LY211-TQMGS (1995)
Toyota Dyna 150/Toyoace G15
(9505- )TB ; (9505- )LY10#,YY101..T2..IV3
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 65500 - PANEL ASSY, REAR BODY SIDE, RH | ||||
| 65500-25100 |
YY211..LPG;LY111,131,211,YY131,211..(T2,T3,T4)..TB..CBU |
1 | ||
| 65500-25160 |
LY211..T2..TB..MTM..WT..CBU;LY13#,211..(T3,T4)..MTM..CBU;LY13#,YY131,211..T2..TB..WT..CBU;LY11#,16#,212..(T2,T4)..TB..MTM..CBU TECS=ﾊﾟﾜ- ﾘﾌﾄ |
1 | ||
| 65500-25150 |
LY211..T2..TB..MTM..WT..CBU;LY13#,211..(T3,T4)..MTM..CBU;LY13#,YY131,211..T2..TB..WT..CBU;LY11#,16#,212..(T2,T4)..TB..MTM..CBU TECS=ﾊﾟﾜ- ｹﾞ-ﾄ |
1 | ||
| 65500 - PANEL ASSY, REAR BODY SIDE, RH | ||||
| 65500-25100 |
YY211..LPG;LY111,131,211,YY131,211..(T2,T3,T4)..TB..CBU |
1 | ||
| 65500-25160 |
LY211..T2..TB..MTM..WT..CBU;LY13#,211..(T3,T4)..MTM..CBU;LY13#,YY131,211..T2..TB..WT..CBU;LY11#,16#,212..(T2,T4)..TB..MTM..CBU TECS=ﾊﾟﾜ- ﾘﾌﾄ |
1 | ||
| 65500-25150 |
LY211..T2..TB..MTM..WT..CBU;LY13#,211..(T3,T4)..MTM..CBU;LY13#,YY131,211..T2..TB..WT..CBU;LY11#,16#,212..(T2,T4)..TB..MTM..CBU TECS=ﾊﾟﾜ- ｹﾞ-ﾄ |
1 | ||
| 65500G - BOLT, W/WASHER(FOR SIDE GATE, RH) | ||||
| 90119-08464 |
LY101,111,121,131,151,161,201,211,YY121,131,201,211..(T2,T3,T4)..TB..CBU |
10 | ||
| 90119-08464 |
LY102..T2..ATM..IV3;LY12#,13#,16#,21#,YY121,131,211..TB..15T..CBU;LY10#,11#,15#,20#,21#,YY201,211..(T2,T3)..TB..(CBR,DSL) |
10 | ||
| 65600 - PANEL ASSY, REAR BODY SIDE, LH | ||||
| 65600-25100 |
YY211..LPG;LY111,131,211,YY131,211..(T2,T3,T4)..TB..CBU |
1 | ||
| 65600-25150 |
LY211..T2..TB..MTM..WT..CBU;LY13#,211..(T3,T4)..MTM..CBU;LY13#,YY131,211..T2..TB..WT..CBU;LY11#,16#,212..(T2,T4)..TB..MTM..CBU TECS=ﾊﾟﾜ- ｹﾞ-ﾄ |
1 | ||
| 65600-25160 |
LY111,161..T2..TB..CBU;LY211..T2..TB..MTM..WT..CBU;LY131,211..(T3,T4)..MTM..CBU;LY131,YY131,211..T2..TB..WT..CBU TECS=ﾗﾂﾄ ｸﾘﾌ |
1 | ||
| 65600 - PANEL ASSY, REAR BODY SIDE, LH | ||||
| 65600-25100 |
YY211..LPG;LY111,131,211,YY131,211..(T2,T3,T4)..TB..CBU |
1 | ||
| 65600-25150 |
LY211..T2..TB..MTM..WT..CBU;LY13#,211..(T3,T4)..MTM..CBU;LY13#,YY131,211..T2..TB..WT..CBU;LY11#,16#,212..(T2,T4)..TB..MTM..CBU TECS=ﾊﾟﾜ- ｹﾞ-ﾄ |
1 | ||
| 65600-25160 |
LY111,161..T2..TB..CBU;LY211..T2..TB..MTM..WT..CBU;LY131,211..(T3,T4)..MTM..CBU;LY131,YY131,211..T2..TB..WT..CBU TECS=ﾗﾂﾄ ｸﾘﾌ |
1 | ||
| 65600H - BOLT, W/WASHER(FOR SIDE GATE, LH) | ||||
| 90119-08464 |
LY101,111,121,131,151,161,201,211,YY121,131,201,211..(T2,T3,T4)..TB..CBU |
10 | ||
| 90119-08464 |
LY102..T2..ATM..IV3;LY12#,13#,16#,21#,YY121,131,211..TB..15T..CBU;LY10#,11#,15#,20#,21#,YY201,211..(T2,T3)..TB..(CBR,DSL) |
10 | ||
| 65679A - SEAL, SIDE GATE | ||||
| 65679-37010 |
LY102..T2..ATM..IV3;LY12#,13#,16#,21#,YY121,131,211..TB..CBU;LY10#,11#,15#,20#,21#,YY201,211..(T2,T3)..TB..(CBR,DSL) |
1 | ||
| 65679-37010 |
LY101,111,121,131,151,161,201,211,YY121,131,201,211..TB..CBU |
1 | ||
| 65679E - SEAL, SIDE GATE | ||||
| 65679-37010 |
LY101,111,121,131,151,161,201,211,YY121,131,201,211..TB..CBU |
1 | ||
| 65679-37010 |
LY102..T2..ATM..IV3;LY132..TB..15T..CBU;LY12#,131,161,21#,YY121,131,211..TB..CBU;LY10#,11#,151,20#,21#,YY201,211..(T2,T3)..TB..(CBR,DSL) |
1 | ||
| 66110C - HINGE ASSY, SIDE GATE, NO.1 RH | ||||
| 65010-37040 |
LY151,161,201,211,YY201,211..(T2,T3,T4)..TB..CBU 2ND,3RD,4TH |
3 | ||
| 65010-37040 |
YY211..(T2,T3)..15T..CBR;LY16#,211,YY211..15T..CBU;LY15#,201,211,YY201..(T2,T3)..TB 2ND,3RD,4TH |
3 | ||
| 65050-37080 |
LY101,111,121,131,151,161,201,211,YY121,131,201,211..TB..CBU 1ST,5TH |
2 | ||
| 65050-37080 |
YY211..(T2,T3)..15T..CBR;LY121,131,16#,211,YY121,131,211..TB..CBU;LY101,111,15#,201,211,YY201..(T2,T3)..TB 1ST,5TH |
2 | ||
| 66110C - HINGE ASSY, SIDE GATE, NO.1 RH | ||||
| 65010-37040 |
LY151,161,201,211,YY201,211..(T2,T3,T4)..TB..CBU 2ND,3RD,4TH |
3 | ||
| 65010-37040 |
YY211..(T2,T3)..15T..CBR;LY16#,211,YY211..15T..CBU;LY15#,201,211,YY201..(T2,T3)..TB 2ND,3RD,4TH |
3 | ||
| 65050-37080 |
LY101,111,121,131,151,161,201,211,YY121,131,201,211..TB..CBU 1ST,5TH |
2 | ||
| 65050-37080 |
YY211..(T2,T3)..15T..CBR;LY121,131,16#,211,YY121,131,211..TB..CBU;LY101,111,15#,201,211,YY201..(T2,T3)..TB 1ST,5TH |
2 | ||
| 66120C - HINGE ASSY, SIDE GATE, NO.1 LH | ||||
| 65010-37040 |
LY101,111,121,131,15#,16#,201,211,YY121,131,201,211..(T2,T3,T4)..TB..CBU 2ND,3RD,4TH |
3 | ||
| 65050-37080 |
LY211,YY211..TB..CBU;LY101,111,121,131,15#,16#,201,YY121,131,201..(T2,T3)..TB..CBU 1ST,5TH |
2 | ||
| 66120C - HINGE ASSY, SIDE GATE, NO.1 LH | ||||
| 65010-37040 |
LY101,111,121,131,15#,16#,201,211,YY121,131,201,211..(T2,T3,T4)..TB..CBU 2ND,3RD,4TH |
3 | ||
| 65050-37080 |
LY211,YY211..TB..CBU;LY101,111,121,131,15#,16#,201,YY121,131,201..(T2,T3)..TB..CBU 1ST,5TH |
2 | ||
| 66187 - HANDLE, SIDE GATE LATCH, CENTER NO.2 | ||||
| 66187-37010 |
LY102..T2..ATM..IV3;LY12#,13#,16#,21#,YY121,131,211..TB..CBU;LY10#,11#,15#,20#,21#,YY201,211..(T2,T3)..TB..(CBR,DSL) |
1 | ||
| 66187-37010 |
LY101,111,121,131,151,161,201,211,YY121,131,201,211..TB..CBU |
1 | ||
| Common parts | ||||
| 90148-80007 | ||||
| 90148-80008 | ||||
| 90148-80024 | ||||
| 90148-80025 | ||||
| 90179-08245 | ||||
| 90467-08008 | ||||
| 90541-06021 | ||||
