BU142-TKPMS3 (1995)
Toyota Dyna 200/Toyoace G25
ILLUST NO. 2 OF 2(9505- )BU14#..T3..20T..IV3
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 48210 - SPRING ASSY, REAR RH | ||||
| 48210-36861 |
BU140,142..T3..20T..IV3 ﾒｲﾝ7枚ﾘｰﾌ+ｻﾌﾞ7枚ﾘｰﾌ,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
1 | ||
| 48210-37190 |
BU102..IV4;BU14#..T3..20T ﾒｲﾝ4枚ﾘｰﾌ+ｻﾌﾞ2枚ﾘｰﾌ |
1 | ||
| 48210C - BUSH(FOR REAR SPRING LEAF) | ||||
| 90389-16005 |
BU14#..T2..CBU;BU14#..(T2,T3)..20T..IV3 ﾌﾛﾝﾄ |
2 | ||
| 90389-16003 |
BU14#..T2..CBU;BU132,172,XZU130;BU14#..(T2,T3)..20T..IV3 ﾘﾔ |
2 | ||
| 90389-16003 |
BU102..IV4;BU102..T3..(275T,30T);BU14#..(T3,T4,TW4)..20T |
4 | ||
| 48211 - LEAF, REAR SPRING, NO.1 | ||||
| 48201-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48201-3B530 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48212 - LEAF, REAR SPRING, NO.2 | ||||
| 48202-3B530 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48202-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48213 - LEAF, REAR SPRING, NO.3 | ||||
| 48213-37190 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48203-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48214 - LEAF, REAR SPRING, NO.4 | ||||
| 48203-37190 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48214-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48215 - LEAF, REAR SPRING, NO.5 | ||||
| 48215-36861 |
BU14#..T3..20T..IV3 |
2 | ||
| 48216 - LEAF, REAR SPRING, NO.6 | ||||
| 48216-3B060 |
BU212..T4..IV3;BU222..T4..TD..IV3;BU212..07S..IV3..6F;BU14#..T3..20T..IV3 |
2 | ||
| 48217 - LEAF, REAR SPRING, NO.7 | ||||
| 48216-3B060 |
BU212..T4..IV3;BU222..T4..TD..IV3;BU212..07S..IV3..6F;BU14#..T3..20T..IV3 |
2 | ||
| 48220 - SPRING ASSY, REAR LH | ||||
| 48210-36861 |
BU140,142..T3..20T..IV3 ﾒｲﾝ7枚ﾘｰﾌ+ｻﾌﾞ7枚ﾘｰﾌ,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
1 | ||
| 48210-37190 |
BU102..IV4;BU14#..T3..20T ﾒｲﾝ4枚ﾘｰﾌ+ｻﾌﾞ2枚ﾘｰﾌ |
1 | ||
| 48247 - BOLT, REAR SPRING, CENTER | ||||
| 48247-36160 |
BU222..TD..IV3;BU142,XZU140..30T;BU212..(T3,T4)..IV3;BU14#..T3..20T..IV3;BU212..(06S,07S)..IV3..6F ｱﾘ(ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ),L=146 |
2 | ||
| 48247-3B550 |
BU102..IV4;BU147..T2,T3;BU140,142,145,RZU140..20T |
2 | ||
| 48261 - LEAF, REAR HELPER SPRING, NO.1 | ||||
| 48218-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48215-3B530 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48262 - LEAF, REAR HELPER SPRING, NO.2 | ||||
| 48219-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48204-3B530 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48263 - LEAF, REAR HELPER SPRING, NO.3 | ||||
| 48204-36861 |
BU14#..T3..20T..IV3 |
2 | ||
| 48264 - LEAF, REAR HELPER SPRING, NO.4 | ||||
| 48222-36861 |
BU14#..T3..20T..IV3 |
2 | ||
| 48265 - LEAF, REAR HELPER SPRING, NO.5 | ||||
| 48223-36861 |
BU14#..T3..20T..IV3 |
2 | ||
| 48266 - LEAF, REAR HELPER SPRING, NO.6 | ||||
| 48224-36861 |
BU14#..T3..20T..IV3 |
2 | ||
| 48267 - LEAF, REAR HELPER SPRING, NO.7 | ||||
| 48224-3B060 |
BU14#..T3..20T..IV3 |
2 | ||
| Common parts | ||||
| 94184-61000 | ||||
ILLUST NO. 1 OF 2(9505- )BU105..T4,TW4 ; (9505- )BU102..T4..30T ; (9505- )BU107..T4..4FC ;
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04483 - SHACKLE KIT, REAR SPRING | ||||
| 04483-36110 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 04483-36110 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 04484 - PIN KIT, REAR SPRING | ||||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48046 - SEAT SUB-ASSY, SPRING U BOLT, RH | ||||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48046 - SEAT SUB-ASSY, SPRING U BOLT, RH | ||||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48046A - BOLT, U(FOR REAR SPRING) | ||||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48047 - SEAT SUB-ASSY, SPRING U BOLT, LH | ||||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48047 - SEAT SUB-ASSY, SPRING U BOLT, LH | ||||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48344 - STOPPER, BUMPER, REAR | ||||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48414B - BRACKET, SPRING, NO.3 RH | ||||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48415B - BRACKET, SPRING, NO.3 LH | ||||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48416 - BRACKET, SPRING, NO.4 | ||||
| 48416-36190 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48416-36190 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48422A - SUPPORT, REAR SPRING PIN | ||||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48481 - SEAT, REAR SPRING, UPPER | ||||
| 48481-36040 |
BU182..T4;BU100,102,12#..ST;BU14#,202,212,222,RZU140..20T..(DSL,EFI) |
2 | ||
| 48481-36040 |
BU182..T4;BU100,102,12#..ST;BU14#,202,212,222,RZU140..20T..(DSL,EFI) |
2 | ||
| 48481-36050 |
BU222..TD;BU142..30T;BU142,147..T3..20T;BU212..T3,T4,TW1,TW4;BU102,XZU140..T3..(275T,30T);BU102,182..(T3,TW1)..(02S,06S) ｱﾘ(ABS) |
2 | ||
| 48481-36050 |
BU222..TD;BU142..30T;BU142,147..T3..20T;BU212..T3,T4,TW1,TW4;BU102,XZU140..T3..(275T,30T);BU102,182..(T3,TW1)..(02S,06S) ｱﾘ(ABS) |
2 | ||
| 48516 - BRACKET, REAR SHOCK ABSORBER, UPPER RH | ||||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48517 - BRACKET, REAR SHOCK ABSORBER, UPPER LH | ||||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 48530C - WASHER, REAR SHOCK ABSORBER CUSHION, NO.2 | ||||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 48530D - WASHER, REAR SHOCK ABSORBER CUSHION, NO.3 | ||||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 48530E - WASHER, REAR SHOCK ABSORBER CUSHION, NO.4 | ||||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48542 - PIN, SHOCK ABSORBER UPPER PIVOT, REAR | ||||
| 48542-26020 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48542-26020 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| Common parts | ||||
| 90101-16025 | ||||
| 90101-16026 | ||||
| 90119-08276 | ||||
| 90119-10355 | ||||
| 90170-16016 | ||||
| 90179-08141 | ||||
| 90179-16030 | ||||
| 90201-16035 | ||||
| 91611-61020 | ||||
| 94130-61600 | ||||
| 94184-61201 | ||||
| 94184-61601 | ||||
ILLUST NO. 1 OF 4(9505- )BU100,102..DM2,DM3,DM5,DM6,T1,T2,T3,T5,TW1,TW2 ; (9505- )BU13#,14#,17
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04483 - SHACKLE KIT, REAR SPRING | ||||
| 04483-36110 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 04483-36110 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 04484 - PIN KIT, REAR SPRING | ||||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 04484 - PIN KIT, REAR SPRING | ||||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48046 - SEAT SUB-ASSY, SPRING U BOLT, RH | ||||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48046 - SEAT SUB-ASSY, SPRING U BOLT, RH | ||||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48046A - BOLT, U(FOR REAR SPRING) | ||||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48046A - BOLT, U(FOR REAR SPRING) | ||||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48047 - SEAT SUB-ASSY, SPRING U BOLT, LH | ||||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48047 - SEAT SUB-ASSY, SPRING U BOLT, LH | ||||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48344 - STOPPER, BUMPER, REAR | ||||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344 - STOPPER, BUMPER, REAR | ||||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344 - STOPPER, BUMPER, REAR | ||||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48414B - BRACKET, SPRING, NO.3 RH | ||||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48415B - BRACKET, SPRING, NO.3 LH | ||||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48416 - BRACKET, SPRING, NO.4 | ||||
| 48416-36190 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48416-36190 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48418A - BRACKET, HELPER SPRING, FRONT | ||||
| 48418-36090 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48418-36090 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48418A - BRACKET, HELPER SPRING, FRONT | ||||
| 48418-36090 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48418-36090 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48422A - SUPPORT, REAR SPRING PIN | ||||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48422A - SUPPORT, REAR SPRING PIN | ||||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48435 - ATTACHMENT, HELPER SPRING BRACKET, NO.1 | ||||
| 48435-36050 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48435-36050 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48435 - ATTACHMENT, HELPER SPRING BRACKET, NO.1 | ||||
| 48435-36050 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48435-36050 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48475R - PLATE, DISTANCE(FOR REAR) | ||||
| 48475-36090 |
BU222..TD;BU162..DM7;BU212..T3,T4,TW1,TW4;BU142,182,XZU140..30T;BU142,147..T3..20T..IV3 ｱﾘ(ABS) |
1 | ||
| 48475-36090 |
BU222..TD;BU162..DM7;BU212..T3,T4,TW1,TW4;BU142,182,XZU140..30T;BU142,147..T3..20T..IV3 ｱﾘ(ABS) |
1 | ||
| 48481 - SEAT, REAR SPRING, UPPER | ||||
| 48481-36040 |
BU182..T4;BU100,102,12#..ST;BU14#,202,212,222,RZU140..20T..(DSL,EFI) |
2 | ||
| 48481-36040 |
BU182..T4;BU100,102,12#..ST;BU14#,202,212,222,RZU140..20T..(DSL,EFI) |
2 | ||
| 48481-36050 |
BU222..TD;BU142..30T;BU142,147..T3..20T;BU212..T3,T4,TW1,TW4;BU102,XZU140..T3..(275T,30T);BU102,182..(T3,TW1)..(02S,06S) ｱﾘ(ABS) |
2 | ||
| 48481-36050 |
BU222..TD;BU142..30T;BU142,147..T3..20T;BU212..T3,T4,TW1,TW4;BU102,XZU140..T3..(275T,30T);BU102,182..(T3,TW1)..(02S,06S) ｱﾘ(ABS) |
2 | ||
| 48516 - BRACKET, REAR SHOCK ABSORBER, UPPER RH | ||||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48517 - BRACKET, REAR SHOCK ABSORBER, UPPER LH | ||||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| Common parts | ||||
| 90101-16018 | ||||
| 90101-16021 | ||||
| 90101-16029 | ||||
| 90105-16021 | ||||
| 90119-08276 | ||||
| 90170-16016 | ||||
| 90179-08141 | ||||
| 90179-10016 | ||||
| 90179-16030 | ||||
| 90201-16035 | ||||
| 90385-13004 | ||||
| 91112-81045 | ||||
| 91611-60832 | ||||
| 91611-61030 | ||||
| 91645-C1032 | ||||
| 91651-60820 | ||||
| 94130-61600 | ||||
| 94183-60801 | ||||
| 94184-01001 | ||||
| 94184-61001 | ||||
| 94185-60800 | ||||
ILLUST NO. 1 OF 4(9505- )RZU100..LPGB ; (9505- )BU107..T4..4FC ; (9505- )BU102..T4..30T ; (
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04483 - SHACKLE KIT, REAR SPRING | ||||
| 04483-36110 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 04483-36110 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 04484 - PIN KIT, REAR SPRING | ||||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 04484 - PIN KIT, REAR SPRING | ||||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48046 - SEAT SUB-ASSY, SPRING U BOLT, RH | ||||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48046 - SEAT SUB-ASSY, SPRING U BOLT, RH | ||||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48046A - BOLT, U(FOR REAR SPRING) | ||||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48046A - BOLT, U(FOR REAR SPRING) | ||||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48047 - SEAT SUB-ASSY, SPRING U BOLT, LH | ||||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48047 - SEAT SUB-ASSY, SPRING U BOLT, LH | ||||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48344 - STOPPER, BUMPER, REAR | ||||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344 - STOPPER, BUMPER, REAR | ||||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344 - STOPPER, BUMPER, REAR | ||||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48414B - BRACKET, SPRING, NO.3 RH | ||||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48415B - BRACKET, SPRING, NO.3 LH | ||||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48416 - BRACKET, SPRING, NO.4 | ||||
| 48416-36190 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48416-36190 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48418A - BRACKET, HELPER SPRING, FRONT | ||||
| 48418-36090 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48418-36090 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48418A - BRACKET, HELPER SPRING, FRONT | ||||
| 48418-36090 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48418-36090 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48422A - SUPPORT, REAR SPRING PIN | ||||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48422A - SUPPORT, REAR SPRING PIN | ||||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48435 - ATTACHMENT, HELPER SPRING BRACKET, NO.1 | ||||
| 48435-36050 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48435-36050 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48435 - ATTACHMENT, HELPER SPRING BRACKET, NO.1 | ||||
| 48435-36050 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48435-36050 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
4 | ||
| 48475R - PLATE, DISTANCE(FOR REAR) | ||||
| 48475-36090 |
BU222..TD;BU162..DM7;BU212..T3,T4,TW1,TW4;BU142,182,XZU140..30T;BU142,147..T3..20T..IV3 ｱﾘ(ABS) |
1 | ||
| 48475-36090 |
BU222..TD;BU162..DM7;BU212..T3,T4,TW1,TW4;BU142,182,XZU140..30T;BU142,147..T3..20T..IV3 ｱﾘ(ABS) |
1 | ||
| 48481 - SEAT, REAR SPRING, UPPER | ||||
| 48481-36040 |
BU182..T4;BU100,102,12#..ST;BU14#,202,212,222,RZU140..20T..(DSL,EFI) |
2 | ||
| 48481-36040 |
BU182..T4;BU100,102,12#..ST;BU14#,202,212,222,RZU140..20T..(DSL,EFI) |
2 | ||
| 48481-36050 |
BU222..TD;BU142..30T;BU142,147..T3..20T;BU212..T3,T4,TW1,TW4;BU102,XZU140..T3..(275T,30T);BU102,182..(T3,TW1)..(02S,06S) ｱﾘ(ABS) |
2 | ||
| 48481-36050 |
BU222..TD;BU142..30T;BU142,147..T3..20T;BU212..T3,T4,TW1,TW4;BU102,XZU140..T3..(275T,30T);BU102,182..(T3,TW1)..(02S,06S) ｱﾘ(ABS) |
2 | ||
| 48516 - BRACKET, REAR SHOCK ABSORBER, UPPER RH | ||||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48517 - BRACKET, REAR SHOCK ABSORBER, UPPER LH | ||||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| Common parts | ||||
| 90101-16018 | ||||
| 90101-16021 | ||||
| 90101-16029 | ||||
| 90105-16021 | ||||
| 90119-08276 | ||||
| 90170-16016 | ||||
| 90179-08141 | ||||
| 90179-10016 | ||||
| 90179-16030 | ||||
| 90201-16035 | ||||
| 90385-13004 | ||||
| 91112-81045 | ||||
| 91611-60832 | ||||
| 91611-61030 | ||||
| 91645-C1032 | ||||
| 91651-60820 | ||||
| 94130-61600 | ||||
| 94183-60801 | ||||
| 94184-01001 | ||||
| 94184-61001 | ||||
| 94185-60800 | ||||
ILLUST NO. 2 OF 2(9505- )BU102..IV4 ; (9505- )BU14#,RZU140..20T
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 48210 - SPRING ASSY, REAR RH | ||||
| 48210-36861 |
BU140,142..T3..20T..IV3 ﾒｲﾝ7枚ﾘｰﾌ+ｻﾌﾞ7枚ﾘｰﾌ,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
1 | ||
| 48210-37190 |
BU102..IV4;BU14#..T3..20T ﾒｲﾝ4枚ﾘｰﾌ+ｻﾌﾞ2枚ﾘｰﾌ |
1 | ||
| 48210C - BUSH(FOR REAR SPRING LEAF) | ||||
| 90389-16005 |
BU14#..T2..CBU;BU14#..(T2,T3)..20T..IV3 ﾌﾛﾝﾄ |
2 | ||
| 90389-16003 |
BU14#..T2..CBU;BU132,172,XZU130;BU14#..(T2,T3)..20T..IV3 ﾘﾔ |
2 | ||
| 90389-16003 |
BU102..IV4;BU102..T3..(275T,30T);BU14#..(T3,T4,TW4)..20T |
4 | ||
| 48211 - LEAF, REAR SPRING, NO.1 | ||||
| 48201-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48201-3B530 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48212 - LEAF, REAR SPRING, NO.2 | ||||
| 48202-3B530 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48202-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48213 - LEAF, REAR SPRING, NO.3 | ||||
| 48213-37190 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48203-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48214 - LEAF, REAR SPRING, NO.4 | ||||
| 48203-37190 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48214-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48220 - SPRING ASSY, REAR LH | ||||
| 48210-36861 |
BU140,142..T3..20T..IV3 ﾒｲﾝ7枚ﾘｰﾌ+ｻﾌﾞ7枚ﾘｰﾌ,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
1 | ||
| 48210-37190 |
BU102..IV4;BU14#..T3..20T ﾒｲﾝ4枚ﾘｰﾌ+ｻﾌﾞ2枚ﾘｰﾌ |
1 | ||
| 48247 - BOLT, REAR SPRING, CENTER | ||||
| 48247-36160 |
BU222..TD..IV3;BU142,XZU140..30T;BU212..(T3,T4)..IV3;BU14#..T3..20T..IV3;BU212..(06S,07S)..IV3..6F ｱﾘ(ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ),L=146 |
2 | ||
| 48247-3B550 |
BU102..IV4;BU147..T2,T3;BU140,142,145,RZU140..20T |
2 | ||
| 48253 - SPACER, REAR SPRING, NO.1 | ||||
| 48253-3B691 |
BU14#,RZU140..20T;BU102,182..(T3,T4,TW1)..(02S,06S)..20T |
4 | ||
| 48253 - SPACER, REAR SPRING, NO.1 | ||||
| 48253-3B691 |
BU14#,RZU140..20T;BU102,182..(T3,T4,TW1)..(02S,06S)..20T |
4 | ||
| 48253D - SPACER, REAR SPRING, NO.3 | ||||
| 48216-3B060 |
BU147..T2,T3;BU222..T3..TD..IV3;BU212..T3..TD..IV3..6F;BU212..(T3,TW1)..DSL..IV3;BU140,142,145,RZU140,XZU140;BU102,182..(T3,T4,TW1)..(02S,06S)..20T ｱﾘ(ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ & ABS) |
4 | ||
| 48253D - SPACER, REAR SPRING, NO.3 | ||||
| 48216-3B060 |
BU147..T2,T3;BU222..T3..TD..IV3;BU212..T3..TD..IV3..6F;BU212..(T3,TW1)..DSL..IV3;BU140,142,145,RZU140,XZU140;BU102,182..(T3,T4,TW1)..(02S,06S)..20T ｱﾘ(ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ & ABS) |
4 | ||
| 48254 - SPACER, REAR SPRING LEAF | ||||
| 48254-3B730 |
BU102,172..TW1;BU132,14#,182..20T |
8 | ||
| 48254 - SPACER, REAR SPRING LEAF | ||||
| 48254-3B730 |
BU102,172..TW1;BU132,14#,182..20T |
8 | ||
| 48254 - SPACER, REAR SPRING LEAF | ||||
| 48254-3B730 |
BU102,172..TW1;BU132,14#,182..20T |
8 | ||
| 48254 - SPACER, REAR SPRING LEAF | ||||
| 48254-3B730 |
BU102,172..TW1;BU132,14#,182..20T |
8 | ||
| 48261 - LEAF, REAR HELPER SPRING, NO.1 | ||||
| 48218-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48215-3B530 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| 48262 - LEAF, REAR HELPER SPRING, NO.2 | ||||
| 48219-36861 |
BU14#..T3..20T..IV3 ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48204-3B530 |
BU102..IV4;BU14#..T3..20T |
2 | ||
| Common parts | ||||
| 94110-71000 | ||||
ILLUST NO. 3 OF 4(9505- )BU10#,13#,14#,172,182,202,212,222,RZU100,140,XZU130,140
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 48530C - WASHER, REAR SHOCK ABSORBER CUSHION, NO.2 | ||||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 48530C - WASHER, REAR SHOCK ABSORBER CUSHION, NO.2 | ||||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 48530C - WASHER, REAR SHOCK ABSORBER CUSHION, NO.2 | ||||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 48530D - WASHER, REAR SHOCK ABSORBER CUSHION, NO.3 | ||||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 48530D - WASHER, REAR SHOCK ABSORBER CUSHION, NO.3 | ||||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 48530D - WASHER, REAR SHOCK ABSORBER CUSHION, NO.3 | ||||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 48530E - WASHER, REAR SHOCK ABSORBER CUSHION, NO.4 | ||||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 48530E - WASHER, REAR SHOCK ABSORBER CUSHION, NO.4 | ||||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 48530E - WASHER, REAR SHOCK ABSORBER CUSHION, NO.4 | ||||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48542 - PIN, SHOCK ABSORBER UPPER PIVOT, REAR | ||||
| 48542-26020 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| Common parts | ||||
| 91611-61020 | ||||
| 94184-61201 | ||||
| 94184-61601 | ||||
ILLUST NO. 4 OF 4(9505- )BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140
| Part # | Description | Qty | Price |
|---|
ILLUST NO. 1 OF 2(9505- )BU105..06S ; (9505- )RZU100..LPGB; (9505- )BU107..T4..4FC ; (9505
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 04483 - SHACKLE KIT, REAR SPRING | ||||
| 04483-36110 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 04483-36110 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 04484 - PIN KIT, REAR SPRING | ||||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 04484-36080 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48046 - SEAT SUB-ASSY, SPRING U BOLT, RH | ||||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48046 - SEAT SUB-ASSY, SPRING U BOLT, RH | ||||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48046A - BOLT, U(FOR REAR SPRING) | ||||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48046A - BOLT, U(FOR REAR SPRING) | ||||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#..TR..20T;BU212,222..(T2,T3)..DSL 長さ=240 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16115 |
BU212..T4,TW4;BU222..T4..TD;BU142..T3..20T;BU102,132..TL4,TW1 長さ=265 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16184 |
BU112,14#,162..TR..20T;BU212,222..(T2,T3,TW1)..DSL 長さ=240 |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16018 |
BU222..TD..IV3..5F;BU142..T3..20T..IV3;BU202,212..(T3,T4,TW1,TW4)..IV3..(4FC,5F) 長さ=300,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16022 |
BU140,142..T3..20T..IV3 長さ=280,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
4 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 90117-16025 |
BU142..T3..20T..IV3;BU212,222..TD..IV3..5F;BU212..(06S,07S)..IV3..5F 長さ=305,ｷﾖｳｶ ｽﾌﾟﾘﾝｸﾞ |
2 | ||
| 48047 - SEAT SUB-ASSY, SPRING U BOLT, LH | ||||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48047 - SEAT SUB-ASSY, SPRING U BOLT, LH | ||||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36100 |
BU182..T4;BU13#,14#,202,212,222,RZU140..20T..(DSL,EFI) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48473-36110 |
BU222..TD;BU142..30T;BU102..275T;BU142..T3..20T;BU212..T3,T4,TW1,TW4;BU132,147,182,XZU130,140..DM7,T3,TL4;BU102,172..(T3,T4,TW1)..(02S,05S,06S) ｱﾘ(ABS) |
1 | ||
| 48344 - STOPPER, BUMPER, REAR | ||||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48344-36190 |
BU142..30T;BU142..T3..20T;BU140,145,147,XZU140..T3 |
2 | ||
| 48414B - BRACKET, SPRING, NO.3 RH | ||||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48415B - BRACKET, SPRING, NO.3 LH | ||||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48414-36210 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48416 - BRACKET, SPRING, NO.4 | ||||
| 48416-36190 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48416-36190 |
BU102..IV4;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB);BU13#,14#,172,182,202,212,222,RZU140,XZU130,140 |
2 | ||
| 48422A - SUPPORT, REAR SPRING PIN | ||||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48422-36030 |
BU102..IV4;BU14#,182,202,212,222,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 48516 - BRACKET, REAR SHOCK ABSORBER, UPPER RH | ||||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48517 - BRACKET, REAR SHOCK ABSORBER, UPPER LH | ||||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48505-36050 |
BU100,105,107,14#,182,202,212,RZU140..WT..20T;BU102,RZU100..(DM3,DM6,T2,T3,T4,T5,TW1,TW4)..WT |
1 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48530 - ABSORBER ASSY, SHOCK, REAR RH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530A - BUSH(FOR REAR SHOCK ABSORBER) | ||||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 90385-16011 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
4 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 48530B - WASHER, REAR SHOCK ABSORBER CUSHION, NO.1 | ||||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 90948-03003 |
RZU100..TR..20T;BU10#,112,14#..(DM2,DM5,T2,T3,T4,TW1,TW4)..WT |
2 | ||
| 48530C - WASHER, REAR SHOCK ABSORBER CUSHION, NO.2 | ||||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 48530C - WASHER, REAR SHOCK ABSORBER CUSHION, NO.2 | ||||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 90948-03004 |
BU10#,112,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140..WT |
2 | ||
| 48530D - WASHER, REAR SHOCK ABSORBER CUSHION, NO.3 | ||||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 48530D - WASHER, REAR SHOCK ABSORBER CUSHION, NO.3 | ||||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 90948-03007 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140 |
2 | ||
| 48530E - WASHER, REAR SHOCK ABSORBER CUSHION, NO.4 | ||||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 48530E - WASHER, REAR SHOCK ABSORBER CUSHION, NO.4 | ||||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 90948-03004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 |
2 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48540 - ABSORBER ASSY, SHOCK, REAR LH | ||||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU102..T3..(275T,30T);BU112,14#,RZU140,XZU140..TR |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| 48531-80443 |
BU102..IV4;BU14#,RZU140,XZU140;BU102,RZU100..T3..(275T,30T)..(DSL,LPGB) |
1 | ||
| Common parts | ||||
| 90101-16025 | ||||
| 90101-16026 | ||||
| 90119-08276 | ||||
| 90119-10355 | ||||
| 90170-16016 | ||||
| 90179-16030 | ||||
| 90201-16035 | ||||
| 91611-61020 | ||||
| 93220-18045 | ||||
| 94130-61600 | ||||
| 94184-61201 | ||||
| 94185-60800 | ||||
Part Price Details
Loading price information...
Part Number:
Price:
