AHR20W-GRXQB (2006)
Toyota Estima Hybrid
(0606- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 11811 - BEARING, CAMSHAFT, NO.1 | ||||
| 11811-2801003 |
2AZFXE..AHR20..CBU MARK 3,修理書参照 |
1 | ||
| 11811-2801002 |
2AZFXE..AHR20..CBU MARK 2,修理書参照 |
1 | ||
| 11811-2801001 |
2AZFXE..AHR20..CBU MARK 1,修理書参照 |
1 | ||
| 11821 - BEARING, CAMSHAFT, NO.2 | ||||
| 11821-2801001 |
2AZFXE..AHR20..CBU MARK 1,修理書参照 |
1 | ||
| 11821-2801003 |
2AZFXE..AHR20..CBU MARK 3,修理書参照 |
1 | ||
| 11821-2801002 |
2AZFXE..AHR20..CBU MARK 2,修理書参照 |
1 | ||
| 13050 - GEAR ASSY, CAMSHAFT TIMING | ||||
| 13050-28021 |
2AZFXE..AHR20..CBU |
1 | ||
| 13506 - CHAIN SUB-ASSY | ||||
| 13506-28020 |
2AZFXE..AHR20..CBU TYPE B:ｲﾗｽﾄ参照 |
1 | ||
| 13506-28011 |
2AZFXE..AHR20..CBU TYPE A:ｲﾗｽﾄ参照 |
1 | ||
| 13507 - CHAIN SUB-ASSY, NO.2 | ||||
| 13507-28010 |
2AZFXE..AHR20..CBU |
1 | ||
| 13511 - CAMSHAFT | ||||
| 13501-28070 |
2AZFXE..AHR20..CBU |
1 | ||
| 13512 - CAMSHAFT, NO.2 | ||||
| 13502-0H030 |
2AZFXE..AHR20..CBU (L) |
1 | ||
| 13502-28030 |
2AZFXE..AHR20..CBU (J) |
1 | ||
| 13523 - GEAR OR SPROCKET, CAMSHAFT TIMING | ||||
| 13523-22020 |
2AZFXE..AHR20..CBU |
1 | ||
| 13540 - TENSIONER ASSY, CHAIN, NO.1 | ||||
| 13540-28010 |
2AZFXE..AHR20..CBU |
1 | ||
| 13540C - GASKET(FOR CHAIN TENSIONER) | ||||
| 13552-28010 |
2AZFXE..AHR20..CBU |
1 | ||
| 13549 - PLATE, CHAIN TENSIONER | ||||
| 13549-28012 |
2AZFXE..AHR20..CBU |
1 | ||
| 13559 - SLIPPER, CHAIN TENSIONER | ||||
| 13559-28010 |
2AZFXE..AHR20..CBU |
1 | ||
| 13561 - DAMPER, CHAIN VIBRATION, NO.1 | ||||
| 13561-28010 |
2AZFXE..AHR20..CBU |
1 | ||
| 13565 - SPRING, CHAIN DAMPER | ||||
| 13565-28012 |
2AZFXE..AHR20..CBU |
1 | ||
| 13566B - GUIDE, TIMING CHAIN | ||||
| 13566-28010 |
2AZFXE..AHR20..CBU |
1 | ||
| 13711 - VALVE, INTAKE | ||||
| 13711-28010 |
2AZFXE..AHR20..CBU |
8 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90501-28038 |
2AZFXE..AHR20..CBU |
16 | ||
| 13711B - SPRING, COMPRESSION(FOR INNER) | ||||
| 90501-28038 |
2AZFXE..AHR20..CBU |
16 | ||
| 13711E - SEAL, INTAKE VALVE STEM OIL | ||||
| 90913-02101 |
2AZFXE..AHR20..CBU |
8 | ||
| 13715 - VALVE, EXHAUST | ||||
| 13715-28010 |
2AZFXE..AHR20..CBU |
8 | ||
| 13715A - SEAL, EXHAUST VALVE STEM OIL | ||||
| 90913-02112 |
2AZFXE..AHR20..CBU |
8 | ||
| 13734 - SEAT, VALVE SPRING | ||||
| 13734-74010 |
2AZFXE..AHR20..CBU |
16 | ||
| 13734 - SEAT, VALVE SPRING | ||||
| 13734-74010 |
2AZFXE..AHR20..CBU |
16 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-22021 |
2AZFXE..AHR20..CBU |
16 | ||
| 13741 - RETAINER, VALVE SPRING | ||||
| 13741-22021 |
2AZFXE..AHR20..CBU |
16 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03028 |
2AZFXE..AHR20..CBU |
32 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03028 |
2AZFXE..AHR20..CBU |
32 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03028 |
2AZFXE..AHR20..CBU |
32 | ||
| 13741A - LOCK, VALVE SPRING RETAINER | ||||
| 90913-03028 |
2AZFXE..AHR20..CBU |
32 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-22040 |
2AZFXE..AHR20..CBU 厚さ=5.06 |
16 | ||
| 13751-22100 |
2AZFXE..AHR20..CBU 厚さ=5.18 |
16 | ||
| 13751-22070 |
2AZFXE..AHR20..CBU 厚さ=5.12 |
16 | ||
| 13751-22130 |
2AZFXE..AHR20..CBU 厚さ=5.24 |
16 | ||
| 13751-22170 |
2AZFXE..AHR20..CBU 厚さ=5.32 |
16 | ||
| 13751-22080 |
2AZFXE..AHR20..CBU 厚さ=5.14 |
16 | ||
| 13751-22150 |
2AZFXE..AHR20..CBU 厚さ=5.28 |
16 | ||
| 13751-22090 |
2AZFXE..AHR20..CBU 厚さ=5.16 |
16 | ||
| 13751-22180 |
2AZFXE..AHR20..CBU 厚さ=5.34 |
16 | ||
| 13751-22200 |
2AZFXE..AHR20..CBU 厚さ=5.38 |
16 | ||
| 13751-22210 |
2AZFXE..AHR20..CBU 厚さ=5.40 |
16 | ||
| 13751-22190 |
2AZFXE..AHR20..CBU 厚さ=5.36 |
16 | ||
| 13751-22050 |
2AZFXE..AHR20..CBU 厚さ=5.08 |
16 | ||
| 13751-22110 |
2AZFXE..AHR20..CBU 厚さ=5.20 |
16 | ||
| 13751-22060 |
2AZFXE..AHR20..CBU 厚さ=5.10 |
16 | ||
| 13751-22160 |
2AZFXE..AHR20..CBU 厚さ=5.30 |
16 | ||
| 13751-22220 |
2AZFXE..AHR20..CBU 厚さ=5.42 |
16 | ||
| 13751-22270 |
2AZFXE..AHR20..CBU 厚さ=5.52 |
16 | ||
| 13751-22340 |
2AZFXE..AHR20..CBU 厚さ=5.66 |
16 | ||
| 13751-22230 |
2AZFXE..AHR20..CBU 厚さ=5.44 |
16 | ||
| 13751-22290 |
2AZFXE..AHR20..CBU 厚さ=5.56 |
16 | ||
| 13751-22310 |
2AZFXE..AHR20..CBU 厚さ=5.60 |
16 | ||
| 13751-22330 |
2AZFXE..AHR20..CBU 厚さ=5.64 |
16 | ||
| 13751-22140 |
2AZFXE..AHR20..CBU 厚さ=5.26 |
16 | ||
| 13751-22300 |
2AZFXE..AHR20..CBU 厚さ=5.58 |
16 | ||
| 13751-22320 |
2AZFXE..AHR20..CBU 厚さ=5.62 |
16 | ||
| 13751-22120 |
2AZFXE..AHR20..CBU 厚さ=5.22 |
16 | ||
| 13751-22380 |
2AZFXE..AHR20..CBU 厚さ=5.74 |
16 | ||
| 13751-22250 |
2AZFXE..AHR20..CBU 厚さ=5.48 |
16 | ||
| 13751-22360 |
2AZFXE..AHR20..CBU 厚さ=5.70 |
16 | ||
| 13751-22350 |
2AZFXE..AHR20..CBU 厚さ=5.68 |
16 | ||
| 13751-22260 |
2AZFXE..AHR20..CBU 厚さ=5.50 |
16 | ||
| 13751-22370 |
2AZFXE..AHR20..CBU 厚さ=5.72 |
16 | ||
| 13751-22240 |
2AZFXE..AHR20..CBU 厚さ=5.46 |
16 | ||
| 13751-22280 |
2AZFXE..AHR20..CBU 厚さ=5.54 |
16 | ||
| 13751 - LIFTER, VALVE | ||||
| 13751-22040 |
2AZFXE..AHR20..CBU 厚さ=5.06 |
16 | ||
| 13751-22100 |
2AZFXE..AHR20..CBU 厚さ=5.18 |
16 | ||
| 13751-22070 |
2AZFXE..AHR20..CBU 厚さ=5.12 |
16 | ||
| 13751-22130 |
2AZFXE..AHR20..CBU 厚さ=5.24 |
16 | ||
| 13751-22170 |
2AZFXE..AHR20..CBU 厚さ=5.32 |
16 | ||
| 13751-22080 |
2AZFXE..AHR20..CBU 厚さ=5.14 |
16 | ||
| 13751-22150 |
2AZFXE..AHR20..CBU 厚さ=5.28 |
16 | ||
| 13751-22090 |
2AZFXE..AHR20..CBU 厚さ=5.16 |
16 | ||
| 13751-22180 |
2AZFXE..AHR20..CBU 厚さ=5.34 |
16 | ||
| 13751-22200 |
2AZFXE..AHR20..CBU 厚さ=5.38 |
16 | ||
| 13751-22210 |
2AZFXE..AHR20..CBU 厚さ=5.40 |
16 | ||
| 13751-22190 |
2AZFXE..AHR20..CBU 厚さ=5.36 |
16 | ||
| 13751-22050 |
2AZFXE..AHR20..CBU 厚さ=5.08 |
16 | ||
| 13751-22110 |
2AZFXE..AHR20..CBU 厚さ=5.20 |
16 | ||
| 13751-22060 |
2AZFXE..AHR20..CBU 厚さ=5.10 |
16 | ||
| 13751-22160 |
2AZFXE..AHR20..CBU 厚さ=5.30 |
16 | ||
| 13751-22220 |
2AZFXE..AHR20..CBU 厚さ=5.42 |
16 | ||
| 13751-22270 |
2AZFXE..AHR20..CBU 厚さ=5.52 |
16 | ||
| 13751-22340 |
2AZFXE..AHR20..CBU 厚さ=5.66 |
16 | ||
| 13751-22230 |
2AZFXE..AHR20..CBU 厚さ=5.44 |
16 | ||
| 13751-22290 |
2AZFXE..AHR20..CBU 厚さ=5.56 |
16 | ||
| 13751-22310 |
2AZFXE..AHR20..CBU 厚さ=5.60 |
16 | ||
| 13751-22330 |
2AZFXE..AHR20..CBU 厚さ=5.64 |
16 | ||
| 13751-22140 |
2AZFXE..AHR20..CBU 厚さ=5.26 |
16 | ||
| 13751-22300 |
2AZFXE..AHR20..CBU 厚さ=5.58 |
16 | ||
| 13751-22320 |
2AZFXE..AHR20..CBU 厚さ=5.62 |
16 | ||
| 13751-22120 |
2AZFXE..AHR20..CBU 厚さ=5.22 |
16 | ||
| 13751-22380 |
2AZFXE..AHR20..CBU 厚さ=5.74 |
16 | ||
| 13751-22250 |
2AZFXE..AHR20..CBU 厚さ=5.48 |
16 | ||
| 13751-22360 |
2AZFXE..AHR20..CBU 厚さ=5.70 |
16 | ||
| 13751-22350 |
2AZFXE..AHR20..CBU 厚さ=5.68 |
16 | ||
| 13751-22260 |
2AZFXE..AHR20..CBU 厚さ=5.50 |
16 | ||
| 13751-22370 |
2AZFXE..AHR20..CBU 厚さ=5.72 |
16 | ||
| 13751-22240 |
2AZFXE..AHR20..CBU 厚さ=5.46 |
16 | ||
| 13751-22280 |
2AZFXE..AHR20..CBU 厚さ=5.54 |
16 | ||
| Common parts | ||||
| 90105-10445 | ||||
| 90109-06381 | ||||
| 90109-08304 | ||||
| 90116-06063 | ||||
| 90119-10843 | ||||
| 90182-06005 | ||||
| 91621-J0612 | ||||
| 91671-80616 | ||||
