BU182-TKMQS3 (1995)
Toyota Dyna 200/Toyoace G25
(9505- )BU162,172,182
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 33481P - GEAR, SPEEDOMETER DRIVE (FOR TRANSFER) | ||||
| 33481-36220 |
BU172,182..30T;BU162,172..DM5,DM7,TW1 歯数=6,ﾏｰｸ 6:23−25 |
1 | ||
| 33481Q - KEY OR BALL, SPEEDOMETER DRIVE GEAR (FOR TRANSFER) | ||||
| 90360-06004 |
BU162,172,182 |
1 | ||
| 36155A - RING, TRANSFER OIL SEAL | ||||
| 36155-36010 |
BU162,172,182 外側 |
2 | ||
| 36155-36020 |
BU162,172,182 内側 |
2 | ||
| 36155A - RING, TRANSFER OIL SEAL | ||||
| 36155-36010 |
BU162,172,182 外側 |
2 | ||
| 36155-36020 |
BU162,172,182 内側 |
2 | ||
| 36202 - SHAFT SUB-ASSY, TRANSFER OUTPUT, REAR | ||||
| 36202-36010 |
BU162,172,182 |
1 | ||
| 36202A - NUT(FOR TRANSFER OUTPUT REAR SHAFT) | ||||
| 90179-24011 |
BU162,172,182,297 |
1 | ||
| 36202B - RING, O(FOR TRANSFER OUTPUT REAR SHAFT) | ||||
| 90301-31003 |
BU162,172,182,297 |
1 | ||
| 36203 - GEAR SUB-ASSY, TRANSFER HIGH SPEED OUTPUT | ||||
| 36203-60071 |
BU162,172,182 |
1 | ||
| 36204 - GEAR SUB-ASSY, TRANSFER LOW SPEED OUTPUT | ||||
| 36204-60090 |
BU162,172,182 |
1 | ||
| 36211 - SHAFT, TRANSFER INPUT | ||||
| 36211-60030 |
BU162,172,182,297..CBU,IV3 |
1 | ||
| 36211 - SHAFT, TRANSFER INPUT | ||||
| 36211-60030 |
BU162,172,182,297..CBU,IV3 |
1 | ||
| 36212 - GEAR, TRANSFER INPUT | ||||
| 36212-60100 |
BU162,172,182,297 |
1 | ||
| 36212 - GEAR, TRANSFER INPUT | ||||
| 36212-60100 |
BU162,172,182,297 |
1 | ||
| 36212 - GEAR, TRANSFER INPUT | ||||
| 36212-60100 |
BU162,172,182,297 |
1 | ||
| 36212A - BEARING, RADIAL BALL (FOR TRANSFER INPUT GEAR) | ||||
| 90363-35030 |
BU162,172,182,297 |
1 | ||
| 36212A - BEARING, RADIAL BALL (FOR TRANSFER INPUT GEAR) | ||||
| 90363-35030 |
BU162,172,182,297 |
1 | ||
| 36212C - RING, SHAFT SNAP (FOR TRANSFER INPUT GEAR) | ||||
| 90520-82001 |
BU162,172,182,297 厚さ=1.65 |
1 | ||
| 36212C - RING, SHAFT SNAP (FOR TRANSFER INPUT GEAR) | ||||
| 90520-82001 |
BU162,172,182,297 厚さ=1.65 |
1 | ||
| 36212D - RING, SHAFT SNAP (FOR TRANSFER INPUT BEARING) | ||||
| 90520-32006 |
BU162,172,182,297..CBU,IV3 厚さ=2.1,ﾏｰｸ B |
1 | ||
| 90520-32009 |
BU162,172,182,297..CBU,IV3 厚さ=2.4,ﾏｰｸ E |
1 | ||
| 90520-32005 |
BU162,172,182,297..CBU,IV3 厚さ=2.0,ﾏｰｸ A |
1 | ||
| 90520-32007 |
BU162,172,182,297..CBU,IV3 厚さ=2.2,ﾏｰｸ C |
1 | ||
| 90520-32008 |
BU162,172,182,297..CBU,IV3 厚さ=2.3,ﾏｰｸ D |
1 | ||
| 36212F - BEARING, RADIAL BALL (FOR TRANSFER INPUT SHAFT FRONT) | ||||
| 90363-50003 |
BU162,172,182,297 |
1 | ||
| 36212F - BEARING, RADIAL BALL (FOR TRANSFER INPUT SHAFT FRONT) | ||||
| 90363-50003 |
BU162,172,182,297 |
1 | ||
| 36212L - RING, SHAFT SNAP | ||||
| 90520-46007 |
BU162,172,182,297 厚さ=3.05−3.10,ﾏｰｸ D |
1 | ||
| 90520-46004 |
BU162,172,182,297 厚さ=2.90−2.95,ﾏｰｸ A |
1 | ||
| 90520-46008 |
BU162,172,182,297 厚さ=3.10−3.15,ﾏｰｸ E |
1 | ||
| 90520-46005 |
BU162,172,182,297 厚さ=2.95−3.00,ﾏｰｸ B |
1 | ||
| 90520-46006 |
BU162,172,182,297 厚さ=3.00−3.05,ﾏｰｸ C |
1 | ||
| 90520-46009 |
BU162,172,182,297 厚さ=3.15−3.20,ﾏｰｸ F |
1 | ||
| 36213B - RING, SHAFT SNAP (FOR TRANSFER INPUT GEAR STOPPER) | ||||
| 90520-44024 |
BU162,172,182,297 厚さ=2.2,ﾏｰｸ C |
1 | ||
| 90520-44023 |
BU162,172,182,297 厚さ=2.1,ﾏｰｸ B |
1 | ||
| 90520-44027 |
BU162,172,182,297 厚さ=2.5,ﾏｰｸ F |
1 | ||
| 90520-44026 |
BU162,172,182,297 厚さ=2.4,ﾏｰｸ E |
1 | ||
| 90520-44022 |
BU162,172,182,297 厚さ=2.0,ﾏｰｸ A |
1 | ||
| 90520-44029 |
BU162,172,182,297 厚さ=2.7,ﾏｰｸ H |
1 | ||
| 90520-44025 |
BU162,172,182,297 厚さ=2.3,ﾏｰｸ D |
1 | ||
| 90520-44030 |
BU162,172,182,297 厚さ=2.8,ﾏｰｸ J |
1 | ||
| 90520-44028 |
BU162,172,182,297 厚さ=2.6,ﾏｰｸ G |
1 | ||
| 36213B - RING, SHAFT SNAP (FOR TRANSFER INPUT GEAR STOPPER) | ||||
| 90520-44024 |
BU162,172,182,297 厚さ=2.2,ﾏｰｸ C |
1 | ||
| 90520-44023 |
BU162,172,182,297 厚さ=2.1,ﾏｰｸ B |
1 | ||
| 90520-44027 |
BU162,172,182,297 厚さ=2.5,ﾏｰｸ F |
1 | ||
| 90520-44026 |
BU162,172,182,297 厚さ=2.4,ﾏｰｸ E |
1 | ||
| 90520-44022 |
BU162,172,182,297 厚さ=2.0,ﾏｰｸ A |
1 | ||
| 90520-44029 |
BU162,172,182,297 厚さ=2.7,ﾏｰｸ H |
1 | ||
| 90520-44025 |
BU162,172,182,297 厚さ=2.3,ﾏｰｸ D |
1 | ||
| 90520-44030 |
BU162,172,182,297 厚さ=2.8,ﾏｰｸ J |
1 | ||
| 90520-44028 |
BU162,172,182,297 厚さ=2.6,ﾏｰｸ G |
1 | ||
| 36221 - GEAR, TRANSFER IDLER | ||||
| 36221-60110 |
BU162,172,182 |
1 | ||
| 36221B - BEARING (FOR TRANSFER IDLER GEAR) | ||||
| 90366-35059 |
BU162,172,182 |
1 | ||
| 36221D - WASHER, PLATE(FOR TRANSFER IDLER GEAR) | ||||
| 90201-61014 |
BU162,172,182 厚さ=0.30,ﾏｰｸ B |
1 | ||
| 90201-61015 |
BU162,172,182 厚さ=0.45,ﾏｰｸ C |
1 | ||
| 90201-61018 |
BU162,172,182 厚さ=1.40,ﾏｰｸ F |
1 | ||
| 90201-61019 |
BU162,172,182 厚さ=1.60,ﾏｰｸ G |
1 | ||
| 90201-61016 |
BU162,172,182 厚さ=1.00,ﾏｰｸ D |
1 | ||
| 90201-61022 |
BU162,172,182 厚さ=2.20,ﾏｰｸ K |
1 | ||
| 90201-61023 |
BU162,172,182 厚さ=2.40,ﾏｰｸ L |
1 | ||
| 90201-61017 |
BU162,172,182 厚さ=1.20,ﾏｰｸ E |
1 | ||
| 90201-61024 |
BU162,172,182 厚さ=0.55,ﾏｰｸ M |
1 | ||
| 90201-61021 |
BU162,172,182 厚さ=2.00,ﾏｰｸ J |
1 | ||
| 90201-61020 |
BU162,172,182 厚さ=1.80,ﾏｰｸ H |
1 | ||
| 36221D - WASHER, PLATE(FOR TRANSFER IDLER GEAR) | ||||
| 90201-61014 |
BU162,172,182 厚さ=0.30,ﾏｰｸ B |
1 | ||
| 90201-61015 |
BU162,172,182 厚さ=0.45,ﾏｰｸ C |
1 | ||
| 90201-61018 |
BU162,172,182 厚さ=1.40,ﾏｰｸ F |
1 | ||
| 90201-61019 |
BU162,172,182 厚さ=1.60,ﾏｰｸ G |
1 | ||
| 90201-61016 |
BU162,172,182 厚さ=1.00,ﾏｰｸ D |
1 | ||
| 90201-61022 |
BU162,172,182 厚さ=2.20,ﾏｰｸ K |
1 | ||
| 90201-61023 |
BU162,172,182 厚さ=2.40,ﾏｰｸ L |
1 | ||
| 90201-61017 |
BU162,172,182 厚さ=1.20,ﾏｰｸ E |
1 | ||
| 90201-61024 |
BU162,172,182 厚さ=0.55,ﾏｰｸ M |
1 | ||
| 90201-61021 |
BU162,172,182 厚さ=2.00,ﾏｰｸ J |
1 | ||
| 90201-61020 |
BU162,172,182 厚さ=1.80,ﾏｰｸ H |
1 | ||
| 36221E - BEARING, RADIAL BALL (FOR TRANSFER IDLER GEAR) | ||||
| 90366-33001 |
BU162,172,182 |
1 | ||
| 36231C - BEARING, TAPER ROLLER (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90366-38007 |
BU162,172,182 ﾘﾔ |
1 | ||
| 90366-35058 |
BU162,172,182 ﾌﾛﾝﾄ |
1 | ||
| 36231C - BEARING, TAPER ROLLER (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90366-38007 |
BU162,172,182 ﾘﾔ |
1 | ||
| 90366-35058 |
BU162,172,182 ﾌﾛﾝﾄ |
1 | ||
| 36231E - BEARING, NEEDLE ROLLER (FOR TRANSFER OUTPUT SHAFT FRONT | ||||
| 90364-42001 |
BU162,172,182 ﾌﾛﾝﾄ |
1 | ||
| 90364-43005 |
BU162,172,182 ﾘﾔ |
1 | ||
| 36231E - BEARING, NEEDLE ROLLER (FOR TRANSFER OUTPUT SHAFT FRONT | ||||
| 90364-42001 |
BU162,172,182 ﾌﾛﾝﾄ |
1 | ||
| 90364-43005 |
BU162,172,182 ﾘﾔ |
1 | ||
| 36231F - RING, SHAFT SNAP (FOR TRANSFER OUTPUT SHAFT) | ||||
| 90520-32005 |
BU162,172,182 厚さ=2.0,ﾏｰｸ A |
1 | ||
| 90520-32007 |
BU162,172,182 厚さ=2.2,ﾏｰｸ C |
1 | ||
| 90520-32006 |
BU162,172,182 厚さ=2.1,ﾏｰｸ B |
1 | ||
| 90520-32009 |
BU162,172,182 厚さ=2.4,ﾏｰｸ E |
1 | ||
| 90520-32008 |
BU162,172,182 厚さ=2.3,ﾏｰｸ D |
1 | ||
| 36231H - BEARING, RADIAL BALL (FOR TRANSFER OUTPUT SHAFT FRONT) | ||||
| 90363-40044 |
BU162,172,182,297 |
1 | ||
| 36231J - BEARING, RADIAL BALL (FOR TRANSFER OUTPUT SHAFT REAR) | ||||
| 90363-38002 |
BU162,172,182 |
1 | ||
| 36231K - WASHER, PLATE(FOR TRANSFER OUTPUT REAR CASE) | ||||
| 90201-76002 |
BU162,172,182 厚さ=0.29−0.31,ﾏｰｸ 2 |
1 | ||
| 90201-76003 |
BU162,172,182 厚さ=0.44−0.46,ﾏｰｸ 3 |
1 | ||
| 90201-76004 |
BU162,172,182 厚さ=0.99−1.01,ﾏｰｸ 4 |
1 | ||
| 90201-76008 |
BU162,172,182 厚さ=1.79−1.81,ﾏｰｸ 8 |
1 | ||
| 90201-76007 |
BU162,172,182 厚さ=1.59−1.61,ﾏｰｸ 7 |
1 | ||
| 90201-76006 |
BU162,172,182 厚さ=1.39−1.41,ﾏｰｸ 6 |
1 | ||
| 90201-76005 |
BU162,172,182 厚さ=1.19−1.21,ﾏｰｸ 5 |
1 | ||
| 90201-76012 |
BU162,172,182 厚さ=2.59−2.61,ﾏｰｸ 12 |
1 | ||
| 90201-76013 |
BU162,172,182 厚さ=0.51−0.59,ﾏｰｸ 13 |
1 | ||
| 90201-76009 |
BU162,172,182 厚さ=1.99−2.01,ﾏｰｸ 9 |
1 | ||
| 90201-76010 |
BU162,172,182 厚さ=2.19−2.21,ﾏｰｸ 10 |
1 | ||
| 90201-76011 |
BU162,172,182 厚さ=2.39−2.41,ﾏｰｸ 11 |
1 | ||
| 36231K - WASHER, PLATE(FOR TRANSFER OUTPUT REAR CASE) | ||||
| 90201-76002 |
BU162,172,182 厚さ=0.29−0.31,ﾏｰｸ 2 |
1 | ||
| 90201-76003 |
BU162,172,182 厚さ=0.44−0.46,ﾏｰｸ 3 |
1 | ||
| 90201-76004 |
BU162,172,182 厚さ=0.99−1.01,ﾏｰｸ 4 |
1 | ||
| 90201-76008 |
BU162,172,182 厚さ=1.79−1.81,ﾏｰｸ 8 |
1 | ||
| 90201-76007 |
BU162,172,182 厚さ=1.59−1.61,ﾏｰｸ 7 |
1 | ||
| 90201-76006 |
BU162,172,182 厚さ=1.39−1.41,ﾏｰｸ 6 |
1 | ||
| 90201-76005 |
BU162,172,182 厚さ=1.19−1.21,ﾏｰｸ 5 |
1 | ||
| 90201-76012 |
BU162,172,182 厚さ=2.59−2.61,ﾏｰｸ 12 |
1 | ||
| 90201-76013 |
BU162,172,182 厚さ=0.51−0.59,ﾏｰｸ 13 |
1 | ||
| 90201-76009 |
BU162,172,182 厚さ=1.99−2.01,ﾏｰｸ 9 |
1 | ||
| 90201-76010 |
BU162,172,182 厚さ=2.19−2.21,ﾏｰｸ 10 |
1 | ||
| 90201-76011 |
BU162,172,182 厚さ=2.39−2.41,ﾏｰｸ 11 |
1 | ||
| 36234B - RING, SNAP (FOR TRANSFER OUTPUT FRONT SHAFT BEARING) | ||||
| 90521-84003 |
BU162,172,182,297 厚さ=1.8,ﾏｰｸ B |
1 | ||
| 90521-84002 |
BU162,172,182,297 厚さ=1.7,ﾏｰｸ A |
1 | ||
| 36235 - SLEEVE, TRANSFER HIGH & LOW CLUTCH | ||||
| 36235-60040 |
BU162,172,182,297 |
1 | ||
| 36236 - SLEEVE, FRONT DRIVE CLUTCH | ||||
| 36236-60060 |
BU162,172,182,297 |
1 | ||
| 36237 - HUB, TRANSFER CLUTCH | ||||
| 36237-60030 |
BU162,172,182 |
1 | ||
| 36237-60050 |
BU162,172,182..CBU,IV3 |
1 | ||
| 36237A - RING, SHAFT SNAP (FOR TRANSFER CLUTCH HUB) | ||||
| 90520-39017 |
BU162,172,182 厚さ=2.70,ﾏｰｸ C |
1 | ||
| 90520-39019 |
BU162,172,182 厚さ=2.80,ﾏｰｸ E |
1 | ||
| 90520-39015 |
BU162,172,182 厚さ=2.60,ﾏｰｸ A |
1 | ||
| 90520-39018 |
BU162,172,182 厚さ=2.75,ﾏｰｸ D |
1 | ||
| 90520-39020 |
BU162,172,182 厚さ=2.85,ﾏｰｸ F |
1 | ||
| 90520-39016 |
BU162,172,182 厚さ=2.65,ﾏｰｸ B |
1 | ||
| 90520-39021 |
BU162,172,182 厚さ=2.90,ﾏｰｸ G |
1 | ||
| 36239 - HUB, TRANSFER DRIVE CLUTCH | ||||
| 36239-60010 |
BU162,172,182,297 |
1 | ||
| 36239A - RING, SHAFT SNAP(FOR TRANSFER DRIVE CLUTCH HUB) | ||||
| 90520-36019 |
BU162,172,182,297 厚さ=1.8,ﾏｰｸ A |
1 | ||
| 90520-36023 |
BU162,172,182,297 厚さ=2.2,ﾏｰｸ E |
1 | ||
| 90520-36020 |
BU162,172,182,297 厚さ=1.9,ﾏｰｸ B |
1 | ||
| 90520-36021 |
BU162,172,182,297 厚さ=2.0,ﾏｰｸ C |
1 | ||
| 90520-36022 |
BU162,172,182,297 厚さ=2.1,ﾏｰｸ D |
1 | ||
| 36245 - PIECE, TRANSFER FRONT DRIVE GEAR | ||||
| 36245-60010 |
BU162,172,182 |
1 | ||
