KDH222B-LEPDY (2005)
Toyota Hiace/Regiusace
(0408- )1KDFTV,2KDFTV
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 13505 - IDLER SUB-ASSY, TIMING BELT, NO.1 | ||||
| 13505-67041 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13511 - CAMSHAFT | ||||
| 13501-30030 |
2KDFTV..KDH20#,22# |
1 | ||
| 13512 - CAMSHAFT, NO.2 | ||||
| 13502-30020 |
2KDFTV..KDH20#,22# |
1 | ||
| 13515A - WASHER, PLATE(FOR DISTRIBUTOR DRIVE GEAR) | ||||
| 90201-10124 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13522P - PULLEY, PUMP DRIVE SHAFT | ||||
| 13524-30010 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13523A - KEY, WOODRUFF(FOR TIMING GEAR) | ||||
| 90280-05004 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13523P - PULLEY, CAMSHAFT TIMING | ||||
| 13523-17010 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13540E - TENSIONER ASSY, TIMING BELT | ||||
| 13540-67020 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13556 - SHAFT, TIMING BELT IDLER | ||||
| 13556-67010 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13568 - BELT, TIMING | ||||
| 13568-39015 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13586 - FLANGE, CAMSHAFT TIMING PULLEY, NO.2 | ||||
| 13586-17020 |
1KDFTV,2KDFTV..KDH20#,211,22# |
1 | ||
| 13711 - VALVE, INTAKE | ||||
| 13711-30040 |
2KDFTV..KDH20#,22# |
8 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90905-01077 |
1KDFTV,2KDFTV..KDH20#,211,22# |
16 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90905-01077 |
1KDFTV,2KDFTV..KDH20#,211,22# |
16 | ||
| 13711D - WASHER, PLATE(FOR VALVE SPRING SEAT) | ||||
| 90201-16023 |
1KDFTV,2KDFTV..KDH20#,211,22# |
16 | ||
| 13711D - WASHER, PLATE(FOR VALVE SPRING SEAT) | ||||
| 90201-16023 |
1KDFTV,2KDFTV..KDH20#,211,22# |
16 | ||
| 13711E - SEAL, INTAKE VALVE STEM OIL | ||||
| 90913-02121 |
1KDFTV,2KDFTV..KDH20#,211,22# |
8 | ||
| 13715 - VALVE, EXHAUST | ||||
| 13715-30040 |
2KDFTV..KDH20#,22# |
8 | ||
| 13715A - SEAL, EXHAUST VALVE STEM OIL | ||||
| 90913-02121 |
1KDFTV,2KDFTV..KDH20#,211,22# |
8 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-15020 |
1KDFTV,2KDFTV..KDH20#,211,22# |
16 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-15020 |
1KDFTV,2KDFTV..KDH20#,211,22# |
16 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03021 |
1KDFTV,2KDFTV..KDH20#,211,22# |
32 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03021 |
1KDFTV,2KDFTV..KDH20#,211,22# |
32 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-46060 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.12,修理書参照 |
16 | ||
| 13751-46070 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.14,修理書参照 |
16 | ||
| 13751-46040 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.08,修理書参照 |
16 | ||
| 13751-46030 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.06,修理書参照 |
16 | ||
| 13751-46140 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.28,修理書参照 |
16 | ||
| 13751-46050 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.10,修理書参照 |
16 | ||
| 13751-46080 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.16,修理書参照 |
16 | ||
| 13751-46130 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.26,修理書参照 |
16 | ||
| 13751-46150 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.30,修理書参照 |
16 | ||
| 13751-46100 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.20,修理書参照 |
16 | ||
| 13751-46180 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.36,修理書参照 |
16 | ||
| 13751-46110 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.22,修理書参照 |
16 | ||
| 13751-46090 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.18,修理書参照 |
16 | ||
| 13751-46200 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.40,修理書参照 |
16 | ||
| 13751-46190 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.38,修理書参照 |
16 | ||
| 13751-46160 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.32,修理書参照 |
16 | ||
| 13751-46250 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.50,修理書参照 |
16 | ||
| 13751-46230 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.46,修理書参照 |
16 | ||
| 13751-46120 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.24,修理書参照 |
16 | ||
| 13751-46300 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.60,修理書参照 |
16 | ||
| 13751-46210 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.42,修理書参照 |
16 | ||
| 13751-46280 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.56,修理書参照 |
16 | ||
| 13751-46260 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.52,修理書参照 |
16 | ||
| 13751-46170 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.34,修理書参照 |
16 | ||
| 13751-46270 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.54,修理書参照 |
16 | ||
| 13751-46220 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.44,修理書参照 |
16 | ||
| 13751-46240 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.48,修理書参照 |
16 | ||
| 13751-46290 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.58,修理書参照 |
16 | ||
| 13751-46340 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.68,修理書参照 |
16 | ||
| 13751-46330 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.66,修理書参照 |
16 | ||
| 13751-46350 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.70,修理書参照 |
16 | ||
| 13751-46320 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.64,修理書参照 |
16 | ||
| 13751-46310 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.62,修理書参照 |
16 | ||
| 13751-46370 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.74,修理書参照 |
16 | ||
| 13751-46360 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.72,修理書参照 |
16 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-46060 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.12,修理書参照 |
16 | ||
| 13751-46070 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.14,修理書参照 |
16 | ||
| 13751-46040 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.08,修理書参照 |
16 | ||
| 13751-46030 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.06,修理書参照 |
16 | ||
| 13751-46140 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.28,修理書参照 |
16 | ||
| 13751-46050 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.10,修理書参照 |
16 | ||
| 13751-46080 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.16,修理書参照 |
16 | ||
| 13751-46130 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.26,修理書参照 |
16 | ||
| 13751-46150 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.30,修理書参照 |
16 | ||
| 13751-46100 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.20,修理書参照 |
16 | ||
| 13751-46180 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.36,修理書参照 |
16 | ||
| 13751-46110 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.22,修理書参照 |
16 | ||
| 13751-46090 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.18,修理書参照 |
16 | ||
| 13751-46200 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.40,修理書参照 |
16 | ||
| 13751-46190 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.38,修理書参照 |
16 | ||
| 13751-46160 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.32,修理書参照 |
16 | ||
| 13751-46250 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.50,修理書参照 |
16 | ||
| 13751-46230 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.46,修理書参照 |
16 | ||
| 13751-46120 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.24,修理書参照 |
16 | ||
| 13751-46300 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.60,修理書参照 |
16 | ||
| 13751-46210 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.42,修理書参照 |
16 | ||
| 13751-46280 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.56,修理書参照 |
16 | ||
| 13751-46260 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.52,修理書参照 |
16 | ||
| 13751-46170 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.34,修理書参照 |
16 | ||
| 13751-46270 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.54,修理書参照 |
16 | ||
| 13751-46220 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.44,修理書参照 |
16 | ||
| 13751-46240 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.48,修理書参照 |
16 | ||
| 13751-46290 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.58,修理書参照 |
16 | ||
| 13751-46340 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.68,修理書参照 |
16 | ||
| 13751-46330 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.66,修理書参照 |
16 | ||
| 13751-46350 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.70,修理書参照 |
16 | ||
| 13751-46320 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.64,修理書参照 |
16 | ||
| 13751-46310 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.62,修理書参照 |
16 | ||
| 13751-46370 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.74,修理書参照 |
16 | ||
| 13751-46360 |
1KDFTV,2KDFTV..KDH20#,211,22# 厚さ=5.72,修理書参照 |
16 | ||
| Common parts | ||||
| 90105-08100 | ||||
| 90119-14005 | ||||
| 91551-80620 | ||||
