BU60VH-QNFT (1986)
Toyota Dyna/Toyoace Quick
(8601-8708)
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 77018 - VALVE SUB-ASSY, FUEL VAPOUR SEPARATE | ||||
| 77018-36071 |
BU60 |
1 | ||
| 77018-36230 |
BU60 |
1 | ||
| 77022A - HOSE, FUEL(FOR FUEL EVAPORATIVE SEPARATOR) | ||||
| 95332-06040 |
BU60 *H,L=340 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
2 | ||
| 95332-08030 |
BU60 *H,L=280,内径=7.6 |
2 | ||
| 77022A - HOSE, FUEL(FOR FUEL EVAPORATIVE SEPARATOR) | ||||
| 95332-06040 |
BU60 *H,L=340 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
2 | ||
| 95332-08030 |
BU60 *H,L=280,内径=7.6 |
2 | ||
| 77022A - HOSE, FUEL(FOR FUEL EVAPORATIVE SEPARATOR) | ||||
| 95332-06040 |
BU60 *H,L=340 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
2 | ||
| 95332-08030 |
BU60 *H,L=280,内径=7.6 |
2 | ||
| 77031 - CAP ASSY, FUEL TANK | ||||
| 69058-89102 |
BU60 |
1 | ||
| 77031B - GASKET (FOR FUEL TANK CAP) | ||||
| 77316-12031 |
BU60 |
1 | ||
| 77100 - TANK ASSY, FUEL | ||||
| 77001-36821 |
BU60 |
1 | ||
| 77001-36820 |
BU60 |
1 | ||
| 77001-3B160 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 77100A - PLUG(FOR FUEL TANK) | ||||
| 90105-12018 |
BU60 |
1 | ||
| 90105-12116 |
BU60 |
1 | ||
| 77100B - GASKET(FOR FUEL TANK) | ||||
| 90430-12245 |
BU60 |
1 | ||
| 77121 - PROTECTOR, FUEL TUBE | ||||
| 77243-36010 |
BU60 |
1 | ||
| 77197 - ORIFICE, FUEL VAPOR | ||||
| 90977-02001 |
BU60 |
1 | ||
| 77205 - TUBE SUB-ASSY, FUEL MAIN | ||||
| 77205-36420 |
BU60 |
1 | ||
| 77205-36650 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 77205-36421 |
BU60 |
1 | ||
| 77206 - TUBE SUB-ASSY, FUEL TANK SUCTION | ||||
| 77017-36340 |
BU60 |
1 | ||
| 77017-36111 |
BU60 |
1 | ||
| 77241A - HOSE, FUEL, NO.1 (FOR MAIN TUBE, NO.1) | ||||
| 23271-56050 |
BU60 *H,L=180 |
1 | ||
| 23271-56050 |
BU60 *H,L=180 |
1 | ||
| 23271-56060 |
BU60 *H,L=171 |
1 | ||
| 77241B - HOSE, FUEL, NO.2 (FOR MAIN TUBE, NO.1) | ||||
| 95332-08030 |
BU60 *H,L=280,内径=7.6 |
1 | ||
| 95332-10030 |
BU60 *H,L=300 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
1 | ||
| 77241C - HOSE, FUEL, NO.3 (FOR MAIN TUBE, NO.1) | ||||
| 95332-10040 |
BU60 *H,L=400 |
1 | ||
| 95333-08040 |
BU60 長さ=400 |
1 | ||
| 95332-08040 |
BU60 長さ=400,内径=7.6 |
1 | ||
| 77241D - HOSE, FUEL, NO.4 (FOR MAIN TUBE, NO.1) | ||||
| 95332-06022 |
BU60..N..3D *H,L=220,ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 95333-06030 |
BU60 *H,L=300 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
1 | ||
| 95332-08030 |
BU60 *H,L=240,内径=7.6 |
1 | ||
| 77277A - HOSE, FUEL, NO.1(FOR RETURN TUBE, NO.1) | ||||
| 23273-56010 |
BU60 長さ=220 |
1 | ||
| 95332-08020 |
BU60 *H,L=180,内径=7.6 |
1 | ||
| 95333-08020 |
BU60 長さ=200,内径=8 |
1 | ||
| 77277B - HOSE, FUEL, NO.2(FOR RETURN TUBE, NO.1) | ||||
| 95332-10024 |
BU60 *H,L=240 |
1 | ||
| 95332-08030 |
BU60 *H,L=240,内径=7.6 |
1 | ||
| 95332-10022 |
BU60..N..3D *H,L=220,ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
1 | ||
| 77283 - BRACKET, FUEL TUBE | ||||
| 58266-36200 |
BU60 |
2 | ||
| 77324 - SPRING, FUEL TANK CAP | ||||
| 77324-12011 |
BU60 |
1 | ||
| 77611 - BAND, FUEL TANK | ||||
| 77601-36090 |
BU60 |
2 | ||
| 77611 - BAND, FUEL TANK | ||||
| 77601-36090 |
BU60 |
2 | ||
| 77611A - PIN (FOR FUEL TANK BAND) | ||||
| 77629-36010 |
BU60 |
2 | ||
| 77612 - BRACKET SUB-ASSY, FUEL TANK | ||||
| 77501-36090 |
BU60 |
2 | ||
| 77501-36110 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,FRONT |
1 | ||
| 77501-36091 |
BU60 |
2 | ||
| 77501-36091 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,REAR |
1 | ||
| 77612 - BRACKET SUB-ASSY, FUEL TANK | ||||
| 77501-36090 |
BU60 |
2 | ||
| 77501-36110 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,FRONT |
1 | ||
| 77501-36091 |
BU60 |
2 | ||
| 77501-36091 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,REAR |
1 | ||
| 77651 - PACKING, FUEL TANK BRACKET | ||||
| 77651-36110 |
BU60 |
2 | ||
| 77651 - PACKING, FUEL TANK BRACKET | ||||
| 77651-36110 |
BU60 |
2 | ||
| Common parts | ||||
| 90179-08143 | ||||
| 90179-08146 | ||||
| 90467-12011 | ||||
| 90467-13007 | ||||
| 91611-60820 | ||||
| 91611-61045 | ||||
| 91651-40616 | ||||
| 93319-14010 | ||||
| 94110-40800 | ||||
| 94110-41000 | ||||
(8708- )
| Part # | Description | Qty | Price | |
|---|---|---|---|---|
| 77018 - VALVE SUB-ASSY, FUEL VAPOUR SEPARATE | ||||
| 77018-36071 |
BU60 |
1 | ||
| 77018-36230 |
BU60 |
1 | ||
| 77022A - HOSE, FUEL(FOR FUEL EVAPORATIVE SEPARATOR) | ||||
| 95332-06040 |
BU60 *H,L=340 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
2 | ||
| 95332-08030 |
BU60 *H,L=280,内径=7.6 |
2 | ||
| 77022A - HOSE, FUEL(FOR FUEL EVAPORATIVE SEPARATOR) | ||||
| 95332-06040 |
BU60 *H,L=340 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
2 | ||
| 95332-08030 |
BU60 *H,L=280,内径=7.6 |
2 | ||
| 77031 - CAP ASSY, FUEL TANK | ||||
| 69058-89102 |
BU60 |
1 | ||
| 77031B - GASKET (FOR FUEL TANK CAP) | ||||
| 77316-12031 |
BU60 |
1 | ||
| 77100 - TANK ASSY, FUEL | ||||
| 77001-36821 |
BU60 |
1 | ||
| 77001-36820 |
BU60 |
1 | ||
| 77001-3B160 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 77100 - TANK ASSY, FUEL | ||||
| 77001-36821 |
BU60 |
1 | ||
| 77001-36820 |
BU60 |
1 | ||
| 77001-3B160 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 77100A - PLUG(FOR FUEL TANK) | ||||
| 90105-12018 |
BU60 |
1 | ||
| 90105-12116 |
BU60 |
1 | ||
| 77100B - GASKET(FOR FUEL TANK) | ||||
| 90430-12245 |
BU60 |
1 | ||
| 77205 - TUBE SUB-ASSY, FUEL MAIN | ||||
| 77205-36420 |
BU60 |
1 | ||
| 77205-36650 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 77205-36421 |
BU60 |
1 | ||
| 77206 - TUBE SUB-ASSY, FUEL TANK SUCTION | ||||
| 77017-36340 |
BU60 |
1 | ||
| 77017-36111 |
BU60 |
1 | ||
| 77241A - HOSE, FUEL, NO.1 (FOR MAIN TUBE, NO.1) | ||||
| 23271-56050 |
BU60 *H,L=180 |
1 | ||
| 23271-56050 |
BU60 *H,L=180 |
1 | ||
| 23271-56060 |
BU60 *H,L=171 |
1 | ||
| 77241B - HOSE, FUEL, NO.2 (FOR MAIN TUBE, NO.1) | ||||
| 95332-08030 |
BU60 *H,L=280,内径=7.6 |
1 | ||
| 95332-10030 |
BU60 *H,L=300 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
1 | ||
| 77241C - HOSE, FUEL, NO.3 (FOR MAIN TUBE, NO.1) | ||||
| 95332-10040 |
BU60 *H,L=400 |
1 | ||
| 95333-08040 |
BU60 長さ=400 |
1 | ||
| 95332-08040 |
BU60 長さ=400,内径=7.6 |
1 | ||
| 77241D - HOSE, FUEL, NO.4 (FOR MAIN TUBE, NO.1) | ||||
| 95332-06022 |
BU60..N..3D *H,L=220,ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 95333-06030 |
BU60 *H,L=300 |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
1 | ||
| 95332-08030 |
BU60 *H,L=240,内径=7.6 |
1 | ||
| 77277A - HOSE, FUEL, NO.1(FOR RETURN TUBE, NO.1) | ||||
| 23273-56010 |
BU60 長さ=220 |
1 | ||
| 95332-08020 |
BU60 *H,L=180,内径=7.6 |
1 | ||
| 95333-08020 |
BU60 長さ=200,内径=8 |
1 | ||
| 77277B - HOSE, FUEL, NO.2(FOR RETURN TUBE, NO.1) | ||||
| 95332-10024 |
BU60 *H,L=240 |
1 | ||
| 95332-08030 |
BU60 *H,L=240,内径=7.6 |
1 | ||
| 95332-10022 |
BU60..N..3D *H,L=220,ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ |
1 | ||
| 95333-08030 |
BU60 *H,L=300 |
1 | ||
| 77283 - BRACKET, FUEL TUBE | ||||
| 58266-36200 |
BU60 |
2 | ||
| 77324 - SPRING, FUEL TANK CAP | ||||
| 77324-12011 |
BU60 |
1 | ||
| 77611 - BAND, FUEL TANK | ||||
| 77601-36090 |
BU60 |
2 | ||
| 77611 - BAND, FUEL TANK | ||||
| 77601-36090 |
BU60 |
2 | ||
| 77611A - PIN (FOR FUEL TANK BAND) | ||||
| 77629-36010 |
BU60 |
2 | ||
| 77612 - BRACKET SUB-ASSY, FUEL TANK | ||||
| 77501-36090 |
BU60 |
2 | ||
| 77501-36110 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,FRONT |
1 | ||
| 77501-36091 |
BU60 |
2 | ||
| 77501-36091 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,REAR |
1 | ||
| 77612 - BRACKET SUB-ASSY, FUEL TANK | ||||
| 77501-36090 |
BU60 |
2 | ||
| 77501-36110 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,FRONT |
1 | ||
| 77501-36091 |
BU60 |
2 | ||
| 77501-36091 |
BU60..N..3D ﾔﾏﾄｳﾝﾕ ｸ-ﾙﾎﾞﾂｸｽ ｼﾖｳ,REAR |
1 | ||
| 77651 - PACKING, FUEL TANK BRACKET | ||||
| 77651-36110 |
BU60 |
2 | ||
| 77651 - PACKING, FUEL TANK BRACKET | ||||
| 77651-36110 |
BU60 |
2 | ||
| Common parts | ||||
| 90119-08086 | ||||
| 90179-08143 | ||||
| 90179-08146 | ||||
| 90467-12011 | ||||
| 90467-13007 | ||||
| 91611-61045 | ||||
| 91651-40616 | ||||
| 93319-14010 | ||||
| 94110-40800 | ||||
| 94110-41000 | ||||
| 96132-41100 | ||||
| 96132-41500 | ||||
