
KDH20#,211,22#,TRH21#,22#..4FC ｱｳﾄﾚｯﾄ |
1 | ||
| 90407-16012 |
KDH201,206,211,221,223,TRH21#,22#..4FC ｲﾝﾚｯﾄ |
1 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90407-14024 |
KDH20#,22#..4FC ｲﾝﾚｯﾄ |
1 | ||
| 90407-16009 |
KDH20#,211,22#,TRH21#,22#..4FC ｱｳﾄﾚｯﾄ |
1 | ||
| 90407-16012 |
KDH201,206,211,221,223,TRH21#,22#..4FC ｲﾝﾚｯﾄ |
1 | ||
| 32921D - HOSE(FOR OIL COOLER INLET) | ||||
| 90445-17178 |
KDH20#,211,22#..4FC |
1 | ||
| 32941-26200 |
TRH200,21#,22#..4FC |
1 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-11006 |
KDH20#,22#..4FC |
2 | ||
| 90301-11030 |
KDH201,206,211,221,223,TRH21#,22#..4FC |
2 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-11006 |
KDH20#,22#..4FC |
2 | ||
| 90301-11030 |
KDH201,206,211,221,223,TRH21#,22#..4FC |
2 | ||
| 32921J - CLIP(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,211,22#,TRH200,21#,22#..4FC |
2 | ||
| 32921J - CLIP(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,211,22#,TRH200,21#,22#..4FC |
2 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32922 - TUBE, OIL COOLER OUTLET, NO.1 | ||||
| 32922-26360 |
TRH21#,22# |
1 | ||
| 32922-26370 |
KDH20#,22#..4FC |
1 | ||
| 32922A - HOSE(FOR OIL COOLER OUTLET) | ||||
| 90445-17073 |
TRH200,21#,22#..4FC |
1 | ||
| 32942-26140 |
KDH20#,211,22#..4FC |
1 | ||
| 32923 - CLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE | ||||
| 32929-24060 |
KDH20#,211,22#,TRH21#,22#..4FC |
1 | ||
| 32923B - CLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE, NO.1 | ||||
| 32909-35190 |
KDH200,201,211,220,221,222,223..4FC |
1 | ||
| 32909-26180 |
TRH200,21#,22#..4FC |
1 | ||
| 32923C - CLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE, NO.4 | ||||
| 32909-26190 |
KDH20#,22#..4FC |
1 | ||
| 32909-34040 |
TRH200,21#,22#..4FC |
1 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32941 - HOSE, OIL COOLER INLET, NO.1 | ||||
| 32941-26180 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224..4FC |
2 | ||
| 32941 - HOSE, OIL COOLER INLET, NO.1 | ||||
| 32941-26180 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224..4FC |
2 | ||
| Common parts | ||||
| 90119-08650 | ||||
| 91611-61014 | ||||
| 91611-B0614 | ||||
| 91611-G0612 | ||||
| 91651-60816 | ||||
(0408- )KDH20#,211,22#..4FC
A340,A340F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 32907 - TUBE SUB-ASSY, OIL COOLER OUTLET, NO.2 | ||||
| 32907-26050 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224..4FC |
1 | ||
| 32907 - TUBE SUB-ASSY, OIL COOLER OUTLET, NO.2 | ||||
| 32907-26050 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224..4FC |
1 | ||
| 32921 - TUBE, OIL COOLER INLET, NO.1 | ||||
| 32921-26380 |
KDH20#,22#..4FC |
1 | ||
| 32921-26370 |
TRH21#,22# |
1 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90407-14024 |
KDH20#,22#..4FC ｲﾝﾚｯﾄ |
1 | ||
| 90407-16009 |
KDH20#,211,22#,TRH21#,22#..4FC ｱｳﾄﾚｯﾄ |
1 | ||
| 90407-16012 |
KDH201,206,211,221,223,TRH21#,22#..4FC ｲﾝﾚｯﾄ |
1 | ||
| 32921C - UNION(FOR OIL COOLER TUBE) | ||||
| 90407-14024 |
KDH20#,22#..4FC ｲﾝﾚｯﾄ |
1 | ||
| 90407-16009 |
KDH20#,211,22#,TRH21#,22#..4FC ｱｳﾄﾚｯﾄ |
1 | ||
| 90407-16012 |
KDH201,206,211,221,223,TRH21#,22#..4FC ｲﾝﾚｯﾄ |
1 | ||
| 32921D - HOSE(FOR OIL COOLER INLET) | ||||
| 90445-17178 |
KDH20#,211,22#..4FC |
1 | ||
| 32941-26200 |
TRH200,21#,22#..4FC |
1 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-11006 |
KDH20#,22#..4FC |
2 | ||
| 90301-11030 |
KDH201,206,211,221,223,TRH21#,22#..4FC |
2 | ||
| 32921G - RING, O(FOR OIL COOLER TUBE UNION) | ||||
| 90301-11006 |
KDH20#,22#..4FC |
2 | ||
| 90301-11030 |
KDH201,206,211,221,223,TRH21#,22#..4FC |
2 | ||
| 32921J - CLIP(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,211,22#,TRH200,21#,22#..4FC |
2 | ||
| 32921J - CLIP(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,211,22#,TRH200,21#,22#..4FC |
2 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32921R - CLIP, NO.2(FOR OIL COOLER HOSE) | ||||
| 90467-16022 |
KDH20#,22#,TRH200,21#,22#..4FC |
6 | ||
| 32922 - TUBE, OIL COOLER OUTLET, NO.1 | ||||
| 32922-26360 |
TRH21#,22# |
1 | ||
| 32922-26370 |
KDH20#,22#..4FC |
1 | ||
| 32922A - HOSE(FOR OIL COOLER OUTLET) | ||||
| 90445-17073 |
TRH200,21#,22#..4FC |
1 | ||
| 32942-26140 |
KDH20#,211,22#..4FC |
1 | ||
| 32923 - CLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE | ||||
| 32929-24060 |
KDH20#,211,22#,TRH21#,22#..4FC |
1 | ||
| 32923B - CLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE, NO.1 | ||||
| 32909-35190 |
KDH200,201,211,220,221,222,223..4FC |
1 | ||
| 32909-26180 |
TRH200,21#,22#..4FC |
1 | ||
| 32923C - CLAMP, AUTOMATIC TRANSMISSION OIL COOLER TUBE, NO.4 | ||||
| 32909-26190 |
KDH20#,22#..4FC |
1 | ||
| 32909-34040 |
TRH200,21#,22#..4FC |
1 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32926 - CUSHION, OIL COOLER TUBE(ATM) | ||||
| 32926-30030 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.1 |
2 | ||
| 32926-30020 |
TRH200,21#,22#..4FC 長さ=35,内径=10,NO.2 |
4 | ||
| 32926-30020 |
KDH20#,211,22#..4FC 長さ=35,内径=10 |
6 | ||
| 32941 - HOSE, OIL COOLER INLET, NO.1 | ||||
| 32941-26180 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224..4FC |
2 | ||
| 32941 - HOSE, OIL COOLER INLET, NO.1 | ||||
| 32941-26180 |
KDH200,201,211,220,221,222,223,TRH200,211,214,221,223,224..4FC |
2 | ||
| Common parts | ||||
| 90119-08650 | ||||
| 91611-60814 | ||||
| 91611-B0614 | ||||
| 91611-G0612 | ||||
| 91619-61216 | ||||
| 91651-60816 | ||||
| Linked diagrams | ||||
| 8410 | ||||
(1312- )TRH21#,22#..4FC
A343E,A343F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08650 | ||||
| 91611-G0612 | ||||
| 91612-B1014 | ||||
| 91651-60816 | ||||
(1312- )KDH20#,211,22#..4FC
A340E,A340F
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| Common parts | ||||
| 90119-08650 | ||||
| 91611-60814 | ||||
| 91611-G0612 | ||||
| 91619-61216 | ||||
| 91651-60816 | ||||
| Linked diagrams | ||||
| 8410 | ||||
