BU102-PQMMS3 (1995)
Toyota Dyna 200/Toyoace G25
(9505- )BU100,102,112,12#,132,140,142,162,172,182,202,212,222,RZU100,140 ; (9510
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17269 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 厚さ=1.20 |
2 | ||
| 45201B - RING, SHAFT SNAP(FOR STEERING MAIN SHAFT) | ||||
| 90520-17269 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 厚さ=1.20 |
2 | ||
| 45201Q - RING(FOR STEERING COLUMN RING) | ||||
| 96152-00300 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45204 - TUBE ASSY, STEERING COLUMN, LOWER | ||||
| 45204-37090 |
BU10#,112,12#,13#,14#,162,172,182,RZU100,XZU130 |
1 | ||
| 45205J - TUBE SUB-ASSY, STEERING COLUMN, UPPER | ||||
| 45205-37030 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45210 - SHAFT ASSY, STEERING MAIN | ||||
| 45210-36060 |
BU10#,112,12#,132,14#,162,172,182,RZU100,XZU130 |
1 | ||
| 45210-36060 |
BU132..T3,T4;BU100,102,112,12#,140,142,162,172,182,RZU100,XZU130..02S,03S,06S |
1 | ||
| 45224 - BLOCK, BEARING(FOR STEERING FLEXIBLE COUPLING) | ||||
| 45225-26010 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,140,XZU130,140 長さ=16 |
1 | ||
| 45254 - SHIELD, STEERING COLUMN HOLE | ||||
| 45254-36090 |
BU10#,112,12#,13#,14#,162,172,182,RZU100,140,XZU130,140 |
1 | ||
| 45263 - RING, STEERING COLUMN, NO.1 | ||||
| 45263-32010 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45275 - BRACKET, STEERING COLUMN, UPPER | ||||
| 45307-37020 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,RZU100,XZU130..(DSL,LPG,LPGB,TD)..5F |
1 | ||
| 45286B - COVER, STEERING COLUMN, UPR | ||||
| 45286-37040B0 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 BLUISH GRAY,TRIM1# |
1 | ||
| 45287 - COVER, STEERING COLUMN, LWR | ||||
| 45287-37030B0 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 BLUISH GRAY,TRIM1# |
1 | ||
| 45292A - COVER, MAIN SHAFT LOWER DUST | ||||
| 45292-36030 |
BU100,102,112,12#,132,140,142,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45804 - LEVER SUB-ASSY, STEERING TILT | ||||
| 45804-36010B0 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 GRAY,TRIM1# |
1 | ||
| 45804B - BOLT(FOR STEERING TILT LEVER) | ||||
| 90105-10204 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45804C - WASHER, PLATE(FOR STEERING TILT LEVER) | ||||
| 90201-10489 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45804F - PLUG(FOR STEERING TILT LEVER) | ||||
| 90339-28001B0 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 GRAY,TRIM1# |
1 | ||
| 45819A - COLLAR(FOR TILT LEVER RETAINER) | ||||
| 90387-06037 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 L=47.5 |
1 | ||
| 90386-19004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 長さ=14 |
1 | ||
| 45819A - COLLAR(FOR TILT LEVER RETAINER) | ||||
| 90387-06037 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 L=47.5 |
1 | ||
| 90386-19004 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 長さ=14 |
1 | ||
| 45826A - SPRING, TENSION(FOR STEERING TILT LEVER) | ||||
| 90507-18018 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45826C - BUSH(FOR STEERING TILT LEVER) | ||||
| 90386-10024 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
2 | ||
| 45826C - BUSH(FOR STEERING TILT LEVER) | ||||
| 90386-10024 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
2 | ||
| 45831 - BOLT, TILT LEVER LOCK, NO.1 | ||||
| 45831-36010 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45833 - NUT, TILT STEERING ADJUSTING, NO.1 | ||||
| 45833-36010 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45872 - COVER, STEERING COLUMN TUBE | ||||
| 45872-36020 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 |
1 | ||
| 45890C - COLLAR(FOR TILT STEERING PAWL) | ||||
| 90389-12009 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 外径=20 |
2 | ||
| 45890C - COLLAR(FOR TILT STEERING PAWL) | ||||
| 90389-12009 |
BU10#,112,12#,13#,14#,162,172,182,202,212,222,297,RZU100,140,XZU130,140 外径=20 |
2 | ||
| Common parts | ||||
| 90119-08560 | ||||
| 90119-08843 | ||||
| 90206-18002 | ||||
| 91121-40665 | ||||
| 91611-60616 | ||||
| 91661-60616 | ||||
| 93315-14012 | ||||
| 93540-13008 | ||||
| 93566-15514 | ||||
| 94130-60600 | ||||
| 94531-00600 | ||||
| 94613-10601 | ||||
