YY201-TKMFS (1995)
Toyota Dyna 150/Toyoace G15
(9505- )LY20#,21#,YY101,121,131,201,211
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 74411B - BRACKET, BATTERY, FRONT | ||||
| 74411-25011 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74412 - BRACKET, BATTERY, REAR | ||||
| 74412-25011 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74417 - BRACKET, BATTERY CARRIER | ||||
| 74417-25020 |
YY211..(T2,T3,T4)..CBR;LY201,211,YY201..(T1,T2,T3,T4)..MTM |
1 | ||
| 74417 - BRACKET, BATTERY CARRIER | ||||
| 74417-25020 |
YY211..(T2,T3,T4)..CBR;LY201,211,YY201..(T1,T2,T3,T4)..MTM |
1 | ||
| 74417 - BRACKET, BATTERY CARRIER | ||||
| 74417-25020 |
YY211..(T2,T3,T4)..CBR;LY201,211,YY201..(T1,T2,T3,T4)..MTM |
1 | ||
| 74417 - BRACKET, BATTERY CARRIER | ||||
| 74417-25020 |
YY211..(T2,T3,T4)..CBR;LY201,211,YY201..(T1,T2,T3,T4)..MTM |
1 | ||
| 74417 - BRACKET, BATTERY CARRIER | ||||
| 74417-25020 |
YY211..(T2,T3,T4)..CBR;LY201,211,YY201..(T1,T2,T3,T4)..MTM |
1 | ||
| 74421 - HANGER, BATTERY | ||||
| 74421-26010 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74421-26020 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74421 - HANGER, BATTERY | ||||
| 74421-26010 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74421-26020 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453A - BAR, BATTERY SET PLATE | ||||
| 74453-25090 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453-25080 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74453A - BAR, BATTERY SET PLATE | ||||
| 74453-25090 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453-25080 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74453A - BAR, BATTERY SET PLATE | ||||
| 74453-25090 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453-25080 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74453A - BAR, BATTERY SET PLATE | ||||
| 74453-25090 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453-25080 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74473 - SPACER, BATTERY | ||||
| 74473-36050 |
YY101,121,131,201,211..CBR |
2 | ||
| 74473 - SPACER, BATTERY | ||||
| 74473-36050 |
YY101,121,131,201,211..CBR |
2 | ||
| 74473 - SPACER, BATTERY | ||||
| 74473-36050 |
YY101,121,131,201,211..CBR |
2 | ||
| Common parts | ||||
| 90119-08676 | ||||
| 90119-10531 | ||||
| 90119-10571 | ||||
| 90179-06158 | ||||
| 90179-08141 | ||||
| 91645-C1032 | ||||
| 94130-00802 | ||||
| 94130-01002 | ||||
(9505- )LY10#,11#,12#,13#,15#,16#,YY101,121,131
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 74411B - BRACKET, BATTERY, FRONT | ||||
| 74411-25011 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74412 - BRACKET, BATTERY, REAR | ||||
| 74412-25011 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74413 - BOLT, BATTERY CLAMP | ||||
| 74451-25020 |
YY211..CBR;YY131..IV3;YY131..TS..15T;YY131..T2..ST..CBU;YY131..(T3,TW2)..CBU;LY101,111,121,131,151,161,201,211,YY101,121,201..MTM..(CBR,DSL) ﾎﾞﾙﾄ径=M6 |
2 | ||
| 74417 - BRACKET, BATTERY CARRIER | ||||
| 74417-25020 |
YY211..(T2,T3,T4)..CBR;LY201,211,YY201..(T1,T2,T3,T4)..MTM |
1 | ||
| 74417 - BRACKET, BATTERY CARRIER | ||||
| 74417-25020 |
YY211..(T2,T3,T4)..CBR;LY201,211,YY201..(T1,T2,T3,T4)..MTM |
1 | ||
| 74417 - BRACKET, BATTERY CARRIER | ||||
| 74417-25020 |
YY211..(T2,T3,T4)..CBR;LY201,211,YY201..(T1,T2,T3,T4)..MTM |
1 | ||
| 74421 - HANGER, BATTERY | ||||
| 74421-26010 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74421-26020 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74421 - HANGER, BATTERY | ||||
| 74421-26010 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74421-26020 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74421 - HANGER, BATTERY | ||||
| 74421-26010 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74421-26020 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74421 - HANGER, BATTERY | ||||
| 74421-26010 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74421-26020 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453A - BAR, BATTERY SET PLATE | ||||
| 74453-25090 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453-25080 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74453A - BAR, BATTERY SET PLATE | ||||
| 74453-25090 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453-25080 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74453A - BAR, BATTERY SET PLATE | ||||
| 74453-25090 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453-25080 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74453A - BAR, BATTERY SET PLATE | ||||
| 74453-25090 |
YY211..CBR;LY101,111,121,131,151,161,201,211,YY101,121,131,201..MTM..(CBR,DSL) ｱﾘ(55D23R ﾊﾞﾂﾃﾘ) OR ｱﾘ(75D26R ﾊﾞﾂﾃﾘ) |
1 | ||
| 74453-25080 |
YY201..WT;YY201..ST..15T;YY121,131,211..CBR |
1 | ||
| 74473 - SPACER, BATTERY | ||||
| 74473-36050 |
YY101,121,131,201,211..CBR |
2 | ||
| 74473 - SPACER, BATTERY | ||||
| 74473-36050 |
YY101,121,131,201,211..CBR |
2 | ||
| Common parts | ||||
| 90119-08676 | ||||
| 90119-10571 | ||||
| 90179-06158 | ||||
| 90179-08141 | ||||
